MSI AMD Ryzen AM4 MicroATX Motherboard – A520M-A PRO

• Description
• Specifications

• MSI AMD Ryzen AM4 MicroATX Motherboard


  PRO series helps users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.

  BUSINESS ELEGANCE
  4K Support Onboard HDMI supports up to 4K UHD resolution.
  Audio Boost Reward your ears with studio grade sound quality for the most immersive gaming experience
  Core Boost With premium layout and digital power design to support more cores and provide better performance.
  DDR4 Boost The fully isolated DDR circuit to deliver pure data signals for the best performance and stability.
  2oz Thickened Copper PCB An enhanced PCB design improves heat dissipation and performance reliability

  Core Boost
  Core Boost technology combines MSI’s premium layout and digital power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, but creating the perfect conditions for your CPU overclocking

  PCB WITH 2OZ THICKENED COPPER
  An enhanced PCB design with 2oz thickened copper increases conductivity, improving heat dissipation and performance reliability especially during overclocking.

  TURBO M.2
  Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.

  UNMATCHED MEMORY PERFORMANCE
  MSI motherboards are crammed with features to fuel your system’s memory with more speed, higher overclockability and increased stability. Optimized traces and a fully isolated memory circuitry ensures perfect stability and performance, so you never have to worry about your system crashing.

• Category	Specifications
  Product Group	Motherboards
  Manufacturer	MSI
  SKU	119294
  Product Specifications
  Product Name	MSI A520M-A PRO (Socket AM4/A520/DDR4/S-ATA 600/Micro ATX)
  Web Address	uk.msi.com
  Model Number	A520M-A PRO
  EAN	4719072749927
  UPC	824142224007
  Package Type	Retail
  Warranty	3 Years
  Chipset	AMD A520
  CPU Interface	Socket AM4
  CPU Support	CPU Support
  RAM Technology	DDR4 (Dual Channel)
  RAM Slots	2 x 288-pin
  RAM Speeds	Up to DDR4 4600+ (O.C.)
  Max. Memory Support	64GB
  PCI Express 3.0 x16	1
  PCI Express 3.0 x1	1
  S-ATA 6Gb/s Port(s)	4
  RAID	Raid 0/1/10
  M.2 Socket(s)	1
  On-Board LAN	1 x Realtek RTL8111H Gigabit LAN controller
  On-Board Audio	Realtek ALC892 Codec
  On-Board Video	Processor with integrated graphics is required
  Back PS/2 Keyboard/Mouse Port	1
  Back USB 2.0 Port(s)	2
  Back USB 3.2 Port(s) Type-A Gen 1	4
  Back DVI-D Port(s)	1
  Back HDMI Port(s)	1
  Back LAN Port(s)	1
  Back Audio Jack(s)	3
  24-pin ATX Power	1
  8-pin ATX Power	1
  USB 2.0 Header(s)	2
  USB 3.2 Header(s) Gen 1	1
  Front Panel Audio Connector	1
  TPM Header(s)	1
  Form Factor	Micro ATX
  Product Dimensions
  Product Width	200mm
  Product Length	236mm
  Package Dimensions
  Package Width	26cm
  Package Length	27cm
  Package Height	5.5cm
  Gross Weight	1.66Kg
  Special Features
  Turbo M.2	Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs.
  Core Boost	With premium layout and digital power design to support more cores and provide better performance.
  DDR4 Boost	Advanced technology to deliver pure data signals for the best performance and stability.
  2oz Thickened Copper PCB	An enhanced PCB design improves heat dissipation and performance reliability.
  Audio Boost	Reward your ears with studio grade sound quality.
  Dragon Centre	A brand new software which integrates all MSI exclusive tools with user friendly user interface.
  Package Contents
  Motherboard
  MSI Case Bage
  Quick Installation
  2 x SATA Cables
  IO Shield
  Support Disk
  Keywords	Motherboard, AM3, A520, DDR4, PCIe, HDMI, M-ATX, Micro ATX
