LG 75UH5J-M 75″ 4K Ultra HD Standart Digital Signage Display
New High Haze UHD Standard Signage
* All images in this page are for illustrative purposes only.
Adequate Brightness Level
The 75UH5J-M series boasts an adequate brightness level of 500 cd/m² for indoor displays, effectively showcasing content and capturing the public’s attention. This makes it an adequate display solution for marketing purposes in various settings, including meeting rooms, airports, retail outlets, and shopping malls.* Actual images available may differ from the example images shown.
High-Performance with webOS
LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
Conformal Coating
In various places the 75UH5J-M series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting 75UH5J-M series from salt, dust, iron powder, humidity, etc.
* Actual images (signage display) available may differ from the example images shown.
IP5x Certified Design
The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.
Compatible with AV Control System
The 75UH5J-M series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*,
boosting business management efficiency.
* Network based control -
Category Details Panel Screen Size 75″ Panel Technology IPS Backlight Type Edge Aspect Ratio 16:9 Native Resolution 3,840 x 2,160 (4K UHD) Refresh Rate 120 Hz Brightness 500 nit (Typ.) Contrast Ratio 1,000:1 Dynamic CR 1,000,000:1 Color Gamut NTSC 72% Viewing Angle (H x V) 178° × 178° Color Depth 1.07 Billion Colors (10 bit (D)) Response Time 6 ms (G to G) Surface Treatment 28% Life Time (Typ.) 50,000 Hrs Operation Hours 24/7 Portrait / Landscape Yes / Yes Mechanical Specification Bezel Color Black Bezel Width 14.9 mm (Even Bezel) Weight (Head) 41.5 kg Packed Weight 51.2 kg Monitor Dimensions (W × H × D) 1,682.4 × 960.3 × 57.9 mm (without Handle and LG Logo) Carton Dimensions (W × H × D) (Box Outer Size) 1,816 × 1,123 × 228 mm Handle Yes VESA™ Standard Mount Interface 600 × 400 mm Environment Conditions Operation Temperature 0°C to 40°C Operation Humidity 10% to 80% Power Power Supply AC 100-240 V~, 50/60 Hz Power Type Built-in Power Power Consumption Typ./Max.: 170 W / 230 W Smart Energy Saving 120 W DPM 0.5 W Power off 0.5 W BTU (British Thermal Unit) 581 BTU/Hr (Typ.), 785 BTU/Hr (Max.) Certification Safety CB / NRTL EMC FCC Class “A” / CE / KC ErP / Energy Star Yes (NewErP) / Yes OPS Compatibility OPS Type Compatible Yes OPS Power Built In No Software Compatibility SuperSign CMS, SuperSign Control+, SuperSign WB, SuperSign Cloud, Mobile CMS, LG Connected Care) Connectivity Input HDMI (3 (HDMI1/2: HDCP 2.2/1.4, HDMI3: HDCP 1.4)), DP (HDCP 2.2/1.3), DVI-D (HDCP 1.4), Audio In, RS-232C In (4 Pin Phone-jack), RJ45 (LAN), IR In, USB 2.0 (Type A) Video / Audio HDMI Out, Audio Out, RS-232C Out (4 Pin Phone-jack), Daisy Chain (Input HDMI, DP / Output HDMI) Sound Speaker Yes Language Supported Languages English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Turkish, Arabic Accessory Basic Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender Optional OPS Kit (KT-OPSF), LSW640A/B (Wall Mount) Special Feature Conformal Coating (Power Board) Key Feature Internal Memory (eMMC) 16 GB, Built-in Wi-Fi, Sensor (Temperature Sensor, Auto Brightness Sensor, Acceleration (Gyro) Sensor), Local Key Operation, Built-in Speaker, webOS 6.0, Local Contents Scheduling, Group Manager, USB Plug & Play, Fail Over, Image (Booting Logo Image, No Signal Image), Sync (RS-232C Sync, Local Network Sync), PIP, PBP (4), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Inside, Smart Energy Saving, PM Mode, Wake on LAN, Network Ready, Beacon, HDMI-CEC), SI Server Setting, webRTC, Pro:Idiom -
Standard Warranty for LG Products
The estimated standard warranty for LG products varies.
Please refer to the below guide, which references general warranty periods beginning from the original purchase date.
Please note: the below is intended as a guide only, and T&Cs may vary depending on your model and product use.Warranty for LG Monitors
Labour : 24 Months
Parts : 24 Months
NOTE: The manufacturer warranty period is the same for consumer and commercial usage.Warranty Terms and Conditions:
Replacement Unit or Parts may be new or remanufactured service exchanges that are equivalent to new in performance and reliability.
The LG warranty does not cover any of the following actions:
a) Periodic check ups, maintenance and repair or replacement of parts due to normal wear and tear.
b) Cost relating to transport, removal or installation of the product.
c) Misuse, including failure to use the product for its normal purposes or incorrect installation.
d) Damage caused by Lightning, Water, Fire, Acts of God, War, Public Disturbances, incorrect mains voltage, improper or insufficient ventilation or any other cause beyond the reasonable control of LG.
The LG manufacturer warranty is only valid when accompanied by the original invoice, sales receipt or confirmation from LGE UK of the warranty period.If the serial number is defaced, missing or illegible, the warranty with LGE UK is null and void. In this case you should contact the dealer from whom the product was purchased.
During the repair process it is possible that any stored data may be lost so it is strongly recommended that you backup any important data and media files before requesting a service. LG will not be responsible for any data corruption or loss however so caused during the repair process or failure of the customer to ensure that all data is properly backed up. -
Description Downloads 75UH5J-M : Leaflet Downloads
