• Netgear GSM4352PA-100NES 48x1G PoE+ 480W, 2x10G, 2xSFP+ Managed Switch


  M4300-52G-PoE+ (GSM4352PA)
  48x1G PoE+ 480W, 2x10G, 2xSFP+ Managed Switch
  Full-Width 48x1G PoE+ Stackable Managed Switch with 2x10GBASE-T and 2xSFP+ (550W PSU) (GSM4352PA)

  Business Continuity Management
  Full-width switches offer dual redundant, modular power supplies (select m4300 models)

  High Availability (HA)
  Non-stop forwarding (NSF) virtual chassis architectures with hitless failover across the stack

  Multi-Resiliency
  Stacking and distributed link aggregation allow for zero downtime and load balancing capabilities

  PVST+ Interoperability
  Per VLAN Spanning Tree and Per VLAN Rapid Spanning Tree (PVSTP/PVRSTP)

  Link Dependency
  Enables or disables ports based on link state of different ports

  Advanced IPv4/IPv6 security
  Malicious code detection, DHCP Snooping, IP Source Guard protection and DoS attacks mitigation
  Fiber Ports
  48 SFP+ Fiber ports have 1G/10G speeds & 2x 10Gb Copper

  Simple GUI
  Full- functional Web console (GUI) for IT admins who prefer an intuitive graphical interface

  Flexible & Efficient
  Line-rate Spine and Leaf topologies offer many possibilities for server rooms, branch collapsed cores, or at the edge of growing networks

  Mix & Match Stacking
  Stack between 10/40 Gigabit and 1 Gigabit models using any 10G/40G port, with any media type (RJ45, SFP+, DAC cables). Vertical, horizontal, manage as one unit

  Room to Grow
  With PoE+, plug and play ports, and hot swap, you’re ready to grow whenever you need to

  Industry Standard
  SNMP, RMON, MIB, LLDP, AAA, sFlow, RSPAN and PTPv2 1-step transparent clock implementation (select M4300 models)

  Zero Touch AV-over-IP
  Pre-configured for Out-of-Box L2 Multicast (SDVoE-ready)

  No Delay
  Non-Blocking Fabric for Near-Zero Switch Latency

  NETGEAR IGMP Plus™
  Prevent network flooding with effortless multicast implementation of Layer 2 Multicast

  Dedicated Design
  ProAV Engineering Services for AV Network Design and Install Support [email protected]

• SUPPORT & WARRANTY
  Warranty	NETGEAR ProSAFE ® Limited Lifetime Hardware Warranty
  Next Business Day Hardware Replacement	Coverage, availability, and terms and conditions
  Support	ProSUPPORT 24×7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts. ProSUPPORT Lifetime 24×7 Advanced Technical Support via chat.

  TECHNICAL SPECS
  Hardware Specifications	48x1G PoE+ Stackable Managed Switch with 2x10GBASE-T and 2xSFP+ (550W PSU)
  Ordering Number	GSM4352PA
  Acoustics	39.8dB @ 25°C (77°F)
  Power Consumption (Max)	865 Watts
  1G RJ45 Ports	48 x 10/100/1000
  10G RJ45 Ports	2 x 10GBASE-T (Fast Ethernet, 1G and 10G speeds)
  10G Fiber SFP+ Ports	2 x SFP+ (1G and 10G speeds)
  Power over Ethernet	48 x PoE+ 30W
  PoE Budget (Watts)	480W PoE Budget with 1 PSU @ 110V / 220V AC input
  	480W PoE Budget with 2 PSUs in redundant RPS mode @ 110V / 220V AC input
  	720W PoE Budget with 2 PSUs in shared EPS mode @ 110V / 220V AC input
  External RPS4000v2 for power redundancy	(RPS) when 2 internal PSUs are used in EPS mode
  Feature Set	Layer 3 (static, policy-based and RIP OSPF VRRP PIM dynamic routing)
  Management Ports	1G Ethernet service port for out-of-band management (OOB, RJ45)
  	RS232 straight-through serial RJ45 for local management console
  	Mini-USB port for local management console
  	USB port for local storage, logs, configuration, or image files
  Form Factor	Full width with dual, redundant modular PSUs for business continuity
