iiyama ProLite TE6504MIS-B3AG 65″ 4K UHD LCD Interactive Touch Screen Display
iiyama ProLite TE6504MIS-B3AG
65″ 4K UHD LCD Interactive Touch Screen Display
Captivate your audience with the ProLite TE6504MIS-B3AG; a perfect solution for educational and corporate use.
- Description
- Specifications
- Warranty
- Downloads
-
PROLITE TE6504MIS-B3AG
65″ Interactive 4K UHD LCD Touchscreen with integrated annotation software
Captivate your audience with the ProLite TE6504MIS-B3AG; a perfect solution for educational and corporate use. This 65’’ PureTouch-IR 20-point touchscreen with iiWare 9.0 (Android OS 9.0) is featuring Note, web browser, file manager, cloud drives, WPS office and ScreenSharePro. It comes with dual function touch pens, allowing users to annotate easily in 4K on files and on-screen content which can be saved directly to a USB device, 32GB internal memory or a selected cloud drive. The display supports playback of presentations, high-resolution video and almost any other type of content. Now with additional USB-C connection to support the latest in video, audio and touch signal via a single port and even charge your device with 65W power delivery.
The high-quality commercial IPS LCD screen with a 4K UHD resolution (3840×2160), 400cd/m2 and a contrast ratio of 1200:1 provide vibrant, detailed and high-quality images from anywhere in the class or meeting room. The anti-glare coating drastically reduces ambient reflection in high-brightness environments without compromising the sharpness and clarity of the image. The screen has a 24/7 non-stop operating time and is equipped with an all-metal bezel, 3mm thick hardened glass to ensure robust durability in high-use environments such as classrooms or meeting rooms.
Share, stream and edit content from any device directly on screen and transform your team meetings or lessons into an easy, fast and seamless interactive session with the included WiFi module (OWM002), ScreenSharePro and EShare app.
PURETOUCH IR
PureTouch-IR from iiyama delivers 1mm touch accuracy for the smoothest and fastest annotation.
IIWARE
iiWare 9.0 features Note, Browser, Cloud Drive and the option for you to sideload relevant apps you require for your organisation.
IIYAMA SHARE
Connect up to 9 devices and easily share, stream and edit content from your device to your interactive display and vice versa, back to your laptop, tablet or phone. iiyama Share supports AirPlay, Chromecast and Miracast.
SECURITY
Utilise Screen lock and USB passcode protection to ensure user security and the new Clean app will clear all data and passwords used.
AG COATING
The anti-glare coating is used in professional-grade displays to help avoid issues with reflections and external light sources affecting colour reproduction, contrast and sharpness. It also makes the screen less susceptible to dust, grease and dirt marks.
4K
UHD resolution (3840×2160), better known as 4K, offers a gigantic viewable area with 4 times more information and work space than a Full HD screen. Due to the high DPI (dots per inch), it displays an incredibly sharp and crisp image. -
Feature Description Design Thin bezel Diagonal 65″, 163.9cm Panel IPS Touch Glass AG coated glass, zero air-gap Native resolution 3840 x 2160 (8.3 megapixel 4K UHD) Aspect ratio 16:9 Panel brightness 400 cd/m² Light transmittance 88% Static contrast 1200:1 Dynamic contrast 3500:1 Response time (GTG) 8ms Viewing zone Horizontal/Vertical: 178°/178°, Right/Left: 89°/89°, Up/Down: 89°/89° Colour support 1.07B 8bit+FRC Horizontal Sync 30 – 135kHz Viewable area W x H 1429 x 804mm, 56.3 x 31.7″ Bezel width (sides, top, bottom) 14mm, 14mm, 43mm Pixel pitch 0.372mm Bezel color and finish Black, matte Touch technology PureTouch-IR Touch points 20, 10pt writing (HID, only with supported OS) Touch accuracy ± 1mm Touch method Stylus, finger, glove Touch interface USB Supported operating systems All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. INTERFACES / CONNECTORS / CONTROLS Analog signal input VGA x1 (max. 1920×1080 @60Hz) Digital signal input HDMI x3 (v.2.0, max. 3840×2160 @60Hz, YUV444) USB-C x1 (3.1, 3840×2160 @60Hz – RGB444 – (65W charging, Touch)) Audio input Mini jack x1 Monitor control input RS-232c x1 (DSUB 9pin) RJ45 (LAN) x1 (LAN Control) IR x1 Audio output S/PDIF (Optical) x1 Mini jack x1 Speakers 2 x 16W HDCP v.2.2 USB ports x6 (media playback / peripherals / storage – front side: 2x v.3.0, right side: 2x v.3.0, 1x v.2.0, 1x USB-C v.3.1) RJ45 (LAN) x2 (Auto switch for PC & Android, 1000MB) FEATURES Integrated software iiWare 9.0 (Android OS 9.0) featuring Note, web browser, file manager, cloud drives, WPS office, BytelloShare, and EShare for wireless connection with Windows/iOS/Android devices WiFi Yes (WiFi Module OWM002 – Dual WiFi Bandwidth: 2.4GHz/5GHz, WiFi Standard: IIEEE 802.11 a/b/g/n/ac, Bluetooth Support: 2.1/3.0/4.2/5.0) Hardware Quad-core A73 CPU, Mali G52 GPU, 4GB RAM, 32GB internal memory Extra WiFi Module (OWM002), Slot for optional OPS Slot PC, 4x Touch pen Kiosk mode Yes Max. non-stop operating time 24/7 Media playback Yes Glass thickness 3mm Glass hardness 7H Housing (bezel) Metal OSD key lock Yes OSD languages EN, DE, FR, ES, IT, RU, CZ, NL, PL Control buttons Power, Power Indicator, Remote Sensor, Light Sensor User controls General settings (input, volume, backlight), audio settings (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode, color temp.), adjust settings (H-position, V-position, clock, phase, auto), settings (wireless & networks, personal, input & output, application, system) Blue light reducer Yes Plug&Play DDC2B Warranty 5 years (for details and eligible countries please check the Warranty section of our website) Orientation Landscape Fanless design Yes VESA mounting 600 x 400mm Operation temperature range 0°C – 40°C Storage temperature range -20°C – 60°C MTBF 50,000 hours (excluding backlight) ACCESSORIES INCLUDED Cables Power, USB, HDMI Touch pen x4 (Dual function tips) Guides Quick start guide, safety guide Other WiFi Module (OWM002), Mounting bracket for NUC, Mounting bracket for webcam, Remote control (batteries included) POWER MANAGEMENT Power supply unit Internal Power supply AC 100 – 240V, 50/60Hz Power usage 173W typical, 0.5W standby, 0.3W off mode SUSTAINABILITY Regulations CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH (RoHS) REACH SVHC Above 0.1%: Lead Product dimensions W x H x D 1488 x 897 x 86mm Box dimensions W x H x D 1628 x 208 x 1005mm Pallet volume 5pcs Weight (without box) 37kg Weight (with box) 47.6kg EAN code 4948570120420 -
Warranty Product Cover Visioncare Desktop LCD products (Monitors) (17″ – 43″) 3 years on-site UK warranty. (Upgrades to 5 years available) Touchcare LCD touchscreen products 3 years repair and return. (Upgrades to on-site & 5 years available) LFD Large Format Displays Standard Warranty 3 years collect and return (Upgrade to swap, installation & 5 years available) Download
HOW TO ACTIVATE YOUR WARRANTY
There is no need to pre-register your warranty, just follow the six simple steps below to activate your warranty should the need arise. First-class service is assured by our experienced engineers and customer service helpdesk.
Step one – Check that all connections have been properly made.
Step two – Check the set-up in the user manual. Wherever possible, please try to check your iiyama product with alternate equipment before contacting the iiyama customer service help desk.
Step three – If the fault cannot be cured by the above means, call the iiyama customer service helpdesk on 01926 819 189. Please have ready to hand the following details: model number, serial number and date of purchase*. Or fill in the Service Request Form.
Step four – Your fault will be registered and you will be issued with a returns number, which you must quote on all paperwork relating to the defective unit.
Step five – Please retain any of your leads and manuals. Replacement/returned units will not include these sundry items.
Step six – Please ensure your product is clean and presentable before packaging it in the original box for collection.
* Proof of purchase may be required
ON-SITE SWAP OUT
PIONEERING CUSTOMER SERVICE.
-
Document Download Link User Manual DOWNLOAD Technical Specification DOWNLOAD Drawing DOWNLOAD
