iiyama ProLite TW1623AS-B1P 15.6″ Full HD PCAP 10pt Touch Screen Display

• Description
• Specifications
• Downloads

• iiyama ProLite TW1623AS-B1P 15.6″ Full HD PCAP 10pt Touch Screen Display

  The ProLite TW1623AS-B1P touch panel PC is a perfect choice for high-use environments such as retail, interactive POS, information desks or hospitality applications. Thanks to the pre-installed Android operating system, it is possible to easily customize the monitor by installing applications directly to it.

  The Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, simplifying all installations. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities.

  Connectivity
  The RJ45 (LAN) connector supporting Power over Ethernet technology (POE*) allows to provide both data connection and power by a single cable, simplifying all installations. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities. *Requires 30W


  Android OS
  Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.

  Touch technology – Capacitive
  This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.

  IPS Technology
  IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.

  Anti-fingerprint coating
  This special Nano coating ensures a smoother touch and less resistance in the swipe. It makes the screen less static and susceptible to dirt, dust, fingerprints and it improves the clarity of the content displayed on the screen.

• Category	Specification
  Display Characteristics
  Design	Edge to edge glass
  Diagonal	15.6″, 39.5cm
  Panel	IPS
  Native Resolution	1920 x 1080 (2 megapixel HD)
  Aspect Ratio	16:9
  Panel Brightness	450 cd/m²
  Brightness with Touch	385 cd/m²
  Light Transmittance	86%
  Static Contrast	1000:1 with touch
  Response Time (GTG)	30ms
  Viewing Zone	170°/170° horizontal/vertical
  Colour Support	16.7mln 8bit
  Viewable Area W x H	344.2 x 193.6mm, 13.5 x 7.6″
  Pixel Pitch	0.17925mm
  Bezel Colour and Finish	Black, matte
  Touch
  Touch Technology	Projective capacitive
  Touch Points	10
  Touch Method	Finger, glove, capacitive stylus
  Touch Interface	USB
  Interfaces / Connectors / Controls
  Monitor Control Input	RJ45 (LAN) x1 (PoE – IEEE802.3 at/Max. 30W)
  Digital Signal Output	HDMI x1 (mini HDMI, 1920×1080 @60Hz)
  Audio Output	Mini jack x1
  Speakers	2 x 2W
  USB Ports	x3 (USB 2.0)
  Microphone	x1
  Features
  Integrated Software	Android 13
  CPU	Rockchip RK3568, up to 2GHz
  GPU	Quad-core Cortex A55
  Storage	32GB eMMC
  Memory	4GB DDR4
  WiFi	IEEE802.11a/b/g/n/ac
  Bluetooth	5.2
  Extra	Auto-rotation, SD card slot, anti-fingerprint coating
  Max. Non-Stop Operating Time	24/7
  Anti Image Retention	Yes
  OSD Key Lock	Yes
  Mechanical
  Orientation	Landscape, portrait, face-up
  VESA Mounting	100 x 100mm
  Accessories Included
  Guides	Quick start guide, safety guide
  Cable Cover	Yes
  Power Management
  Power Supply Unit	External
  Power Supply	DC 12 V
  Power Usage	24W typical, 0.5W stand by, 0.3W off mode
  Sustainability
  Regulations	CE, EAC, RoHS, ErP, WEEE, REACH, UKCA
  REACH SVHC	Above 0.1%: Lead
  Dimensions / Weight
  Product Dimensions W x H x D	387 x 244 x 30.5mm
  Box Dimensions W x H x D	477 x 295 x 75mm
  Pallet Volume	150pcs
  Pallet Dimensions W x H x D	1000 x 1200 x 1760mm
  Weight (without box)	1.5kg
  Weight (with box)	2.4kg
  EAN Code	4948570124534
