Multibrackets MBC5X1UP M Menu Board Mount Pro – (27″-32″)

Multibrackets MBC5X1UP M Menu Board Mount Pro – (27″-32″)

• Description
• Specifications
• Downloads

• M Menu Board Mount Pro MBC5X1UP VESA 200 – Ceiling mount for LCD display, steel, single side, 5 displays in portait with tilt arms, VESA Max 200×200 – screen size: 27″-32″ – black

  The M M Menu Board Mount Pro MBC5X1UP VESA 200 is our 5 screen side by side menuboard system – ready to be installed.

  The professional Pro Series A/V line from Multibrackets was designed with the installer in mind. Modular, easy to configure, quick to install and simple to maintain. Developed together with installers we added close to unlimited flexibility and versatility. Based on the Pro Series ultra-flexible aluminum rail it is completely modular and has built in cable management throughout the entire solution to quicken installation and create an esthetic result worth the public eye.

  With its modular construction installers can tailor with the clients need in mind. Possibilities to change, update and reconfigure its design and if ideas change over time Pro Series can follow.

  The M Menu Board Mount Pro MBC5X1UP VESA 200 creates a seamless mounting surface through the aluminum rail. The tilted mounting of the displays allow all 5 displays to be placed side by side in portrait and tilted at the same angle with ease creating alignment and true menuboard perfection.

  Designed with our Scandinavian heritage in mind Pro Series provides a clean Nordic look where each part and detail is made as simple as can be and still service its function. Possible to use in a variety of environments our Pro Series Menuboards are truly versatile. The Pro Series possibilities to extend pipes and add details by individual choice is vast so that one can tailor each mount to its location and function. With included hardware kit a basic installation should not be a hassle.

  Multibrackets Pro Series Menuboards is simply ideal for any large screen digital signage application.

  Highlights
  5 displays side by side in portait position
  Aprofessional, flexible and modular product
  Includes VESA adapters for compatibility up to VESA 200×200
  Integrated cable management throughout the entire solution
  Power click install for an easy, fast and safe installation
  Ceiling plate included
  Portrait position of screens
  Hardware kit included

• Attribute	Specification
  For screen size	27″-32″
  Type	Single Side MBC5X1UP
  Universal & VESA standard	Adjustable from 75×75, 100×100, 100×200, 200×100 to 200×200 max
  Optional VESA available	Yes
  Material	Steel, Aluminium
  Color	Black
  Surface Finish	Powder coating/Anodic Oxidation
  Weight	22 kg
  Measurements	110 x 23 x 15 cm
  Max Load	30 kg per screen
  Pillar length	Min: 580mm to Max: 750 mm from ceiling to VESA plate center
  Tilt	Yes, 0~15°
  Swivel	0°
  Rotate	0°
  Cable Management	Yes
  Warranty	5 years
  Retail Package Specification	Package Parcels: 1 pcs
  	Package Measurements: 39.1 x 38.7 x 14.2 cm
  	Package Weight: 39.14 kg

• Download Type	Downloads
  Drawing PDF	Downloads
  Product Fact Sheet	Downloads
