iiyama ProLite LH8664UHS-B2AG 86″ 4K Ultra HD Digital Signage Display
Elevate your visual communication with the LH8664UHS-B2AG and unlock the new possibilities for your business. This 500cd/m² high brightness display is a powerful business tool that takes your marketing and communication efforts to the next level. With its Android 11 OS, iiSignage² (Content Management Software), Signal FailOver and EShare features, this display offers a straightforward user experience, making content creation, management, and sharing a breeze. WiFi enabled, the display is ready for remote content delivery using your network or you can choose to utilise LAN control.
Its versatile orientation, sleek design, and 24/7 reliability ensure it seamlessly integrates into any business environment. Whether it’s used in retail, corporate, hospitality, or educational settings, the LH8664UHS-B2AG will undoubtedly captivate your audience and leave a lasting impression.
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.
Signal FailOver
FailOver is a feature which automatically detects input sources. When there is no signal on the default input it will automatically switch to the next available input. FailOver allows customers to prioritize a number of inputs (incl. Browser, Media Player and Custom) and ensures your content is always actively displayed, assuring active content at all times.
4K
UHD resolution (3840×2160), better known as 4K, offers a gigantic viewable area with 4 times more information and work space than a Full HD screen. Due to the high DPI (dots per inch), it displays an incredibly sharp and crisp image.
Media player
Play your favourite music and show your most beautiful videos, photos and images directly on screen from a flash drive or internal memory with the built-in media player. -
Category Details Display Characteristics Design 3-side borderless Diagonal 85.6″, 217.4cm Panel IPS, AG coated glass, matte finish, haze 25% Native Resolution 3840 x 2160 @60Hz (8.3 MegaPixels 4K UHD) Aspect Ratio 16:9 Panel Brightness 500 cd/m² Static Contrast 1200:1 Response Time (GTG) 8ms Viewing Zone 178°/178°, 89°/89° Colour Support 1.07G (8 Bits+FRC) (NTSC 72%) Horizontal Sync 28 – 160kHz Viewable Area W x H 1895 x 1066mm, 74.6 x 41.9″ Pixel Pitch 0.493mm Bezel Colour and Finish Black, matte Interfaces / Controls Digital Signal Input HDMI x3 (v.2.0, max. 3840×2160 @60Hz) Audio Input Mini jack x1 (3.5mm) Monitor Control Input RS-232c x1, RJ45 x1, IR x1 Audio Output Mini jack x1 Speakers 2 x 16W HDCP v.1.4 & 2.2 USB Ports x2 (v.2.0) Features Operating System Android 11 OS, iiSignage², FailOver, EShare WiFi Built-in, 2.4G/ 5G Hardware CPU: A53*4, GPU: G52 MP2, RAM: 2GB, ROM: 16GB Max. Non-stop Operating Time 24/7 Anti Image Retention Yes Media Playback Yes Mechanical Orientation Landscape, portrait Fanless Design Yes VESA Mounting 800 x 600mm Operation Temperature Range 0°C – 40°C Storage Temperature Range -20°C – 60°C MTBF 50,000 hours (excluding backlight) Accessories Included Power, HDMI, RS-232c cables; quick start guide, safety guide; wall mount kit (bracket, screws, screw anchors) Power Management Internal power supply; AC 100 – 240V, 50/60Hz; 145W typical usage Sustainability CB, CE, TÜV-Bauart, EAC, RoHS, ErP, WEEE, REACH Energy Efficiency Class F Dimensions / Weight Product: 1938 x 1109 x 79.5mm; Box: 2125 x 1275 x 275mm; Weight: 47.6 kg EAN Code 4948570124916 -
