• Matrox Extio N3408 IP KVM Receiver Appliance | XTO3-N3408RX

  Secure IP KVM control for critical workflows
  Matrox® Extio N3408 IP KVM extenders deliver 4K/UHD performance or quad-monitor capabilities over standard Gigabit Ethernet at ultra-low bitrates. Easy to set up, Extio N3408 can be configured as a point-to-point or networked KVM extender to deliver multiple video, keyboard, mouse, USB 2.0, and audio signals using a single fiber optic or copper cable. Aggregated and seamless control of multiple systems from a remote display station with a single keyboard and mouse set leads to efficient operations and increased productivity. TAA compliant SKU available.

  4K KVM extension over standard 1 GbE


  Multi-monitor KVM over a single fiber optic or copper cable


  4Kp60


  Point-to-point KVM


  KVM matrix over IP with fast switching


  Secure KVM with encryption


  Aggregator mode


  Tile View


  Longer distance over WAN or Internet

  Connect further and faster
  The Extio 3 4K KVM extender supports 4K60 4:4:4 applications at low bitrates over standard 1 GbE networks. Featuring four DisplayPort™ connectors, Extio 3 also extends multi-display desktops extender and delivers multiple video, keyboard, mouse, USB 2.0,  audio, and RS232 signals with a single pair of KVM transmitter and receiver units—over LAN, WAN, or internet—for the ultimate KVM matrix over IP.


  Deploy flexible, scalable, secure configurations – easily
  Whether deployed as point-to-point extenders or as KVM over IP, Extio 3 KVM extenders offer the flexibility to adapt to your installations as demands change. With the power to create flexible, scalable, and secure KVM matrix-routing using standard network switches, Extio 3 enables you to easily expand your installations with confidence and without costly upgrades to help future proof your investment.


  Fast multi-monitor, multi-system control
  View and operate four source computer systems from any Extio receiver unit and control them with a single keyboard and mouse set. Seamlessly shift control from one target source system to another simply by moving your mouse across a multi-screen desktop.

  With Aggregator Mode, you can shift from the current desktop to the next by moving the mouse freely across multiple desktops. For an even more efficient way to control multiple KVM systems, the Tile View feature enables you to display up to four separate systems on one 4K or FHD monitor.

  Secure KVM control
  To ensure sensitive information remains protected, Extio 3 features built-in protections to prevent security gaps, and doesn’t require software to be installed on the source system.

  Advanced Encryption Standard (AES) to encrypt signals between transmitters and receivers
  Password and user management with Microsoft® Active Directory®
  802.1x port authentication and IGMPv3 to prevent unauthorized devices from accessing your network
  Syslog support to monitor and record KVM device and user activity


  High availability & redundancy
  Build redundancy and fault tolerance into your installations. Supporting a distributed model of operation, Extio 3 removes single point of failure by storing all device settings and connectivity rules in each transmitter and receiver unit. Extio 3 appliances also feature two network interface ports that are configurable for link redundancy.


  The ultimate IP KVM for Broadcast and Media
  Working with standard COTS network switches, Extio 3 IP KVM extenders offer broadcast environments a best-in-class KVM extension and switching solution over IP that is scalable and cost-effective. With Extio 3’s Aggregator Mode, you can access up to four systems simultaneously, and switch between sources with just a single keyboard and mouse. The 4K Tile View feature gives you advanced multi-system control by extending and displaying up to four FHD systems on a single 4K display.


  Link your KVM devices. Enhance your remote workspace.
  Create a larger multi-monitor workspace by linking multiple Extio 3 receivers with Matrox KMLync, our 4-port keyboard and mouse switch.
  Enjoy seamless mouse movement across larger workspaces. KMLync enables you to control all the Extio 3 receiver devices on a network with a single keyboard and mouse set.


  Always powered. Always on.
  Safeguard against a potential loss of power. Matrox makes available rack-mounted, multi-output redundant power supply units (RPSU) to ensure uninterrupted operation of your Matrox device in case of a power module failure and a redundant power input in case a circuit breaker trips.

