iiyama ProLite XUB3293UHSN-B1 32″ 4K Ultra HD Desktop Monitor

• Description
• Spesifications
• Warranty

• iiyama ProLite XUB3293UHSN-B1

  32’’ IPS panel with KVM switch, USB-C dock and RJ45 (LAN)

  Equipped with the KVM switch, the XUB3293UHSN allows you to connect multiple computers that can be operated over one console (monitor, keyboard, mouse). The USB-C dock provides a clean and practical workspace by using a single cable to both send the signal from your notebook to your monitor and power and charge the notebook from the monitor. Additionally, if your monitor is connected to the Internet with a LAN cable, your notebook will automatically be connected to the network as well. IPS panel guarantees wide viewing angles and natural, highly accurate colours.

  iiyama ProLite XUB3293UHSN-B1 is a versatile 32” monitor with a range of innovative features. Its KVM switch allows you to seamlessly switch between multiple computers with just one console, streamlining your workflow and saving you time. The USB-C dock eliminates clutter by allowing you to connect your notebook to the monitor with just one cable, while also providing power and charging capabilities. With an RJ45 (LAN) connection, you can easily connect to the internet and network your devices. The monitor’s IPS panel ensures that you’ll enjoy stunning visuals with vivid colours and wide viewing angles. Whether you’re a professional or a casual user, the XUB3293UHSN-B1 is an excellent choice for anyone looking for a high-quality, feature-rich monitor.

  Unleash productivity, switch seamlessly – KVM switch, your workflow dream


  KVM SWITCH

  Having a monitor with a KVM switch allows you to share the devices connected via USB to your monitor with two different PCs. Just change the signal input in the OSD menu of the monitor and your keyboard, mouse and webcam will switch from your work laptop to your gaming PC.

  ---


  Connect, charge, and work with ease – USB-C dock, your productivity keys




  USB-C DOCK

  The dock allows you to connect your laptop with a single cable to the monitor to both make sure it is charged and connected to a wired network and signal from the laptop is sent to the monitor. With additional USB ports, your mouse, keyboard or webcam can also be connected to the monitor. All thanks to a single cable connecting your laptop* to the USB C dock in the monitor.
  *Functions vary depending on your laptop’s USB-C support.

  ---

  Experience True Color with IPS Technology


  IPS TECHNOLOGY

  IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.

  ---

  Protect Your Eyes with Flicker-Free & Blue Light Reducing Monitors



  FLICKER-FREE + BLUE LIGHT

  The ultimate solution for the comfort and health of your eyes. Flicker-free monitors with the blue light reducer function substantially reduce the strain and fatigue caused by flickering and blue light emittance of regular monitors.

  ---

  Get Immersed in the Game with Integrated Speakers and Headphone Support

  SPEAKERS AND HEADPHONES

  Playing with friends? Use the integrated high-quality speakers. Don’t want to disturb anybody? Plug your headset into the headphone socket and turn the volume up.

• DISPLAY CHARACTERISTICS

  Design	3-side borderless
  Diagonal	31.5″, 80cm
  Panel	IPS Panel Technology LED, matte finish
  Native resolution	3840 x 2160 @60Hz (8.3 megapixel 4K UHD)
  Aspect ratio	16:9
  Panel brightness	350 cd/m²
  Static contrast	1000:1
  Advanced contrast	80M:1
  Response time (GTG)	4ms
  Viewing zone	horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
  Colour support	1.07B 10bit (8bit + Hi-FRC) (sRGB: 99%; NTSC: 93%)
  Horizontal Sync	30 – 135kHz
  Viewable area W x H	698.1 x .392.7mm, 27.5 x 15.5″
  Pixel pitch	0.182mm
  Colour	matte, black

  INTERFACES / CONNECTORS / CONTROLS

  Signal input	HDMI x1 DisplayPort x1 USB-C x1 (Power delivery 65W)
  USB HUB	x2 (v.3.0 (DC5V, 900mA))
  USB-C DOCK	x1 (Power delivery 65W, LAN, USB 3.0)
  HDCP	yes
  Headphone connector	yes
  RJ45 (LAN)	x1

