Multibrackets MBFSC1U M Floorstand Column Pro – (40″-75″)

Multibrackets MBFSC1U M Floorstand Column Pro – (40″-75″)

• Description
• Specifications
• Downloads

• M Floorstand Column Pro MBFSC1U 270 Micro Adjustable – Floor column stand for LCD display, steel, 1.8m height, 1 screen, single side, micro adjustable arms, VESA Max 400×400 – screen size: 40″-75″ – black
  M Floorstand Column Pro MBFSC1U 270 Micro Adjustable is a signage solution – ready to be installed.

  The professional Pro Series A/V line from Multibrackets was designed with the installer in mind. Modular, easy to configure, quick to install and simple to maintain. Developed together with installers we added close to unlimited flexibility and versatility. Based on the Pro Series ultra-flexible aluminum rail it is completely modular and has built in cable management throughout the entire solution to quicken installation and create an esthetic result worth the public eye.

  With its modular construction installers can tailor the M Floorstand Column Pro MBFSC1U 270 Micro Adjustable with the clients need in mind. Possibilities to change, update and reconfigure its design and if ideas change over time Pro Series can follow
  The M Floorstand Column Pro MBFSC1U 270 Micro Adjustable creates a rock steady screen display solution aimed for the retail store, mall or any other public area. 50mm black, brass or chrome tubes can be tailored to fit the environment the unit is positioned in. Mount screens with tilt or fixed displays. Place them side by side and/or above each other.

  This M Floorstand Column series was designed with our Scandinavian heritage in mind and provides a clean Nordic look where each part and detail is made as simple as can be and still service its function. The result a sleek Nordic solution emphasizing quality and function by design and its material choices throughout the entire solution. Widely used in a variety of environments the unit can also be mounted floor to wall via a wall bracket accessory uniquely constructed to hold the pipe connected to the wall.

  Our Pro Series includes hardware so that a basic installation should not be a hassle. The Pro Series possibilities to extend tubes and add details by choice is so vast that one can tailor each solution to its location and needed function.

  Multibrackets Pro Series Floormount Column is ideal for any large screen digital signage application

  Highlights
  A professional, flexible and modular product
  Includes VESA adapters for compatibility up to VESA 400×400
  Integrated cable management throughout the entire solution
  Power click install for an easy, fast and safe installation
  Portrait or landscape position of screen possible
  Hardware kit included

• Attribute	Value
  Article No	7 350 105 214 110
  Color	Black
  For Screen Size	40″~75″
  Universal & VESA Standard	75×75, 100×100, 200×200, 300×300, 400×400
  Material	Steel, Aluminium, Plastic
  Surface Finish	Powder coating
  Weight	34.6 kg
  Measurements	276.7 x 18.5 x 12.9 cm (Main Unit), 83 x 6.3 x 11 cm (Additional Component)
  Max Load	50 kg per screen
  Height	10 mm height adjustment
  Tilt	0°
  Swivel	0°
  Rotate	0°
  Installation	Floorstand
  Warranty	5 years
  Retail Package Specification
  Package Parcels	1 pcs
  Package Measurements	0 x 0 x 0 cm
  Package Weight	0 kg

• Download Type	Downloads
  Drawing PDF	Downloads
