• RALLY BAR
  All-in-one video bar for medium to large rooms

  SEE WHAT YOU’VE BEEN MISSING
  With a dual-camera system and RightSight 2 auto-framing technology, Rally Bar welcomes remote participants to the conversation. Choose Grid View to eliminate space and frame each person in their stream, Speaker View to highlight the active speaker, or Group View to capture everyone in the room.

  LOOKS BRILLIANT
  An innovative dual-camera system with optical zoom and an AI Viewfinder delivers fluid, cinematic video in medium and large rooms.

  Razor-sharp images at resolutions up to 4K

  Lossless optical zoom

  AI Viewfinder for persistent room view people count

  Motorized pan and tilt with RightSight2 auto-framing

  SOUNDS AWESOME
  Rally Bar’s advanced audio engineering delivers powerful, room-filling sound and makes sure every voice is heard.

  Port tube for enhanced lowfrequencies

  Patented anti-vibration suspensionsystem for full duplex

  GREAT CONVERSATIONS START HERE

  AI Sound Optimization
  Auto-level loud and soft voices – while suppressing unwanted noise – with AI-based RightSound technology that improves over time.

  Adaptive Beamforming
  Focus on the active talker with high-precision beamforming mics.

  EXPAND THE CONVERSATION
  Easily accommodate larger spaces with Rally Mic Pods. Out of the box, Rally Bar has a pickup range up to 7 m, which you can significantly extend by adding up to four Mic Pods.

  COMPATIBLE WITH YOUR PLATFORM OF CHOICE
  Start your meeting with just one touch, seamlessly connecting Rally Bar to your preconfigured room solution.

  DESIGNED FOR DEPLOYMENT AT SCALE

  Run supported video conferencing applications – such as Microsoft Teams® Rooms and Zoom® Rooms – directly on the device with no computer or laptop required.

  Connect via USB to virtually any PC or Mac with no additional software needed.

  Ensure clean, confident installs with secure cable retention and minimal cabling.

  Take advantage of multiple mounting options to deploy Rally Bar quickly and easily across all your medium to large rooms.

  SIMPLE TO MANAGE
  Easily manage your Logitech video collaboration devices with Logitech Sync. Monitor room health, deploy updates, and modify settings all from a single cloud-based platform. And with Sync Insights, you can see how meeting spaces are utilized over time.

  ENSURE BUSINESS CONTINUITY WITH SELECT SERVICE PLAN
  Remove barriers to collaboration and ensure conference rooms are ready for the next meeting. Select is a service plan beneficial for all room sizes and deployments. Optimize uptime with expert assistance within one hour, fast product replacements, and premium Sync functionality to proactively resolve issues before they impact your business. With Select, we partner with you to reduce daily management, optimize performance, and help you maximize your investment.

  SUSTAINABILITY AT LOGITECH
  Logitech is committed to creating a more sustainable world. We are actively working to minimize our environmental footprint and accelerate the pace of social change.

  WELCOME TO THE FAMILY
  Explore Logitech’s beautifully simple, next generation of small, medium, and large room solutions that can be deployed in PC or appliance mode.

