NEC MultiSync® V864Q IGB | 60004680 86″ LCD InGlass™ Touch Display
- Descriptions
- Specifications
- Warranty
-
Enjoy the most natural interactive digital experience
Modern meeting spaces drive the demand for advanced touch technology with innovative design. To support interactive sessions, the NEC InGlassTM Touch Board along with the responsive passive pen brings superior paper-like writing with minimal latency to a digital canvas. With its slim bezel design, the technology seamlessly integrates into modern interior styling.
High brightness levels ensure excellent readability and image reproduction even in today’s typically bright meeting spaces where maintaining a motivational environment is paramount. The anti-glare coating minimizes disturbing reflections and helps to eliminate niggling fingerprints on the touch surface.
Best-in-class visual performance – benefit from a „pixel-free“ Ultra-High Definition (UHD) visual performance.
Natural writing experience – it’s like working on paper! Whether using finger or pen, the InGlass™ touch technology provides seamless interactive touch performance including Windows Ink and palm rejection.
Future Ready with Open Modular Intelligence Expansion – upgrade the power of your display at any time by seamlessly integrating one of NEC’s options for OPS Slot-in PCs, Raspberry Pi compute modules or signal interfaces for content feed and computing.
Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
Be more productive – get a one-year free license of FlatFrog Board for Rooms! FlatFrog Board whiteboard software makes hybrid work easy and equally productive for everyone. -
Parameter Value Panel Technology IPS with Edge LED backlights Active Screen Area (W x H) [mm] 1,895 x 1,065.9 Screen Size [inch/cm] 86 / 217 Brightness [cd/m²] 500, 350 (shipment setting) Contrast Ratio (typ.) 1200:1 Viewing Angle [°] 178 / 178 (at contrast ratio > 10:1) Colour Depth [bn] 1.073 (10bit) Response Time (typ.) [ms] 8 (grey-to-grey) Haze Level [%] Pro (28) Supported Orientation Face Up 1; Landscape; Portrait Touch Technology InGlass™ Number of Touches Real multi-touch up to 20 touches Response Time [ms] ≤ 15 Touch Method Finger; Gloves; Stylus (≥ 2 mm) Supported Operating System Native Multi-Touch: Windows 7, Windows 8, Windows 10, Linux, Android; Default Mouse: Windows XP, Windows Vista, Mac OS X Data Interface USB-HID Accuracy [mm] < 1 Palm Rejection No Windows Ink Yes Glass Type Premium toughened glass, anti-glare coating Glass Thickness [mm] 3 Light Transmission [%] 88 (+/- 1 %) Native Resolution 3840 x 2160 Supported Resolutions 1920 x 1080; 1920 x 2160; 3840 x 2160; 4096 x 2160 Horizontal Frequency [kHz] 31.5 – 91.1 Vertical Frequency [Hz] 24 – 85 Input Video Digital 2 x DisplayPort (with HDCP); 3 x HDMI (with HDCP) Input Audio Analogue 1 x 3,5 mm jack Input Audio Digital 2 x DisplayPort; 3 x HDMI Input Control 1 x LAN 100Mbit; 1 x Remote Control (3.5 mm jack); 1 x RS232 Input Data 1 x microSD (MediaPlayer); 1 x USB 2.0 (Downstream); 1 x USB 2.0 (MediaPlayer); 1 x USB Type-B (Upstream); 2 x USB 2.0 (Compute Module, 1 x 5V/2A powered) Output Video Digital 1 x DisplayPort (loop through: DisplayPort, OPS slot-in PC) Output Audio Analogue 1 x 3,5 mm jack Output Control 1 x LAN 100Mbit USB Hub 4x USB 3.0 OPS Slot Slot Technology: Open pluggable specification (NEC / Intel OPS standard) OPS Max. Current / Power Consumption 4.7 A / 75 W Compute Module Slot Slot Technology: Compute Module 3 Slot (NEC proprietary standard) Human Sensor Optional, external, 4-5m range, triggered actions programmable