• Lindy 200m Fibre Optic DisplayPort 1.2 & USB 2.0 KVM Extender | 39380

  Designed for highly demanding use cases the DisplayPort 1.2 & USB 2.0 KVM Extender is capable of supporting DisplayPort 1.2 resolutions up to Ultra HD 4K (7680×4320) at distances of up to 200m using a single MPO/MTP cable (OM3 12 Core Method A 1:1). Using fibre optic technology the Extender is capable of extending these Ultra HD video signals in real time without compression over long distances whilst also extending four USB 2.0 devices* such as a keyboard, mouse and USB drive. The Transmitter and Receiver units are electronically isolated from one another removing the risk of damage via ground loop.

  * Please Note: Isochronous USB devices such as Webcams and Audio interfaces are not supported.


  Package Contents:
  Fibre Optic DisplayPort 1.2 & USB 2.0 KVM Extender (1 x Transmitter, 1 x Receiver)

  2 x 5V 3A Multi-Country (EURO, UK, US & AUS) Power Supply

  LINDY Manual

• Category	Feature	Details
  DisplayPort Features	DP Version Supported	DP 1.2
  	Maximum Resolution	Up to 3840×2160
  	DP Capabilities	Supports highest DP resolutions, MST
  	DP++ Support	Not supported, conversion via active converters only
  	Bandwidth	Up to 5.4Gbps per lane, 21.6 Gbps total
  	Transmission Quality	Uncompressed, real-time, lossless
  USB 2.0 Features	Supported Devices	Supports most USB 2.0 devices except isochronous devices
  	Incompatibilities	Potential issues with isochronous webcams and audio adapters
  	Data Transfer Rate	Up to 11 Mbyte/s total (approx. 1/4 of USB 2.0 max rate)
  	Device Support	Supports USB hubs and other devices
  MPO / MTP Fibre Optic Link	Laser Class	Laser Class 1 product with 0.5mW output
  	Laser Safety	Automatic laser cut-off with retracted/broken MPO cable
  	Optical Transmitters	Automatic shutdown when input signals are off
  	MPO Cable Compatibility	12-core MPO cables OM3 1:1
  Technical Specifications	Dimensions (TX and RX)	Approx. 18 x 12 x 3 cm each
  	Weight (TX and RX)	Approx. 0.6kg each
  	Total Weight	Approx. 1.7kg incl. accessories
  	Operating Temperature	-10°C to 50°C
  	Storage Temperature	-20°C to 75°C
  	Usage Environment	Indoor use in well-ventilated locations
  	Power Consumption	TX: 0.5A / 2.5W, RX: 0.8A / 4W plus connected USB devices
  Notifications	MPO/MTP Cable	1:1 by Method A, up to 200m
  	Handling Cautions	Keep glass fibre plugs/sockets dust-free, avoid high tensile forces, and maintain minimum bending radius
  	Minimum Bending Radius	Approx. 10cm
