NEC MultiSync® E868 LCD 86″ 4K Essential Large Format Display
Enhance your meeting and conferencing performance with stunning UHD resolution. Get high-end quality and reliability at a low total cost of ownership with long life-times.
Professional haze levels ensure great visibility without distracting reflections – along with brightness of up to 350 cd/m², the NEC MultiSync® E868 meets the demands of today’s meeting environments
An integrated MediaPlayer supports native UHD resolution and High Dynamic Range (HDR) for deep contrasts and natural looking content playback with auto-play function. Requiring no additional cables, external devices or signage software, the USB MediaPlayer enables a simple seamless professional signage solution.
With this Sharp/NEC display presenters will feel confident during meetings of up to 12 participants whilst retailers and hospitality facilities can boost sales through digital signage. For instant start-up in meeting spaces, inputs are detected automatically with easy switching between HDMI sources. Facilities managers will welcome the ability to remotely control their digital estate via the network thanks to the integrated LAN and NEC NaviSet Administrator 2 functionality making this display the perfect choice for corporate meeting rooms and entry level digital signage.
Benefits
Reduced Installation and Operating Costs – highly energy efficient LED backlit display ensures low power consumption, longer backlight lifetime and lighter design for easy transportation, mounting and integration.
Slim Design and Integrated Speakers – the aesthetic design is pleasing to the eye and enables easy, low cost installation.
Future Ready Connectivity – featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
Standalone operation – the display is designed for straightforward standalone operation due to integrated USB media player, speakers and scheduling functionality.
Effortless content playback – the integrated USB media player supports various image video file formats for effortless and standalone content playback. -
Category Specification Panel Technology IPS with Direct LED backlights Active Screen Area 1,895.04 x 1,065.96 mm Screen Size 85.6 inches / 217.43 cm Aspect Ratio 16:9 Pixel Pitch 0.494 mm Brightness 350 cd/m² Contrast Ratio ≥8000:1 Viewing Angle 178° horizontal / 178° vertical (typical at contrast ratio 10:1) Colour Depth 1.073 billion (10-bit) Response Time 8 ms Panel Refresh Rate 60 Hz Haze Level Pro (25%) Supported Orientation Landscape; Portrait Native Resolution 3840 x 2160 Supported Resolutions 1280 x 720; 1920 x 1080; 1920 x 1200; 3840 x 2160; 4096 x 2160; 640 x 480; 720 x 480; 720 x 576 Horizontal Frequency 15 – 136 kHz Vertical Frequency 24 – 75 Hz Input Video Analogue 1 x VGA; Component (RCA); Composite (RCA) Input Video Digital 3 x HDMI Input Audio Analogue 1 x 3.5 mm jack Input Audio Digital 3 x HDMI Input Control LAN 100Mbit; RS232 Input Data 1 x USB 2.0 (MediaPlayer); 1 x USB Type-C (5V/3A, power for external devices) Output Audio Analogue 1 x 3.5 mm jack Output Audio Digital 1 x SPDIF Remote Control Remote Control IR; RS-232C (9-pin D-sub) Input Ambient Light Sensor Integrated, triggered actions programmable Power Consumption Eco/max. 250 W (shipping) Power Savings Mode <0.5 W; <2 W (Networked Standby) Power Supply 100-240 V AC; 50/60 Hz; internal Operating Temperature +0 to +40 °C Operating Humidity 20% to 80% Storage Humidity 10% to 90% Storage Temperature -20 to +60 °C Dimensions Without stand: 1,927.6 x 1,099.1 x 83.2 mm Weight Without stand: 46 kg Bezel Width 14.3 mm (left, right and top); 14.8 mm (bottom) VESA Mounting 4 holes; 600 x 400 (FDMI); M8 Supported File Storage / File System USB 2.0 / FAT16, FAT32 Supported Image Formats JPG (baseline, progressive, RGB, CMYK); max. resolution 15360 x 8640 Supported Video Formats MPG (MPEG1/2/4, max res 1080p@30Hz); MP4 (MPEG2/4, H.263, H.264, HEVC/H.265, max res 3840×2160@60Hz); TS (MPEG2, H.264, HEVC/H.265, max res 3840×2160@60Hz); audio: LPCM, MP3, AAC; WMV (video H.264, Windows Media Video 9, max res 1080p@30Hz, audio WMA 9, WMA 10 Pro) Supported Audio Formats MP3 (MP3); max. bit-rate 320 kBit/s Accessories Feet (ST-801); Trolley (L20PNSR780MEU); Wall mount (L20PNWALL90EU); Wall mount (SF680P) Energy Efficiency Energy consumption: 176 kWh/1000 h; Energy efficiency class: G; LED backlight Ecological Standards EnergyStar 8.0 Special Characteristics Ambient Light Sensor; Audio settings -
In Warranty Support
Warranty Period 36 Months
Contact: NEC Display Solutions
Email uklcdservice@emea.nec.com
Manufacturers Website http://www.nec-display-solutions.co.ukNEC deal with all your AfterCare requirements for the product you have purchased, they can help with technical queries and offer advice.
Please contact them direct.
You will need the following information to hand:* Customer Name
* Email Address
* Product Model Number
*Proof of Purchase
* Serial Number
* Details of the fault
* Any permanent security markings?
* Any physical damage?
* Any non-NEC repair or modi?caon?Once provided NEC will be able to issue a return and provide a replacement if required.
If you have any questions or would like further advise, please feel free to contact our AfterCare Team (ACE) on 02081 919223 / who will be happy to assist
3 Year On-Site Warranty. Please contact NEC for full Ts & Cs (exclusions apply).
-
Description Downloads Datasheet Downloads User Manual Downloads Product Drawings Downloads Energy Label Downloads
