NEC MultiSync® MA431 LCD 43″ 4K Message Advanced Large Format Display | 60005046

• Description
• Specifications
• Warranty
• Downloads

• NEC MultiSync® MA431 LCD 43″ 4K Message Advanced Large Format Display

  Meticulously powerful signage
  When true-to-life colour rendition is essential, the MA Series’ advanced feature set delivers calibrated precision, without compromise. For specialist applications, the wide colour gamut panel, SpectraView engine technology and 8K signal processing, positions the MA series at the high end of professional content delivery.

  The MA series’ modular design includes Intel® Smart Display Module (Intel® SDM) technology integrated into the display, facilitating powerful media playback for the most intuitive signage creation and delivery. Featuring an integral audio amplifier, multi-picture mode technology and extensive connectivity including video out, the MA series offers versatile functionality for corporate signage and prestige retail applications.

  Benefits
  Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
  Wide colour gamut – high-performance panel technology delivers a wider spectrum of colours for a superb visual experience
  Safe for public environments – a metal back cover and intelligent heat management ensure safe use in public spaces where fire-retardancy is mandatory
  Enhanced imaging performance – advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.
  Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.

• Specification	Value
  Panel Technology	IPS with Edge LED backlights
  Screen Size	43 inches / 108 cm
  Aspect Ratio	16:9
  Brightness	500 cd/m²
  Contrast Ratio	≥8000:1
  Viewing Angle	178° horizontal / 178° vertical (typ. at contrast ratio 10:1)
  Colour Depth	1.073 billion (10bit)
  Colour Gamut	86% of DCI
  Response Time (typ.)	8 ms
  Panel Refresh Rate	60 Hz
  Haze Level	Pro (28%)
  Supported Orientation	Face Up, Landscape, Portrait
  Native Resolution	3840 x 2160
  Supported Resolutions	1024×768, 1280×1024, 1280×720, 1360×768, 1366×768, 1400×1050, 1440×900, 1600×1200, 1920×1080, 1920×1200, 1920×2160, 2560×1440, 2560×1600, 3840×2160, 4096×2160, 7680×4320
  Horizontal Frequency	15-135 kHz
  Vertical Frequency	23-86 Hz
  Input Video Digital	2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP)
  Input Audio Digital	1 x DisplayPort; 2 x HDMI
  Input Control	LAN 100Mbit, remote control wire (3.5mm jack), RS232
  Input Data	1 x USB 2.0 (Downstream), 1 x USB 2.0 (Powered 5V/2A, Firmware Updates), 1 x USB 2.0 Type-B (Downstream)
  Output Video Digital	1 x DisplayPort (loop through: DisplayPort, SDM slot-in PC); 1 x HDMI (loop through: HDMI, SDM slot-in PC)
  Output Audio Analogue	1 x 3.5 mm jack
  Output Control	1 x LAN 100Mbit
  Input Detect	Custom; First; Last
  PiP/PbP	Dual-Split; Quad-Split; scalable picture size
  Factory Calibration	Gamma; Intensity; RGB; Uniformity; White Point
  Sensor Calibration (through USB)	PC-less Calibration with USB Sensor MDSVSensor3; White Copy (post self-calibration)
  Calibration with Software	Corner Uniformity; Gamma; Intensity; RGB; Update Factory Calibration; White Point
  Calibration Software	NEC Display Wall Calibrator
  Intel® SDM	accepts Intel® Smart Display Modules Large and Small up to 66 W
  Compute Module Slot	RPi Compute Module 4
  Ambient Light Sensor	Integrated, triggered actions programmable
  Temperature Sensor	Integrated, 3 sensors, triggered actions programmable
  Power Consumption Eco/max.	70 W shipping
  Power Savings Mode	<0.5 W; <2 W (Networked Standby)
  Power Management	VESA DPMS
  Power Supply	100-240 V AC; 50/60 Hz; internal
  Operating Temperature	+0 to +40°C
  Operating Humidity	20% to 80%
  Storage Humidity	10% to 90%
  Storage Temperature	-20 to 60°C
  Dimensions (W x H x D)	968.2 x 561 x 67.1 mm
  Weight	18.5 kg
  Bezel Width	11 mm (left, right, and top); 15.6 mm (bottom)
  VESA Mounting	300 x 300 (FDMI); 4 holes; M6
  Ingress Protection	IP5x (front); IP2x (back)
  Packaging Dimensions	1120 x 700 x 203 mm
  Packaging Weight	23 kg
  Colour Bezel	Pantone 426M (black)
  Material	Metal

• In Warranty Support
  Warranty Period 36 Months
  Contact: NEC Display Solutions
  Email uklcdservice@emea.nec.com
  Manufacturers Website http://www.nec-display-solutions.co.uk

  NEC deal with all your AfterCare requirements for the product you have purchased, they can help with technical queries and offer advice.


  Please contact them direct.
  You will need the following information to hand:

  * Customer Name
  * Email Address
  * Product Model Number
  *Proof of Purchase
  * Serial Number
  * Details of the fault
  * Any permanent security markings?
  * Any physical damage?
  * Any non-NEC repair or modi?caon?

  Once provided NEC will be able to issue a return and provide a replacement if required.

  If you have any questions or would like further advise, please feel free to contact our AfterCare Team (ACE) on 02081 919223 / who will be happy to assist

  3 Year On-Site Warranty. Please contact NEC for full Ts & Cs (exclusions apply).

• Description	Downloads
  Datasheet	Downloads
  User Manual	Downloads
  Product Drawings	Downloads
  Energy Label	Downloads
