• Netgear GS116UK 16-Port Gigabit Ethernet Unmanaged Switch


  Gigabit 16-port Unmanaged Switch (GS116)
  16-Port Gigabit Ethernet Unmanaged Switch
  Get networks up and running with plug-and-play unmanaged switches. Set it and forget it, energy-efficient switches are built like tanks and last for decades.

  PLUG & PLAY
  Simple setup with no software or configuration needed

  FLEXIBLE MOUNTING
  Mount on rack, desktop, or wall

  SMALL SIZE, METAL CASE, AND SILENT OPERATION
  Durable quality, space saver, and quietness for peace of mind

  LIFETIME LIMITED WARRANTY & NEXT BUSINESS DAY REPLACEMENT
  NETGEAR has your back to ensure your network is up and running

  STURDY METAL CASE, DESKTOP/RACKMOUNT FORM FACTOR WITH QUIET FANS
  Can be placed on desk or on mounted rack and will operate quietly with assured durability

  Choice of Fast Ethernet and Gigabit Ethernet connectivity

  Energy-efficient technology for power savings

  Auto-MDI/MDIX eliminates the need for crossover cables

  Non-blocking switching architecture for maximum throughput at wire speed

  Auto-negotiation for automatic connection at the highest common speed between switch and an end device

  Desktop or rackmountable

• PHYSICAL SPECIFICATION
  Dimensions (WxDxH) @mm	285 x 102 x 27 mm
  Weight (kg)	0.896

  TECHNICAL SPECS
  Speed	10/100/1000Mbps Gigabit Ethernet
  Number of Ports	16
  PoE ports	N/A
  Total PoE Budget	N/A
  Loop Detection	N/A
  Short cable power saving	N/A
  Energy Efficient Ethernet Support (IEEE 802.3az)	Yes
  Jumbo Frame Support	9KB
  Queue WRR Ratio	1:2:4:8
  MAC Table Size	8K
  Packet buffer size	2MB
  IEEE 802.1p QoS	Yes
  Max Power Consumption	9.5W
  Operating Temperature	0 to 50° C
  MTBF (hours)	554,582
  FCC Class	A

  SUPPORT & WARRANTY
  Warranty	This product is backed by a NETGEAR ProSAFE ® Limited Lifetime Hardware Warranty. Lifetime Next Business Day Hardware Replacement. Coverage, availability, and terms and conditions.
  Support	ProSUPPORT 24×7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five year contracts. ProSUPPORT Lifetime 24×7 Advanced Technical Support via chat.
