• Lindy KVM Switch Quad View Extender Module | 32328

  This remote module allows you to replicate the main console of the Quad View KVM Switch PRO (No. 32327) over an IP connection (direct or through a Gigabit switch).

  With the direct connection it’s possible to reach a maximum distance of 100m using a Cat.5e/6 cable.

  While through a Gigabit Ethernet switch the distance can be increased to a maximum of 200m.

  The remote module provides a remote for USB Mouse & Keyboard, a DVI-D Single Link monitor and Audio Stereo 3.5mm interfaces.


  Package Contents:

  1 x KVM Extender Over IP – Remote Module for No.32327

  1 x Multi-Country Power Adapter 5V 2.0A

  1 x Quick Installation Guide

• Category	Feature	Details
  KVM Extender	Connection Type	Standard IP protocol
  	Connection Requirement	Must connect to LAN port of Quad View KVM Switch PRO (No.32327)
  	Direct Cable Connection	Cat.5e/6 100m (200m with gigabit Ethernet switch)
  Video Support	Supported Video Signals	1x DVI-D digital video, up to 1920×1200
  Audio Support	Supported Audio Signals	Analogue stereo speaker signals
  USB Support	Console Connection	USB mouse and keyboard, no USB 2.0
  Environmental Specs	Operating Temperature	0…40°C
  	Storage Temperature	-20…60°C
  	Humidity	0…90%, non-condensing, indoor use only
  Certifications	Compliance	CE, FCC, REACH, and RoHS compliant
