iiyama ProLite TE7512MIS-B1AG 75″ 4K UHD Interactive Touchscreen Display

iiyama ProLite TE7512MIS-B1AG

75″ Interactive Touchscreen Display

The TE7512MIS-B1AG is an exceptional 4K UHD interactive display designed by iiyama to enhance collaboration, communication, and engagement.

• Description
• Specifications
• Warranty
• Downloads

• iiyama PROLITE TE7512MIS-B1AG
  75″ Interactive 4K UHD Touchscreen featuring a 4K interface with User Profiles for Education and Classroom.

  Collaboration for education and enterprise made simple. The TE7512MIS-B1AG from iiyama inspires all possibilities in all stages for education, start-up and large-scale businesses. With our hybrid interactive solution, you can smoothly annotate in 4K and control any content on the display from any source.

  This PureTouch-IR 40-point Touchscreen with iiWare 10 (Android 11 OS) features Note, Browser, Cloud Drive and the option for you to sideload relevant apps you require for your organisation. It comes with dual function Touch pens, and you can easily save your notes and on-screen content directly to a USB device, 32GB internal memory or a selected cloud drive. Including an additional USB-C connection, the display supports the latest in video, audio and Touch signal via a single port and even charge your device with 65W power delivery.

  With a 4K UHD resolution (3840×2160) and 400cd/m2 brightness this 75” IPS LCD screen provides vibrant, detailed, and high-quality images from anywhere in the class or meeting room. The anti-glare coating drastically reduces ambient reflection in high-brightness environments without compromising the sharpness and clarity of the image.

  You can be sure that no matter what your Interactive aspiration, iiyama has the simplified solution just for you. Boasting a new 4K Interface with User Profiles for simple login and access to your very own bespoke menu and Cloud Drives, the TE7512MIS-B1AG becomes a highly personalised device within a busy hybrid environment for multiple users.

  Share, stream and edit content from any device directly on screen and transform your team meetings or lessons into an easy, fast and seamless interactive session with the included WiFi module (OWM002), ScreenSharePro and EShare app.

  PURETOUCH-IR
  PureTouch-IR from iiyama delivers 1mm touch accuracy for the smoothest and fastest annotation.

  IIWARE
  iiWare 10 features Note, Browser, Cloud Drive and the option for you to sideload relevant apps you require for your organisation.

  IIYAMA SHARE
  Connect up to 9 devices and easily share, stream and edit content from your device to your interactive display and vice versa, back to your laptop, tablet or phone. iiyama Share supports AirPlay, Chromecast and Miracast.

  IIYAMA DMS
  This software provides organizations a suitable and fast unified management solution for terminal equipment, builds an efficient and real-time equipment management system, helps digitize the campus/office environment and makes campus/office management more convenient.

  SECURITY
  Utilise Screen lock and USB passcode protection to ensure user security and the new Clean app will clear all data and passwords used.

• DISPLAY CHARACTERISTICS
  Design	Thin bezel
  Diagonal	75″, 189.3cm
  Panel	IPS
  Touch Glass	AG coated glass, zero air-gap
  Native resolution	3840 x 2160 (8.3 megapixel 4K UHD)
  Aspect ratio	16:9
  Panel brightness	400 cd/m²
  Light transmittance	92%
  Static contrast	1200:1
  Dynamic contrast	4000:1
  Response time (GTG)	8ms
  Viewing zone	Horizontal/Vertical: 178°/178°, Right/Left: 89°/89°, Up/Down: 89°/89°
  Colour support	1.07B 8bit+FRC
  Horizontal Sync	30 – 135kHz
  Viewable area W x H	1650 x 928mm, 65 x 36.5″
  Bezel width (sides, top, bottom)	16.5mm, 16.5mm, 45mm
  Pixel pitch	0.4296mm
  Bezel color and finish	Black, matte

  TOUCH
  Touch technology	PureTouch-IR
  Touch points	40, 5pt writing
  Touch accuracy	+- 1.5mm
  Touch method	Stylus, finger, glove
  Touch interface	USB
  Supported operating systems	All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.

