• NEC MultiSync® M551-2 LCD 55″ 4K Message Large Format Display


  Intuitive professional content delivery
  Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation and high haze panel to reduce reflections when ambient light is high, the Mxx1-2 series is the professional way to deliver your message, yet at an attractive price point.

  With the optional Raspberry PI Compute Module or the more powerful Intel® Smart Display Module (Intel® SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment and meeting room applications, the Mxx1-2-2 Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.


  Benefits
  Modern and slim design – robust yet elegant allowing for an unobtrusive integration into any application and environment.
  Secure remote management – control your devices remotely and securely using NEC NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources
  Ease of use and operation – smart installation, operation and maintenance functionality ensures accurate performance over the entire lifetime of the display saving time, effort and resources.
  Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
  Effortless content playback – the integrated USB media player supports various image video file formats for effortless and standalone content playback.

• Category	Specification
  Display
  Panel Type	VA with Direct LED
  Screen Size	55″ (138.8 cm)
  Aspect Ratio	16:9
  Brightness	500 cd/m²
  Contrast Ratio	≥ 8000:1
  Viewing Angle	178° H / V
  Colour Depth	1.073B (8bit + FRC)
  HDR Support	HDR10, HLG, PQ
  Response Time	8 ms
  Refresh Rate	60 Hz
  Haze Level	25% (Pro)
  Orientation	Landscape, Portrait
  Resolution
  Native Resolution	3840 x 2160 (4K UHD)
  Supported Resolutions	Up to 4096 x 2160
  Sync Rates
  Horizontal	26 – 135 kHz
  Vertical	23 – 86 Hz
  Connectivity
  Video Inputs	1x DisplayPort, 2x HDMI (HDCP)
  Audio Inputs	DisplayPort, HDMI
  Control Inputs	LAN, RS232, 3.5mm jack
  USB Port	1x USB 2.0 (MediaPlayer)
  Audio Output	1x 3.5 mm jack
  Input Detect	Custom, First, Last
  Modular Options
  Intel® SDM Slot	Large/Small up to 66W
  Compute Module Slot	Raspberry Pi CM4
  Sensors
  Temperature Sensors	3 (programmable actions)
  Power
  Consumption	120 W (Shipping)
  Standby Mode	<0.5W / <2W (Network)
  Power Supply	100–240V AC, 50/60 Hz
  Environmental
  Operating Temp	0°C to 40°C
  Operating Humidity	20% to 80%
  Storage Temp	-20°C to 60°C
  Storage Humidity	10% to 90%
  Mechanical
  Dimensions (WxHxD)	1241.8 x 712.6 x 62.6 mm
  Weight	19.8 kg
  Bezel Width	13.9 mm
  VESA Mount	400 x 400 mm (M6)
  IP Rating	IP5x (Front), IP2x (Back)
  Packaging Size	1430 x 920 x 250 mm
  Packaging Weight	29.4 kg
  Bezel Colour	Pantone 426M (Black)
  Material	Metal
  Media Player
  File System	USB 2.0 / FAT16, FAT32
  Image Formats	JPG (max 15360×8640)
  Video Formats	MPG, MP4, TS, WMV (up to 4K@60Hz)
  Audio Formats	MP3 (max. 320 kbps)
  Features
  Audio Output	2x 10W Integrated Speakers
  Special Functions	HDMI ARC, DICOM Sim, 10W USB Power
  Software	NaViSet Admin 2, Scheduler
  Operating Hours	24/7 Commercial Use
  External Control	AMX, Crestron, PJLink, CEC, SNMP, HTTP
  Remote Management	Email Alerts, NaViSet Admin 2
  Security	HW Button/IR Disable, Emergency Alerts
  Accessories
  Optional Add-ons	Feet, Sensor, Trolley, Wall Mount
  Certifications
  Safety & Eco Certs	CE, FCC, RoHS, EnergyStar 8, VCCI, etc.
  Energy Class	Class G (118 kWh/1000h)
  Pixel Policy	ISO 9241-307, Class 1
  Fire Resistance	UL94-5VB Certified Materials
  In the Box
  Contents	Display, Remote, HDMI & Power Cable, Manual, Batteries
  Warranty
  Coverage	3 Years incl. backlight (Optional 4th/5th Yr)