Temperature Sensor Integrated, 3 sensors, triggered actions programmable Power Consumption Eco/max. [W] 242 (shipping) Power Savings Mode [W] < 0.5; < 2 (Networked Standby) Power Management VESA DPMS Operating Temperature [°C] +0 to +35 Operating Humidity [%] 20 to 80 Dimensions (W x H x D) [mm] Without stand: 1,972 x 1,142 x 84.6 Weight [kg] 84 Bezel Width [mm] 19.8 (top and bottom); 20.3 (left and right) VESA Mounting [mm] 4 holes; 400 x 400 (FDMI); 600 x 400 (FDMI); M8 Ingress Protection IP5x (front); IP2x (back) Supported File Storage / File System MicroSDHC / FAT16, FAT32; USB 2.0 / FAT16, FAT32 Supported Image Formats JPG (baseline, progressive, RGB, CMYK); max. resolution 5000 x 5000; PNG (interlace, alpha channel); max. resolution 4000 x 4000 Supported Video Formats MP4 / MOV / FLV (video H.264, audio MP3, AAC); max. resolution 1080p at 30 Hz, 1080i at 60 Hz; MPG (video mpeg1/2, audio mpeg audio layer2/3, AAC-LC); MP @ ML, MP @ HL; WMV (video H.264, wmv advanced L3, wmv simple / main, audio mp3 wmv std); max. resolution 1080p at 30 Hz, 1080i at 60 Hz Supported Audio Formats MP3 (MP3); max. bit-rate 320 kBit/s; WAV (LPCM); max. 48 kHz sampling Accessories Speaker (InfinityBoard Speaker SP-86IBSM, SP-TF1); Trolley (PD02MHA, PD03MHA); Wall mount (BalanceBox 650 MEDIUM, PDW T XL-2) Compute Module Slot NEC Compute Module; Raspberry Pi Compute Module 1 and 3 OPS Slot HDBaseT receiver; Intel® Atom, Celeron and Core CPUs; OPS-2C Quad 3G SDI Energy Efficiency Ambient light sensor; Carbon savings meter; ECOMode; Local dimming Special Characteristics 12-bit Look Up table; Ambient Light Sensor; AMX NetLinx Support; ASCII Control Commands; Auto ID assignment; Auto tiling function; Automated Email Alert; CEC Support; Cisco Webex Kit compatible; Crestron Connected Support; DICOM Simulation; Display Browser Control; Emergency Notification; HDMI with UHD at 60 Hz; HDR Gamma Support (HLG, PQ); KeyGuide; MediaPlayer with Browser Control; NaViSet Administrator 2; OmniColor Control; OSD rotation for portrait mode; PIN as theft protection; PJLink Support; Powered USB-Port; Removable Logo; Scheduler; Slim LED Indicator; SNMP Support; TileMatrix (10 x 10); User readable log function Safety and Ergonomics CE; EMC Class B; FCC; REACH; RoHS Pixel Failure Class ISO 9241-307, Class 1 Audio Integrated Speakers (10 W + 10 W); Optional Speakers (15 W + 15 W) Shipping Content 1x 10 cm USB Cable; 2 x Stylus; 2x 300 cm USB Cable; Cable Clamps; CD-ROM (User Guides/Manuals); Display; DisplayPort Cable; Power Cable; Remote Control Warranty 3 years warranty incl. backlight; optional 4. + 5. year warranty extension Operating Hours 24/7 -
In Warranty Support
Warranty Period 36 Months
Contact: NEC Display Solutions
Tel. No. 01952 237003
Email [email protected]
Manufacturers Website http://www.nec-display-solutions.co.ukNEC deal with all your AfterCare requirements for the product you have purchased, they can help with technical queries and offer advice.
Please contact them direct.
You will need the following information to hand:* Customer Name
* Email Address
* Product Model Number
*Proof of Purchase
* Serial Number
* Details of the fault
* Any permanent security markings?
* Any physical damage?
* Any non-NEC repair or modi?caon?Once provided NEC will be able to issue a return and provide a replacement if required.
If you have any questions or would like further advise, please feel free to contact our AfterCare Team (ACE) on 02081 919223 / who will be happy to assist
3 Year On-Site Warranty. Please contact NEC for full Ts & Cs (exclusions apply).