  INTERFACES / CONNECTORS / CONTROLS
  Analog signal input	VGA x1 (max. 1920×1080 @60Hz)
  Digital signal input	HDMI x3 (v.2.0, max. 3840×2160 @60Hz, YUV444)
  	USB-C x1 (v.3.2 (Gen 1, 5Gbit), 3840×2160 @60Hz – RGB444 – (65W charging, Touch))
  Audio input	Mini jack x1
  Monitor control input	RS-232c x1
  	RJ45 (LAN) x1
  	IR x1
  Digital signal output	HDMI x1 (3840×2160 @60Hz)
  Audio output	S/PDIF (Optical) x1
  	Mini jack x1
  Speakers	2 x 16W (Front)
  HDCP	HDMI 1: 2.1, USB-C: 2.2
  USB ports	x5 (media playback / peripherals / storage – front side: 2x v.3.2 (Gen 1, 5Gbit), 1x USB-C v.3.2 (Gen 1, 5Gbit, 65W PD), right side: 2x v.3.2 (Gen 1, 5Gbit))
  RJ45 (LAN)	x2 (Auto switch for PC & Android, 1000MB)

  FEATURES
  Integrated software	iiWare 10 (Android OS 11) featuring iiyama DMS, Note, web browser, file manager, cloud drives, WPS office, iiyama Share and EShare for wireless connection with Windows/iOS/Android devices
  WiFi	Yes (WiFi 6 Module OWM002 – Dual WiFi Bandwidth: 2.4GHz/5GHz, WiFi Standard: IEEE 802.11 a/b/g/n/ac, Bluetooth Support: 2.1/3.0/4.2/5.0)
  Hardware	Quad-core A55 CPU, Mali G52 GPU, 4GB RAM, 32GB internal memory
  Extra	WiFi 6 Module (OWM002), Slot for optional OPS Slot PC, 4x Touch pen
  Kiosk mode	Yes
  Max. non-stop operating time	24/7
  Media playback	Yes
  Glass thickness	3mm
  Glass hardness	7H
  Housing (bezel)	Metal
  OSD key lock	Yes

  GENERAL
  OSD languages	EN, DE, FR, ES, IT, RU, CZ, NL, PL, SV, FI, DA, NB
  Control buttons	Power, Power Indicator, Remote Sensor, Light Sensor
  User controls	General settings (input, volume, backlight), audio settings (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode, color temp.), adjust settings (H-position, V-position, clock, phase, auto), settings (wireless & networks, personal, input & output, application, system)
  Blue light reducer	Yes
  Plug & Play	DDC2B
  Warranty	5 years (for details and eligible countries please check the Warranty section of our website)

  MECHANICAL
  Orientation	Landscape
  Fanless design	Yes
  VESA mounting	800 x 400mm
  Operation temperature range	0°C – 40°C
  Storage temperature range	-20°C – 60°C
  MTBF	50,000 hours (excluding backlight)

  ACCESSORIES INCLUDED
  Cables	Power, USB, HDMI
  Touch pen	x4
  Guides	Quick start guide, safety guide
  Other	WiFi 6 Module (OWM002), Mounting bracket for NUC, Mounting bracket for webcam
  Remote control	Yes (batteries included)

  POWER MANAGEMENT
  Power supply unit	Internal
  Power supply	AC 100 – 240V, 50/60Hz
  Power usage	120W typical, 0.5W standby, 0.3W off mode

  SUSTAINABILITY
  Regulations	CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH
  REACH SVHC	Above 0.1%: Lead

  DIMENSIONS / WEIGHT
  Product dimensions W x H x D	1709 x 1020 x 88mm
  Box dimensions W x H x D	1863 x 1140 x 225mm
  Weight (without box)	47kg
  Weight (with box)	60.6kg
  EAN code	4948570121847

  COMPATIBLE ACCESSORIES
  Other	OPS PC Slot

• Warranty	Product	Cover
  Visioncare	Desktop LCD products (Monitors)  (17″ – 43″)	3 years on-site UK warranty. (Upgrades to 5 years available)
  Touchcare	LCD touchscreen products	3 years repair and return. (Upgrades to on-site & 5 years available)
  LFD	Large Format Displays Standard Warranty	3 years collect and return (Upgrade to swap, installation & 5 years available) Download

  HOW TO ACTIVATE YOUR WARRANTY

  There is no need to pre-register your warranty, just follow the six simple steps below to activate your warranty should the need arise. First-class service is assured by our experienced engineers and customer service helpdesk.

  Step one – Check that all connections have been properly made.

  Step two – Check the set-up in the user manual. Wherever possible, please try to check your iiyama product with alternate equipment before contacting the iiyama customer service help desk.

  Step three – If the fault cannot be cured by the above means, call the iiyama customer service helpdesk on 01926 819 189. Please have ready to hand the following details: model number, serial number and date of purchase*. Or fill in the Service Request Form.

  Step four – Your fault will be registered and you will be issued with a returns number, which you must quote on all paperwork relating to the defective unit.

  Step five – Please retain any of your leads and manuals. Replacement/returned units will not include these sundry items.

  Step six – Please ensure your product is clean and presentable before packaging it in the original box for collection.

  * Proof of purchase may be required

  ON-SITE SWAP OUT

  PIONEERING CUSTOMER SERVICE.

• Document	Download Link
  User Manual	DOWNLOAD
  Technical Specification	DOWNLOAD
  Drawing	DOWNLOAD