  FEATURES

  Blue light reducer	yes
  Flicker free	yes
  Extra	i-Style Colour
  OSD languages	EN, DE, FR, IT, RU, JP, CZ, NL, PL
  Control buttons	Power, Menu, Right / Volume, Left / Eco, Input Select / Exit
  User controls	picture (brightness, contrast, black tuner, sharpness, OD, ACR, ECO, X-res technology), colour (warm, normal, cool, user colour, i-Style colour, blue light reducer), input select, audio (volume, mute), language, OSD settings (OSD H. position, OSD V. position, OSD background, OSD time out, information), setup menu (video mode adjust, HDMI RGB range, KVM, USB-C, USB BC, opening logo, LED, memory recall)
  Speakers	2 x 3W
  Convenience	Kensington-lock™ prepared, DDC2B

  MECHANICAL

  Display position adjustments	height, swivel, tilt
  Height adjustment	130mm
  Swivel stand	90°; 45° left; 45° right
  Tilt angle	22° up; 3° down
  VESA mounting	100 x 100mm

  ACCESSORIES INCLUDED

  Cables	power, USB, HDMI, DP, USB-C
  Other	quick start guide, safety guide

  POWER MANAGEMENT

  Power supply unit	internal
  Power supply	AC 100 – 240V, 50/60Hz
  Power usage	36W typical, 0.5W stand by, 0.5W off mode

  SUSTAINABILITY

  Regulations	CE, TÜV-Bauart, EAC, PSE, RoHS support, ErP, WEEE, VCCI, REACH, UKCA
  Energy efficiency class (Regulation (EU) 2017/1369)	G
  REACH SVHC	above 0.1%: Lead

  DIMENSIONS / WEIGHT

  Product dimensions W x H x D	714 x 454.5 (574.5) x 230mm
  Box dimensions W x H x D	795 x 506 x 225mm
  Weight (without box)	10kg
  Weight (with box)	12.3kg
  EAN code	4948570118175

• Warranty	Product	Cover
  Visioncare	Desktop LCD products (Monitors)  (17″ – 43″)	3 years on-site UK warranty. (Upgrades to 5 years available)
  Touchcare	LCD touchscreen products	3 years repair and return. (Upgrades to on-site & 5 years available)
  LFD	Large Format Displays Standard Warranty	3 years collect and return (Upgrade to swap, installation & 5 years available) Download

  HOW TO ACTIVATE YOUR WARRANTY

  There is no need to pre-register your warranty, just follow the six simple steps below to activate your warranty should the need arise. First-class service is assured by our experienced engineers and customer service helpdesk.

  Step one – Check that all connections have been properly made.

  Step two – Check the set-up in the user manual. Wherever possible, please try to check your iiyama product with alternate equipment before contacting the iiyama customer service help desk.

  Step three – If the fault cannot be cured by the above means, call the iiyama customer service helpdesk on 01926 819 189. Please have ready to hand the following details: model number, serial number and date of purchase*. Or fill in the Service Request Form.

  Step four – Your fault will be registered and you will be issued with a returns number, which you must quote on all paperwork relating to the defective unit.

  Step five – Please retain any of your leads and manuals. Replacement/returned units will not include these sundry items.

  Step six – Please ensure your product is clean and presentable before packaging it in the original box for collection.

  * Proof of purchase may be required

  ON-SITE SWAP OUT

  PIONEERING CUSTOMER SERVICE.

  iiyama has always strived to achieve maximum reliability and to prove our belief in our products we were the first manufacturer to confidently guarantee our display products with a 3-year on-site warranty as standard changing and shaping the warranty landscape forever.
  Visioncare is our comprehensive warranty support scheme for standard desktop display products.  We understand that should a fault occur, downtime needs to be minimised and vision care was designed to do just that.

  1-) If your display should develop a fault within the first 2 years of purchase, iiyama will arrange a replacement unit of an equivalent or higher specification.
  2-) iiyama endeavours to dispatch the replacement unit within 24hrs whenever possible.
  3-) iiyama takes care of the swap out and all carraige charges.

  And it’s not just us at iiyama that believes we provide great service, our customers think so too. iiyama has been proud to receive many reader-voted magazine awards for customer satisfaction and reliability.

  For Desktop and Touchscreen displays (below 42″) service
  Call 01926 819189 between 9:00am – 5:30pm Monday to Friday
  For Large Format Displays (42″ and above) service
  Call 03302 020 463 between 9:00am – 5:30pm Monday to Friday

  Service request form
