iiyama ProLite T1731SR-B1S 17” Touchscreen Monitor with 5-wire Resistive Touch Technology

• Description
• Specifications
• Warranty
• Downloads

• iiyama ProLite T1731SR-B1S 17” Touchscreen Monitor with 5-wire Resistive Touch Technology

  The T1731SR-B1S is based on 5 wire resistive touch technology. The price / performance ratio is ideal for the budget conscious user while quality and performance are certainly not compromised. The display inputs include both analogue and digital (HDMI and DisplayPort) with touchscreen connectivity via USB offering great flexibility. The flexible stand can be positioned at several angels creating a comfortable and ergonomic user experience and the integrated cable management system hides all the cables and electrical wires giving a neat and cable-free workspace. The T1731SR-B1S can be used in a variety of environments, especially recommended for shops, restaurants and industrial purposes.

  TOUCH TECHNOLOGY – RESISTIVE
  5-wire resistive touchscreens are very durable and can be used in a variety of environments. They are especially recommended for shops, restaurants and industrial purposes.

  IP54
  The IP Code classifies how resistant a device is to foreign objects and moisture. IP54 means that the monitor will operate in dusty conditions, and will resist splashing water.

  SPEAKERS
  This LED monitor is equipped with two stereo speakers.

  VESA
  VESA mount compliance means you can easily mount the display to any mounting that complies with the VESA standard.

• CATEGORY	SPECIFICATIONS
  DISPLAY CHARACTERISTICS
  Diagonal	17″, 43cm
  Panel	TN
  Native resolution	1280 x 1024 (1.3 megapixel)
  Aspect ratio	5:4
  Panel brightness	250 cd/m²
  Brightness	200 cd/m² with touch
  Light transmittance	80%
  Static contrast	1000:1 with touch
  Response time (BTB)	5ms
  Viewing zone	Horizontal/vertical: 170°/160°, right/left: 85°/85°, up/down: 80°/80°
  Colour support	16.7 million
  Horizontal Sync	31.5 – 80kHz
  Viewable area W x H	338 x 270mm, 13.3 x 10.6″
  Pixel pitch	0.264mm
  Bezel colour and finish	Black, matte
  TOUCH
  Touch technology	Serial resistive
  Touch points	1
  Touch method	Stylus, finger, glove
  Touch interface	USB
  Supported operating systems	All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
  INTERFACES / CONNECTORS / CONTROLS
  Analog signal input	VGA x1
  Digital signal input	HDMI x1, DisplayPort x1
  Audio output	Speakers 2 x 1W
  HDCP	Yes
  FEATURES
  Water and dust protection	IP54 (front)
  OSD key lock	Yes
  GENERAL
  OSD languages	EN, DE, FR, ES, IT, CN, JP
  Control buttons	Menu, Scroll up/Brightness, Scroll down/Mute, Select, Power
  User controls	Contrast, brightness, lock mode (power, OSD), auto adjust, OSD, H. position, V. position, H-size, fine, OSD H. position, OSD V. position, OSD timeout, reset, input select, OSD language, colour temperature, volume, mute
  Convenience	Kensington-lock™ prepared
  Plug&Play	DDC2B
  MECHANICAL
  Tilt angle	90° up; 5° down
  VESA mounting	100 x 100mm
  Cable management system	Yes
  ACCESSORIES INCLUDED
  Cables	Power, USB, HDMI, Audio, DP
  Guides	Quick start guide, safety guide
  Cable cover	Yes
  POWER MANAGEMENT
  Power supply unit	Internal
  Power supply	AC 100 – 240V, 50/60Hz
  Power usage	20W typical, 1.5W standby, 0.3W off mode
  SUSTAINABILITY
  Regulations	CE, EAC, RoHS support, ErP, WEEE, cULus, VCCI, REACH, UKCA
  Energy efficiency class	E
  REACH SVHC	Above 0.1%: Lead
  DIMENSIONS / WEIGHT
  Product dimensions W x H x D	387 x 378 x 239.5mm
  Weight (without box)	5.4kg
  EAN code	4948570122127

• Warranty	Product	Cover
  Visioncare	Desktop LCD products (Monitors)  (17″ – 43″)	3 years on-site UK warranty. (Upgrades to 5 years available)
  Touchcare	LCD touchscreen products	3 years repair and return. (Upgrades to on-site & 5 years available)
  LFD	Large Format Displays Standard Warranty	3 years collect and return (Upgrade to swap, installation & 5 years available) Download

  HOW TO ACTIVATE YOUR WARRANTY

  There is no need to pre-register your warranty, just follow the six simple steps below to activate your warranty should the need arise. First-class service is assured by our experienced engineers and customer service helpdesk.

  Step one – Check that all connections have been properly made.

  Step two – Check the set-up in the user manual. Wherever possible, please try to check your iiyama product with alternate equipment before contacting the iiyama customer service help desk.

  Step three – If the fault cannot be cured by the above means, call the iiyama customer service helpdesk on 01926 819 189. Please have ready to hand the following details: model number, serial number and date of purchase*. Or fill in the Service Request Form.

  Step four – Your fault will be registered and you will be issued with a returns number, which you must quote on all paperwork relating to the defective unit.

  Step five – Please retain any of your leads and manuals. Replacement/returned units will not include these sundry items.

  Step six – Please ensure your product is clean and presentable before packaging it in the original box for collection.

  * Proof of purchase may be required

  ON-SITE SWAP OUT

  PIONEERING CUSTOMER SERVICE.

• Description	Downloads
  User manual	Download
  Technical specification	Download
  Drawing	Download
  UK Energy Label	Download
