LG 86TR3PJ 86″ UHD Education Interactive Createboard Digital Board
- Description
- Specifications
- Warranty
-
True Interactivity for Bringing People Together
Multi Touch
The TR3DJ series can simultaneously use up to 20 points of multi touch. This function offers a lifelike board touch experience and makes collaboration much easier.
Enhanced Visibility with Low Parallax
With 1mm gap between the screen and tempered glass, which supports low parallax, The TR3DJ series can offer precise touch and excellent writing experience.
Dual Pen & Dual Color
The stylus pen comes in two different colors and with two different tip sizes of 3mm and 8mm. The dual pens enable users to write or draw simultaneously.
Easy Writing Experience
The TR3DJ series allows you to write and annotate on sources, so your writing experience can be easy and satisfying.
Air Class
Air Class supports connecting up to 30 students and offers interactive meetings for mobile devices on the same network, providing a variety of tools such as voting, answering, and sharing project texts. Air Class is easily accessible from the TR3DJ’s main toolbar.
Built-in OPS Slot
The TR3DJ series supports OPS* slots, allowing you to easily and conveniently mount an OPS* device at the back of the digital board without the hassle of connecting to an external desktop, offering you more expanded functions.
* OPS : Open Pluggable Specification
ScreenShare Pro
ScreenShare Pro enables you to show up to six shared screens or a file on a screen in real-time, and it has enhanced usability by allowing users to share Chromecast and Apple device mirroring on the same network without any additional application.
Bluetooth Connectivity
TR3DJ supports Bluetooth wireless connections to various devices such as speaker, mouse, keyboard, etc. This is optimal for building a hybrid environment so that online and offline meetings and classes can proceed smoothly.
Web Browser
The TR3DJ series supports an embedded Android web browser, so you can search the web easily and quickly, without connecting to an external tablet or computer.
Toolbar
The Toolbar allows you to easily find and run the tool you need. The annotation feature works on virtually all file types, and you can highlight the section you wish to emphasize using the Spotlight function. The countdown and stopwatch features help you manage class time effectively.
Audio Experience
The TR3DJ series supports built-in speakers in both sides of the front bezel which deliver clear audio experience.
USB Block
USB Block Mode is a security measure that helps prevent data from being copied to unauthorized devices, which is essential for being used in spaces where security is critical. -
Specification/Feature Details Screen Size 86″ Panel Technology IPS Back Light Type Direct Aspect Ratio 16:9 Native Resolution 3,840 X 2,160 (UHD) Refresh Rate 60Hz Brightness 490 nit (w/o Glass Max.), 390 nit (w/o Glass Typ.), 450 nit (w Glass Max.), 350 nit (w Glass Typ.) Contrast Ratio 1,200 : 1 Color Gamut NTSC 68% (Typ.) Viewing Angle (H x V) 178 × 178 Color Depth 10 bit, 1.07 Billion Colors Response Time 8 ms (G to G) Surface Treatment (Haze) Anti Glare, 7 Mohs, Haze 28% Life Time (Min.) 30,000 Hrs Operation Hours (Hours / Days) 16 / 7 Portrait / Landscape No / Yes Bezel Color Black Bezel Width 17.7 / 17.7 / 17.7 / 45.7 mm Weight (Head) 65.75 kg Packed Weight 80.7 kg Monitor Dimensions (W × H × D) 1,957 × 1,160 × 87 mm Carton Dimensions (W × H × D) 2,110 × 225 × 1,283 mm (Box Outer Size) Handle Yes VESA™ Standard Mount Interface 800 × 600 Internal Memory 32 GB Built-In Wi-Fi Slot Type Power Indicator Yes Local Key Operation Yes webOS ver. (Android 9.0) Yes Background Image (Booting Logo Image) Yes Screen Share (Screenshare Pro) Yes 3rd Party Compatibility (Crestron Inside) Yes Power (Smart Energy Saving, PM Mode, Wake on LAN, Network Ready), HDMI-CEC Yes Operating Temperature 0 to 40 Operating Humidity 10% to 90% RH Power Supply AC 100-240 V ~, 50/60 Hz Power Consumption (Typ./Max./DPM/Power off) 320 W / 600 W / Yes / 0.5 W↓ BTU (British Thermal Unit) 1,092 BTU/Hr (Typ.), 2,047 BTU/Hr (Max.) Safety Certification CB / NRTL EMC Certification FCC Class “A” / CE ErP / Energy Star Yes / No OPS type compatible Yes (Slot) OPS Power Built In Yes LG ConnectedCare Yes Input Connectivity HDMI (3, HDCP 2.2 / 1.4), Audio In, RS-232C In, RJ45 (LAN), USB 3.0 Type A (4), USB 2.0 Type A, USB Type C (USB-PD, DP-Alt, Mode) Output Connectivity DP Out (HDMI Out), Audio Out (1, Optical 1 (SPDIF)), Touch USB (2), RJ45 (LAN) Speaker Yes (16 W × 2) OSD Language English, Simplified Chineses, Catalan, Czech, Denmark, Arabic (Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands (Dutch), Norwegian, Polski, Portugues (Europe), Portugues (Brazil), Romanian, Russian, Spanish, Swedish, Turkish, Ukrainian, Traditional Chinese, Hungarian, Latvian, Thai Basic Accessories Power Cord (3 M × 1), USB Cable (Type A-Type B) 5 M × 1, HDMI Cable (3 M × 1), Writing Pen × 2 Pcs, User Manual, QSG, Carton Box, Remote Controller, Wi-Fi Module Touch Specifications Available Object Size for Touch: Ø2 mm↑, Writing Height: ≤3 mm, Response Time: ≤10 ms, Accuracy: ±1 mm, Interface: USB 3.0, Protection Glass Thickness: 4 T (Anti-Glare), Protection Glass Transmission: 87%, Operating System Support: Windows 7 / 8 / 10 / Windows XP / Linux / Mac / Android (Supports one -
Standard Warranty for LG Products
The estimated standard warranty for LG products varies.
Please refer to the below guide, which references general warranty periods beginning from the original purchase date.
Please note: the below is intended as a guide only, and T&Cs may vary depending on your model and product use.Warranty for LG Monitors
Labour : 24 Months
Parts : 24 Months
NOTE: The manufacturer warranty period is the same for consumer and commercial usage.Warranty Terms and Conditions:
Replacement Unit or Parts may be new or remanufactured service exchanges that are equivalent to new in performance and reliability.
The LG warranty does not cover any of the following actions:
a) Periodic check ups, maintenance and repair or replacement of parts due to normal wear and tear.
b) Cost relating to transport, removal or installation of the product.
c) Misuse, including failure to use the product for its normal purposes or incorrect installation.
d) Damage caused by Lightning, Water, Fire, Acts of God, War, Public Disturbances, incorrect mains voltage, improper or insufficient ventilation or any other cause beyond the reasonable control of LG.
The LG manufacturer warranty is only valid when accompanied by the original invoice, sales receipt or confirmation from LGE UK of the warranty period.If the serial number is defaced, missing or illegible, the warranty with LGE UK is null and void. In this case you should contact the dealer from whom the product was purchased.
During the repair process it is possible that any stored data may be lost so it is strongly recommended that you backup any important data and media files before requesting a service. LG will not be responsible for any data corruption or loss however so caused during the repair process or failure of the customer to ensure that all data is properly backed up.
