LCD Video Wall Display Super Narrow Bezel Matrix Solution
49″ & 55″ LCD VIDEO WALL DISPLAYS
Go big using our 4K compatible video wall panels, with automatic tiling to fill any space
Seamless Video Wall
With a total screen-to-screen bezel size of 3.5mm these displays are ideal as part of a virtually seamless LCD video wall – providing you with an eye catching, and content focused display. Their super narrow bezel allows you to build video walls of any size.
4K Daisy Chain Tiling
These displays feature DisplayPort in and outputs, allowing you to daisy chain up to a 4K signal once connected. The integrated matrix processor significantly cuts the cost of external hardware, installation and maintenance, providing a cost-effective solution while still maximizing video quality with an immersive viewing experience.
4K Compatible Video Walls
With large video walls content resolution is very important. If you have a 4K source you can achieve stunning Ultra High Definition resolution across your video wall configuration without having to purchase an external matrix controller.
500cd/m² IPS Panel
Commercial grade IPS technology accurately displays image quality and colour depth with no fall-off in colour accuracy. These panels are designed to achieve ultimate lifelike colour temperature when used in either landscape or portrait.
Multiple Inputs
Featuring HDMI and DisplayPort inputs, these displays are ideal whether the screens are being used individually, as part of a video wall using the internal video matrix processor or being run from an external matrix controller.
Eco Friendly Display
Designed to perform at high quality levels while operating at a lower energy usage, these displays feature LED backlight technology that reduces power consumption by around 30%. They also feature an eco-friendly power timer that recognises your input signal so they automatically power off and on and are only in use when needed.
Smart Temperature Control
A fanless cooling system keeps their panels and other internal components at the optimum working temperature; ensuring a long and reliable life for your screen.
Optional Network Upgrade
You can add our Cloud Network Media Player, allowing your video wall to networks so you can remotely update your screen via LAN, WiFi or 4G. To find out more about what features our Digital Signage CMS unlocks -
Panel Resolution 1920×1080 Aspect Ratio 16:9 Brightness (cd/m²) 500 Colour 16.7M Viewing Angle 178° Contrast Ratio 1,300:1 Backlight Life 70,000 Hours AV Inputs/Outputs Inputs DisplayPort In, HDMI In x2, RS-232 In Outputs DisplayPort Out, RS-232 Out Power Input Voltage 100V ~ 240V(50/60Hz) Power Management VESA DPMS Environmental Operating Temperature 0°C to 50°C Operating Humidity 10% to 90% Working Pressure 800-1114 hPa (Altitude:0-2,000m) Accessories Included 1.5m DisplayPort Cable, LAN Cable and IR Sensor, Remote Control, 1.5m Power Cable, User Manual Optional Network or Standalone Media Player, Touch Screen Frame -
3-year warranty.
All standard product ranges come with a 3 year warranty starting from date of invoice. This excludes Electronic Shelf Label (ESL) products which come with a 2 year warranty. This also excludes all bespoke hardware which is manufactured under OEM.Any warranty extension needs to be completed at point of order and should be clearly noted on the sales invoice.
Covers hardware failure but excludes accidental damage or user error.
All screen sizes up to and including 55”, as well as media players, are covered by a swap-out warranty. There may be some situations (such as not having a particular model in stock) where an advanced replacement product cannot be supplied, in these cases a collection, repair and return service will be implemented. Screens larger than 55” and freestanding models (“L” and “OT” ranges only, excluding “LUHB”, “LHDS”, “TAO”, “AB” and “OAB” ranges) are covered by an on-site service.
Free lifetime telephone and email technical support.
-
Spec Sheet Download Link 49″ Video Wall Display – Spec Sheet Download 55″ Video Wall Display – Spec Sheet Download Technical Drawings Download Link 49″ Video Wall Display – Technical Drawing Download 55″ Video Wall Display – Technical Drawing Download User Manual Download Link Video Wall Display – User Manual Download
