• NEC MultiSync® P495 LCD 49″ 4K Professional Large Format Display


  When imaging precision and 24/7 operational reliability cannot be compromised, the 5th generation of NEC MultiSync® P series presents best-in-class performance with an advanced feature set for mission-critical applications

  Unparalleled clarity of detail and colour accuracy is achieved with 8K signal processing, wide colour gamut and the integrated NEC SpectraView® engine controlling all visual parameters. Even in bright ambient light conditions, high brightness levels of 700 cd/m² combined with a high haze filter guarantees exceptional readability with no annoying reflections. Despite its slim, elegant profile, the quality build is robust for use in public spaces, with an all-metal chassis for fire-retardancy. Featuring NEC Open Modular Intelligence (OMI) slot-in technology, choose scalable computing power with Raspberry Pi Compute Module 4 or the more powerful Intel® Smart Display Modules (Intel®SDM) for tailor-made signage solutions.

  For best visualisation in control rooms and production lines, for passenger information and wayfinding signage; the NEC P Series is trusted for safety and long-life, fit-for-purpose performance.

  Benefits
  Secure remote management – control your devices remotely and securely using NEC NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources
  Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
  Safe for public environments – a metal back cover and intelligent heat management ensure safe use in public spaces where fire-retardancy is mandatory
  Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
  Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.

• Specification	Value
  Panel Technology	IPS with Edge LED backlights
  Active Screen Area (W x H)	Not specified.
  Screen Size	49 inches / 124.5 cm
  Aspect Ratio	16:9
  Pixel Pitch	Not specified.
  Brightness	700 cd/m²
  Contrast Ratio	≥ 8000:1
  Viewing Angle	178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
  Colour Depth	1.073 billion (10bit)
  Response Time (typ.)	8 ms
  Panel Refresh Rate	60 Hz
  Haze Level	Pro (28%)
  Supported Orientation	Face Down; Face Up; Landscape; Portrait
  Native Resolution	3840 x 2160
  Supported Resolutions	1024×768, 1280×1024, 1360×768, 1366×768, 1400×1050, 1440×900, 1600×1200, 1920×1080, 1920×2160, 2560×1440, 2560×1600, 3840×2160, 4096×2160, 7680×4320
  Horizontal Frequency	15-135 kHz
  Vertical Frequency	23-76 Hz
  Input Video Digital	2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP)
  Input Audio Digital	1 x DisplayPort; 2 x HDMI
  Input Control	LAN 100Mbit; remote control wire (3.5mm jack); RS232
  Input Data	1 x USB 2.0 (Downstream); 1 x USB 2.0 (Powered 5V/2A, Firmware Updates); 1 x USB 2.0 Type-B (Downstream)
  Output Video Digital	1 x DisplayPort (loop through: DisplayPort, SDM slot-in PC); 1 x HDMI (loop through: HDMI, SDM slot-in PC)
  Output Audio Analogue	1 x 3.5 mm jack
  Output Control	1 x LAN 100Mbit
  Input Detect	Custom; First; Last
  PiP/PbP	Dual-Split; Quad-Split; scalable picture size
  Factory Calibration	Gamma; Intensity; RGB; Uniformity; White Point
  Sensor Calibration	PC-less Calibration with USB Sensor MDSVSensor3; White Copy (post self-calibration)
  Calibration Software	NEC Display Wall Calibrator
  Intel® SDM	Accepts Intel® Smart Display Modules Large and Small up to 66 W
  Compute Module Slot	RPi Compute Module 4
  Ambient Light Sensor	Integrated, triggered actions programmable
  Temperature Sensor	Integrated, 3 sensors, triggered actions programmable
  Power Consumption Eco/max.	105 W shipping
  Power Savings Mode	<0.5 W; <2 W (Networked Standby)
  Power Supply	100-240 V AC; 50/60 Hz; internal
  Operating Temperature	+0 to +40°C
  Operating Humidity	20% to 80%
  Storage Humidity	10% to 90%
  Storage Temperature	-20 to +60°C
  Dimensions (W x H x D)	1,103.4 x 636.2 x 61.1 mm
  Weight	22.9 kg
  Bezel Width	12 mm (top); 12.5 mm (left and right); 15.6 mm (bottom)
  VESA Mounting	300 x 300 (FDMI); 4 holes; M6
  Ingress Protection	IP5x (front); IP2x (back)
  Packaging Dimensions (W x H x D)	1,298 x 860 x 224 mm
  Packaging Weight	29.8 kg
  Colour Bezel	Pantone 426M (black)
  Material	Metal
  Accessories	Feet (ST-43M); Presence Sensor
