Lindy 3m DisplayPort 1.4 Cable, Anthra Line | 36483
From the Lines cable connectivity concept developed by Lindy, Anthra Line DisplayPort cables are the professional choice for high performance connections in commercial AV and IT installations.
Anthra Line DisplayPort cables are premium connections that feature triple shielded with 28AWG tinned copper conductors for performance and corrosion resistance. High quality 24K gold plated contacts and connectors maintain optimal signal integrity and maximum reliability.
UHD resolutions up to 8K 7680×4320@60Hz 4:2:2 8bit, including 4K 4096×2160@144Hz 4:2:2 10bit and HDCP are supported. DisplayPort 1.4 technology and DisplayPort compliance certification ensures compatibility with all DisplayPort enabled devices.
Anthra Line DisplayPort cables are available in lengths: 0.5m, 1m, 2m, 3m, 5m, 7.5m and 10m.
-
Category Specification Connectors Connector A DisplayPort Male Connector B DisplayPort Male Housing Material ABS Connector Plating 24K Gold 15µm Pin Construction Phosphor Bronze Pin Plating 24K Gold 3µm Dimensions (WxDxH) 20.7×42.6x13mm (0.81×1.68×0.51in) Cable Construction Length 3m (9.84ft) Standard DisplayPort 1.4 Colour Black Type Round Jacket Diameter 7.0mm (0.28in) Jacket Material PVC Conductor Material Copper Conductor Gauge 28AWG Shielding Copper Braid 65% Specifications Supported Bandwidth 32.4Gbit/s Maximum Resolution 7680×4320@60Hz 4:2:2 8bit, 4096×2160@144Hz 4:2:2 10bit Nominal Attenuation 100MHz-450MHz <5.1dB, 450MHz-8100MHz <33.28dB Minimum Bend Radius 58.4mm (2.14in) Operating Temperature -20°C – 80°C (-4°F – 176°F) Storage Temperature -25°C – 85°C (-13°F – 185°F) ATC Approved – Miscellaneous Packaging Type Polybag Warranty 10 years Product Compliance RoHS, REACH, UL Purchasing Information No. 36483 EAN 4002888364836 Available Lengths 0.5m 36480 1m 36481 2m 36482 3m 36483 5m 36484 -
