iiyama ProLite T2736MSC-B1 27″ PCAP Touch Screen Monitor

iiyama ProLite T2736MSC-B1 27″ PCAP Touch Screen Monitor

• Description
• Specifications
• Warranty

• 27″ 10 point touch monitor with edge to edge glass and AMVA panel

  With its Full HD (1920×1080) resolution and accurate Projective Capacitive 10 point touch technology, the ProLite T2736MSC delivers seamless and accurate touch response. The AMVA panel technology guarantees high performance with excellent colour reproduction and high contrast, making it an excellent choice for a vast array of demanding interactive applications. The flexible stand can be positioned at several angles creating a comfortable and ergonomic user experience.

  • TOUCH TECHNOLOGY – CAPACITIVE

    This technology uses a sensor-grid of micro-fine wires integrated into the glass that covers the screen. Touch is detected because electrical characteristics of the sensor grid change when human finger is placed on the glass. Thanks to the glass overlay this technology is highly durable, and the touch function remains unaffected even if the glass is scratched. It offers perfect picture performance and will work with human finger (also latex gloved) and stylus-pen.

  • SCRATCH RESISTANCE

    Scratch resistance is essential for touch solutions used in public places and schools. This is achieved thanks to a glass overlay covering the screen. It guarantees high durability of the touch function and even more importantly the touch function remains unaffected even if the glass is scratched.

  • SPEAKERS

    This LED monitor is equipped with two stereo speakers.

  • OVERDRIVE ON / OFF

    When very fast graphics are displayed your monitor can sometimes get blurry. Turning on the OverDrive feature will eliminate that.

  • AMVA

    AMVA technology offers higher contrast, darker blacks and much better viewing angles than standard TN technology. The screen will look good no matter what angle you look at it.

• DISPLAY CHARACTERISTICS

  Design	Edge to edge glass
  Diagonal	27″, 68.6cm
  Panel	AMVA LED
  Native resolution	1920 x 1080 @60Hz (2.1 megapixel Full HD)
  Aspect ratio	16:9
  Panel brightness	300 cd/m²
  Brightness	255 cd/m² with touch
  Light transmittance	85%
  Static contrast	3000:1
  Advanced contrast	12M:1
  Response time (GTG)	4ms
  Viewing zone	horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
  Colour support	16.7mln
  Horizontal Sync	30 – 80kHz
  Viewable area W x H	597.6 x 336.15mm, 23.5 x 13.2″
  Pixel pitch	0.311mm
  Bezel colour and finish	black, matte

  TOUCH

  Touch technology	projective capacitive
  Touch points	10 (HID, only with supported OS)
  Touch method	stylus, finger, glove (latex)
  Touch interface	USB
  Supported operating systems	All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
  Palm rejection	yes

  INTERFACES / CONNECTORS / CONTROLS

  Analog signal input	VGA x1
  Digital signal input	HDMI x1 DisplayPort x1
  Audio output	Speakers 2 x 2W
  HDCP	yes
  USB HUB	x4 (v.3.0)

  FEATURES

  Glass thickness	2.2mm
  Glass hardness	7H
  OSD key lock	yes

  GENERAL

  OSD languages	EN, DE, FR, ES, IT, PT, RU, JP, NL, PL
  Control buttons	Scroll up / Audio Adjust / Blue Light Reducer, Scroll down / ECO, Auto, Menu, Power
  User controls	Picture adjust (brightness, contrast, ECO, i-Style colour, ACR), geometry (pixel clock, phase, H.position, V.position, aspect), colour settings (gamma, colour temp), OSD (H.position, V. position, OSD time, language), extra (reset, signal select, audio input, opening logo, LED, OD, information, volume, auto adjust)
  Convenience	Kensington-lock™ prepared
  Blue light reducer	yes
  Plug&Play	DDC2B

  MECHANICAL

  Tilt angle	73° up; 3° down
  VESA mounting	100 x 100mm

  ACCESSORIES INCLUDED

  Cables	power (1.8m), VGA (1.8m), USB (1.8m), HDMI (1.8m)
  Guides	quick start guide, safety guide

  POWER MANAGEMENT

  Power supply unit	internal
  Power supply	AC 100 – 240V, 50/60Hz
  Power usage	28W typical, 0.5W stand by, 0.5W off mode

  SUSTAINABILITY

  Regulations	CE, TÜV-Bauart, RoHS support, ErP, WEEE, CU, REACH
  Energy efficiency class (Regulation (EU) 2017/1369)	F
  REACH SVHC	above 0.1%: Lead

  DIMENSIONS / WEIGHT

  Product dimensions W x H x D	659.5 x 444 x 220.5mm
  Weight (without box)	7.4kg
  EAN code	4948570116423

  RELATED INFORMATION

  Product series

  ProLite T2236MSC-B2, ProLite T2336MSC-B2, ProLite T2336MSC-B2AG, ProLite T2236MSC-B2AG

• Warranty	Product	Cover
  Visioncare	Desktop LCD products (Monitors)  (17″ – 43″)	3 years on-site UK warranty. (Upgrades to 5 years available)
  Touchcare	LCD touchscreen products	3 years repair and return. (Upgrades to on-site & 5 years available)
  LFD	Large Format Displays Standard Warranty	3 years collect and return (Upgrade to swap, installation & 5 years available) Download

  HOW TO ACTIVATE YOUR WARRANTY

  There is no need to pre-register your warranty, just follow the six simple steps below to activate your warranty should the need arise. First-class service is assured by our experienced engineers and customer service helpdesk.

  Step one – Check that all connections have been properly made.

  Step two – Check the set-up in the user manual. Wherever possible, please try to check your iiyama product with alternate equipment before contacting the iiyama customer service help desk.

  Step three – If the fault cannot be cured by the above means, call the iiyama customer service helpdesk on 01926 819 189. Please have ready to hand the following details: model number, serial number and date of purchase*. Or fill in the Service Request Form.

  Step four – Your fault will be registered and you will be issued with a returns number, which you must quote on all paperwork relating to the defective unit.

  Step five – Please retain any of your leads and manuals. Replacement/returned units will not include these sundry items.

  Step six – Please ensure your product is clean and presentable before packaging it in the original box for collection.

  * Proof of purchase may be required