• Category	Details
  Part Number	Transmitter Appliance—XTO3-N3408TX Transmitter Card—XTO3-N3408CTX Receiver Appliance—XTO3-N3408RX
  Connectivity
  Video Input	Transmitter Appliance: 3x DisplayPort 1.1, 1x DisplayPort 1.2 Transmitter Card: PCI Express x8 electrical and x16 mechanical, 3x mini DisplayPort 1.1, 1x mini DisplayPort 1.2
  Video Output	Transmitter Appliance: 1x DisplayPort 1.1 Receiver Appliance: 3x DisplayPort 1.1, 1x DisplayPort 1.2
  Link Connector	Transmitter Appliance: 1x RJ45 network port, 1x SFP cage (optional RJ45 or Fiber-optic transceiver) Transmitter Card: 1x RJ45 copper transceiver (option to replace with fiber-optic transceiver) Receiver Appliance: 1x RJ45 network port, 1x SFP cage (optional RJ45 or Fiber-optic transceiver)
  USB Ports	Transmitter Appliance: 1x USB 2.0 (Type B) Transmitter Card: 1x Mini USB 2.0 (Type B) Receiver Appliance: 6x USB 2.0 (Type A)
  Audio Input	Transmitter Appliance: Line in 3.5 mm Receiver Appliance: Line in 3.5 mm, mic in 3.5 mm
  Audio Output	Transmitter Appliance: Line out 3.5 mm Receiver Appliance: Line out 3.5 mm, headphone out 3.5 mm
  RS-232	Transmitter Appliance: 1x 9-pin D-type (female) Receiver Appliance: 1x 9-pin D-type (male)
  Bus Interface	Transmitter Card: PCI Express x8 electrical and x16 mechanical
  Performance
  USB Support	High Speed USB 2.0, Keyboard, mouse, touchscreens, USB 2.0 mass storage device, industrial keyboards, smart card/CAC readers, USB 2.0 (full speed) speakers/sound bars, and other USB HID devices.
  Audio Support	Digital audio embedded in DisplayPort, Stereo analog audio (available with appliances)
  Link Redundancy	Yes (available with appliances)
  Maximum Distance on Copper Cables	Cat5e, Cat6—100 m (328 ft)
  Maximum Distance on Fiber-Optic Cables	OM2, OM3, OM4 (50/125μm) multi-mode – 550 m (1804 ft.), OM1 (62.5/125μm) multi-mode – 275 m (902 ft.), OS1, OS2 (9/125μm) single-mode – 10 km (6.20 mi)
  Maximum Distance over IP	LAN, Private WAN, Internet* * Network conditions vary per region. For optimal user experience, we recommend a ping time of less than 20ms and +/- 10% WC jitter. Please contact Matrox for additional details.
  Network
  Network Standard	1,000 base-T Ethernet, Auto-detect, Half/full duplex
  Routing Scheme	Unicast, Multicast, Multi-unicast
  IP Addressing	IPv4 or IPv6, DHCP (default) and static IP
  Physical
  Product Dimensions	Transmitter Appliance: 1U ½ R, 7.45 x 1.676 x 8.526 inches, 18.9 x 4.26 x 21.66 cm Transmitter Card: Full height, ¾ length, 9.020 x 4.376 inches, 22.91 x 11.12 cm Receiver Appliance: 1U ½ R, 7.45 x 1.676 x 8.526 inches, 18.9 x 4.26 x 21.66 cm
  Power Supply Unit	External PSU, Lockable PSU Connector
  Additional Features	Transmitter Appliance: 3x LED Indicators (status and power), 1x Power & 1x Reset Button Transmitter Card: 1x LED Indicators (status and power) Receiver Appliance: 3x LED Indicators (status and power), 1x Power & 1x Reset Button
  Hardware & Software
  Hardware Included	Transmitter Appliance: 4x 6ft power cord for North America/Japan, UK, Australia/China, Continental Europe/China, USB-A To USB-B 6ft cable Transmitter Card: Mini USB-A To USB-B 2ft cable Receiver Appliance: 4x 6ft power cord for North America/Japan, UK, Australia/China, Continental Europe/China
  Accessories (sold separately)	Rack Mount Kit (RMK-19TR-A), Under Desk Mounting Brackets (RMK-UDMKIT-A), KMLync Keyboard and Mouse Switch (KMLYNC-4Y-XX), 3.5mm Audio Stereo Cable (CAB-AUDIO-TRS6F), Mini DisplayPort Secure Cable solution (SK-SLNB-6), Multi-Mode Fiber Optic Transceiver (XTO3-SFPMM), Single-Mode Fiber Optic Transceiver (XTO3-SFPSM), Secure Mini DisplayPort to DisplayPort Adapter (CAB-MDP-DPF)*, NRG Redundant Power Supply Unit *Not recommended for 4K60 resolutions
  Software	Extio Central Manager (free download)
  General
  Supported Operating Systems	Extio Central Manager Software, Microsoft® Windows® 10 (64-bit), Windows 7 (32-bit), Windows 7 (64-bit), Server® 2016, Server 2012 R2, Server 2008 R2
  EMC/EMI Device Class	Class A
  EMC/EMI Compliance	CE (EU), FCC (US), KC (Korea), RCM (AU/NZ), VCCI (Japan)
  Warranty	Two-year limited warranty with free online or telephone support. Extended warranty available. For more information, contact Matrox Video.
