iiyama ProLite TW1523AS-B1P – 10pt PCAP Android 15.6″ POE Touch Screen Monitor
- Description
- Specifications
- Warranty
-
PROLITE TW1523AS-B1P
15.6” Full HD PCAP 10pt touch screen with Android and POE Technology
The ProLite TW1523AS-B1P touch panel PC is a perfect choice for high-use environments such as retail, interactive POS, information desks or hospitality applications.
The Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, simplifying all installations. This monitor can operate in landscape, portrait and face-up orientation in 24/7 operating time. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities.
CONNECTIVITY
The RJ45 (LAN) connector supporting Power over Ethernet technology (POE*) allows to provide both data connection and power by a single cable, simplifying all installations. Together with the built-in microphone and speakers it offers interactive and almost limitless application possibilities. *Requires 30W
ANDROID OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
TOUCH TECHNOLOGY – CAPACITIVE
This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.
IPS
IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.
ANTI-FINGERPRINT COATING
This special Nano coating ensures a smoother touch and less resistance in the swipe. It makes the screen less static and susceptible to dirt, dust, fingerprints and it improves the clarity of the content displayed on the screen. -
Category Details Design Edge to edge glass Diagonal 15.6″, 39.5cm Panel IPS Panel Technology, LED Native resolution 1920 x 1080 (2 megapixel HD) Aspect ratio 16:9 Panel brightness 450 cd/m² Brightness 385 cd/m² with touch Light transmittance 85% Static contrast 1000:1 with touch Response time (GTG) 30ms Viewing zone horizontal/vertical: 170°/170°, right/left: 85°/85°, up/down: 85°/85° Colour support 16.7mln 8bit Viewable area W x H 344.16 x 193.59mm, 13.5 x 7.6″ Pixel pitch 0.17925mm Bezel colour and finish black, matte Touch technology projective capacitive Touch points 10 Touch method finger, glove (latex), capacitive stylus Touch interface USB Digital signal output HDMI x1 (mini HDMI, 1920×1080 @60Hz) Audio output Speakers 2 x 2W USB ports x2 (2.0) RJ45 (LAN) x1 (PoE – IEEE802.3at/30W) Integrated software Android 8.1 without GMS CPU Rockchip RK3288, quad-core Cortex-A17 up to 1.8GHz GPU Quad-core cortex A17 Storage 16GB eMMC Memory 2GB DDR3 WiFi IEEE802.11b/g/n Bluetooth 4.0 Extra auto-rotation, microphone, SD card slot, anti-fingerprint coating Max. non-stop operating time 24/7 Glass thickness 1.8mm Glass hardness 6H Orientation landscape, portrait, face-up VESA mounting 100 x 100mm Power supply unit external Power supply DC 12 V Power usage 12W typical Regulations CE, RoHS support, ErP, WEEE, REACH REACH SVHC above 0.1%: Lead Product dimensions W x H x D 387 x 244 x 30.5mm Box dimensions W x H x D 477 x 295 x 75mm Pallet volume 150pcs Pallet dimensions W x H x D 1000 x 1200 x 1760mm Weight (without box) 1.5kg Weight (with box) 2.4kg EAN code 4948570118014 -
Warranty Product Cover Visioncare Desktop LCD products (Monitors) (17″ – 43″) 3 years on-site UK warranty. (Upgrades to 5 years available) Touchcare LCD touchscreen products 3 years repair and return. (Upgrades to on-site & 5 years available) LFD Large Format Displays Standard Warranty 3 years collect and return (Upgrade to swap, installation & 5 years available) Download
HOW TO ACTIVATE YOUR WARRANTY
There is no need to pre-register your warranty, just follow the six simple steps below to activate your warranty should the need arise. First-class service is assured by our experienced engineers and customer service helpdesk.
Step one – Check that all connections have been properly made.
Step two – Check the set-up in the user manual. Wherever possible, please try to check your iiyama product with alternate equipment before contacting the iiyama customer service help desk.
Step three – If the fault cannot be cured by the above means, call the iiyama customer service helpdesk on 01926 819 189. Please have ready to hand the following details: model number, serial number and date of purchase*. Or fill in the Service Request Form.
Step four – Your fault will be registered and you will be issued with a returns number, which you must quote on all paperwork relating to the defective unit.
Step five – Please retain any of your leads and manuals. Replacement/returned units will not include these sundry items.
Step six – Please ensure your product is clean and presentable before packaging it in the original box for collection.
* Proof of purchase may be required