• DIMENSIONS
  Height	164 mm
  Width	910 mm
  Depth	130.5 mm
  Lens Depth	28.8 mm
  Weight	7.08 kg
  COMPATIBILITY
  Internet Connection	Wired or wireless
  USB Mode	Windows® 11, Windows 10, the two most recent versions of macOS
  Appliance Mode	Room solution software license (not included)
  TECHNICAL SPECIFICATIONS
  Certifications & Compatibility
  Certifications	Microsoft Teams Rooms on Android™ for medium-sized rooms, Microsoft Teams Rooms on Windows for medium-sized rooms, Zoom Room™, Tencent Meeting Rooms, Google Meet (ChromeOS/USB)
  Appliance Mode	Supports compatible video conferencing software in appliance mode (no PC required) including Microsoft Teams Rooms on Android, Zoom Rooms, RingCentral Rooms™, Tencent Meeting Rooms
  USB Mode	Plug-and-play USB connectivity with virtually any video conferencing application
  Compatibility information	Logitech Compatibility
  General Specifications
  Built-in Components	6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management & retention system, table stand, Logitech CollabOS platform
  Enclosure	All-in-one enclosure with integrated table stand and patented speaker suspension system
  Device Management	Logitech Sync
  Displays Supported	2 (up to 1080p)
  Display Resolution	Up to 1080p
  Network Protocol Support	IPv4, IPv6
  Proxy Support	IP-based Proxy, FQDN-based Proxy, Proxy using PAC file
  Camera
  Resolution	4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
  Pan	Motorized ±25°
  Tilt	Motorized ±15°
  Zoom	15X HD zoom (5X optical and 3X digital)
  Diagonal Field of View	90°
  Horizontal Field of View	82.1°
  Vertical Field of View	52.2°
  Total Room Coverage	132.1° Horizontal x 82.2° Vertical
  Speakers
  Drivers	2x 70 mm
  Sensitivity	92 dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter
  Rated Power	8W
  THD	1kHz <2% at 1W
  Speaker Sampling Rate	48 kHz
  Impedance	4 Ohms
  Microphones
  Frequency Response	90Hz – 16kHz
  Sensitivity	>-36dBFS +/-1 dB @ 1Pa
  Microphone data rate output	48KHz
  Pickup Range	Up to 7 m
  Beamforming Elements	Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
  Audio processing	AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
  Noise suppression	AI-based de-noising algorithm
  Add-on Mics	Supports up to 4 additional Rally Mic Pods and 2 Rally Mic Pod Hubs for larger conference rooms
  RightSense™ Technologies
  RightLight	Renders natural skin tones for each participant
  RightSight	Primary camera frames the active speaker while the AI Viewfinder captures everyone in the room
  RightSound	Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo
  Grid View	Detect and frame all meeting participants to create equitable hybrid meeting experiences
  Interfaces
  HDMI Out	2 (up to 1080p)
  HDMI In	1
  MAC	3x Type A, 1x Type C
  Network	10/100/1G Ethernet
  WiFi	802.11a/b/g/n/ac
  External Mic Input	Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)
  Remote Control	Bluetooth® Low Energy
  Power & Cables
  Power supply	Auto-sensing
  Operating Voltage/Power	100-240V, 19V, 4.74A
  Power Supply Dimensions	127 mm x 51 mm x 30 mm
  DC Cable	1.5 m
  AC Cable	1 m
  HDMI 1.4 Cable	2 m
  USB A to USB C 3.0 Cable	2.2 m
  Environmental
  Operating Temperature	0 to 40°C
  Storage Temperature	-40 to 70°C
  Humidity	10 to 95%
  BTU/hr	57 idle, 64 in meeting
  Security
  Full Disk Encryption	AES-128
  Data Encryption	Symmetric Keys, PKI
  Device Identity	Protected by device attestation
  Device Access	Authenticated using API
  Key Protection	Arm TrustZone, RPMP
  Device Security	Kensington Lock
  Accessories
  Mounts	Wall Mount for Video Bars, TV Mount for Video Bars
  Audio	Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable
  Connectivity	Logitech Strong USB (10 m, 25 m, 45 m)
  Touch Controller	Logitech Tap and Tap IP (Compatibility may vary, see www.logitech.com/support/tap-compatibility for the latest information)
  PACKAGE CONTENTS
  Included	Rally Bar, Power supply, AC power cord, HDMI cable, USB cable, Remote control, Lens caps for main camera and AI Viewfinder, User documentation
  WARRANTY INFORMATION
  Standard	2-year limited hardware warranty included
  Extended	Additional one-year and three-year extended warranties available at the time of hardware purchase. Contact your reseller for availability
  PART NUMBER
  Graphite	960-001311
  White	960-001323
