NEC MultiSync® M321 LCD 32″ FHD Message Large Format Display | 60005288
- Description
- Specifications
- Warranty
- Downloads
-
NEC MultiSync® M321 LCD 32″ FHD Message Large Format Display
Intuitive professional content delivery
For economical signage in 24/7 commercial environments, the 32” MultiSync® M321 delivers all the professional performance and features you need, whilst minimising the cost of ownership. With a 450 cd/m2 brightness output and anti-glare panel, the viewer enjoys excellent visual quality unhindered by reflections, with a slim, aesthetic design for unobtrusive integration.
Featuring multiple industry standard digital and analogue signal inputs, the M321 is future-proof for flexible integration. It also features full external control support through both RS-232 or LAN connectivity enabling operators to achieve time and cost savings when managing an estate of displays.
The full metal chassis, high end componentry and integrated schedule function affords peace of mind for extended runtimes, ideal for retail and transportation applications.
Benefits
Modern and slim design – robust yet elegant allowing for an unobtrusive integration into any application and environment.
Secure remote management – control your devices remotely and securely using NEC NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources
Unhindered readability – no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation
Mission-critical 24/7 ready operation – the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures. -
Category Specification Panel Technology IPS with Direct LED backlights Screen Size 32 inches / 80 cm Aspect Ratio 16:9 Brightness 450 cd/m² Contrast Ratio 1100:1 Viewing Angle 178° horizontal / 178° vertical (typ. at contrast ratio 10:1) Colour Depth 16.7 billion (8bit) Response Time 8 ms Panel Refresh Rate 60 Hz Haze Level Pro (28%) Supported Orientation Face Up 1; Landscape; Portrait Native Resolution 1920 x 1080 Supported Resolutions 1024 x 768; 1280 x 1024; 1280 x 720; 1360 x 768; and more Horizontal Frequency 26 – 91.1 kHz Vertical Frequency 23 – 86 Hz Input Video Analogue 1 x VGA Input Video Digital 1 x DisplayPort (with HDCP); 2 x HDMI (with HDCP) Input Audio Digital 1 x DisplayPort; 2 x HDMI Input Control LAN 100Mbit; remote control wire (3,5mm jack); RS232 Input Data 1 x USB 2.0 (MediaPlayer) Output Audio Analogue 1 x 3,5 mm jack Input Detect Custom; First; Last Ambient Light Sensor Integrated, triggered actions programmable Temperature Sensor Integrated, 3 sensors, triggered actions programmable Power Consumption Eco/max. 40 W (shipping) Power Savings Mode < 0.5 W; < 2 W (Networked Standby) Power Management VESA DPMS Power Supply 100-240 V AC; 50/60 Hz; internal Operating Temperature +0 to +40°C Operating Humidity 20% to 80% Storage Humidity 10% to 90% Storage Temperature -20 to 60°C Dimensions (W x H x D) 726.5 x 425.4 x 66.5 mm Weight 6.3 kg Bezel Width 11.8 mm (top); 11.9 mm (left and right); 17.2 mm (bottom) VESA Mounting 100 x 100 (FDMI); 200 x 200 (FDMI); 4 holes; M4 Ingress Protection IP5x (front); IP2x (back) Packaging Dimensions 870 x 527 x 160 mm Packaging Weight 9.8 kg Colour Bezel Pantone 426M (black) Material Metal Supported File Storage USB 2.0 / FAT16, FAT32 Supported Image Formats JPG (baseline, progressive, RGB, CMYK), max. res 15360 x 8640 Supported Video Formats MPG, MP4, TS, and more; max. res 3840×2160@60Hz Supported Audio Formats MP3 (max. bit-rate 320 kBit/s) Accessories Feet (ST-32M); Presence Sensor (KT-RC3); Wall mount (PDW T XS) Energy Efficiency Energy consumption: 41 kWh/1000 h; Energy efficiency class: G Ecological Standards EnergyStar 8.0 HDMI ARC Yes Powered USB Port 10 W Removable Logo Yes Safety and Ergonomics CE; EAC; RoHS Pixel Failure Class ISO 9241-307, Class 2 Audio Integrated Speakers (5 W + 5 W) Operating Hours 24/7 External Control AMX NetLinx Support; ASCII Control Commands; Crestron Connected; HDMI CEC; HTTP Browser -
In Warranty Support
Warranty Period 36 Months
Contact: NEC Display Solutions
Email [email protected]
Manufacturers Website http://www.nec-display-solutions.co.ukNEC deal with all your AfterCare requirements for the product you have purchased, they can help with technical queries and offer advice.
Please contact them direct.
You will need the following information to hand:* Customer Name
* Email Address
* Product Model Number
*Proof of Purchase
* Serial Number
* Details of the fault
* Any permanent security markings?
* Any physical damage?
* Any non-NEC repair or modi?caon?Once provided NEC will be able to issue a return and provide a replacement if required.
If you have any questions or would like further advise, please feel free to contact our AfterCare Team (ACE) on 02081 919223 / who will be happy to assist
3 Year On-Site Warranty. Please contact NEC for full Ts & Cs (exclusions apply).
-
Description Downloads Datasheet Downloads User Manual Downloads Product Drawings Downloads Energy Label Downloads
