• Netgear GSM4210PX-100EUS AV Line M4250-8G2XF-PoE+ 8x1G PoE+ 220W and 2xSFP+ Managed Switch

  AV Line M4250-8G2XF-PoE+ (GSM4210PX)
  8x1G PoE+ 220W and 2xSFP+ Managed Switch
  Switching engineered for 1G AV over IP with versatile mounting options for under a table or behind a display. Pre-configured for out of the box functionality!

  POWERFUL AV SWITCHES
  MADE SIMPLE
  Pre-configured to get you up and running faster

  Groundbreaking AV GUI
  A simplified user interface makes it easy to assign configuration profiles to each port.

  Multicast in an Instant
  NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

  Sleek, Quiet Design
  Less fan noise, and mounting ears included for under-table or wall mounting.

  Automatic Configuration
  Auto-trunk and auto-LAG functionality auto connects with other M4250 (and M4300) switches.

  FAST, EASY
  CONFIGURATION
  FOR AV PROS
  A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.

  FOCUS ON THE EVENT
  NOT FAN NOISE
  Most models have quiet mode which greatly reduces fan noise, and some models are even fanless.

  DESIGNED FOR
  AV OVER IP
  RIGHT OUT OF
  THE BOX
  With built-in NETGEAR IGMP Plus™, there’s little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.

  MAXIMISE
  PERFORMANCE
  WITH NETGEAR
  ACCESS POINTS
  Enable powerful, reliable WiFi at your location with WAX600 Series PoE access points.

  PRO AV
  RESOURCES
  All the resources you need to learn about NETGEAR AV over IP solutions, including family brochures, product data sheets, tech tips and more.

• PHYSICAL SPECIFICATION
  Dimensions (WxDxH)	210 x 140 x 40 mm
  Weight	967g (2.13 lb)

  TECHNICAL SPECS
  Primary Port Speed	1 Gigabit
  Number of Ports	10 (8x 1G PoE+, 2x SFP+)
  PoE Ports / Budget	8 PoE+ (30W/port), 220W Budget
  IGMP Support	Enhanced (NETGEAR IGMP Plus™)
  Jumbo Frame Support	Yes, up to 12kb
  AVB Support	Yes. Electronic license required, activation key sent via email (AVB4210PX-10000S)
  Acoustics	Fanless or 3dB at 25ºC
  Power Consumption	With PoE: 257.9W/880.47Btu/hr
  	Without PoE: 18.14W/61.93Btu/hr
  	Standby without any port connection: 9.51W/32.47Btu/hr
  Third-party support	Domotz

  SUPPORT & WARRANTY
  Warranty	This product is backed by a NETGEAR ProSAFE ® Limited Lifetime Hardware Warranty. This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorized reseller, and covers unmodified hardware, fans, and internal power supplies – not software or external power supplies, and requires product registration at https://www.netgear.com/business/registration within 90 days of purchase; see https://www.netgear.com/about/warranty for details. Intended for indoor use only.
  Support	Phone and chat technical support provided for 90 days from the purchase date.
