iiyama OPC51103BC Intel® i5 OPS Slot PC with Windows® 10

• Description
• Specifications
• Downloads

• iiyama OPC51103BC Intel® i5 OPS slot PC with Windows® 10

  This mini OPS PC with Intel® Core™ i5 inside turns your iiyama interactive large format display into a stand-alone solution. It comes equipped with a powerful Intel® processor with integrated Ultra HD graphics and a fast SSD drive. No hassle with cables and having to mount a PC at the back of the monitor or on a floor lift. Simply slide in the iiyama OPS slot PC and get started right away.


• Type	OPS slot PC
  CPU	Intel® Core™ i5-1135G7, TPM 2.0 (Trusted Platform Module)
  RAM	8GB DDR4
  SSD	256GB M.2
  Graphics	Integrated Intel® Iris® Xe
  Sound card	Integrated High Definition Audio Stereo
  Network	10/100/1000M Adapter
  WiFi	802.11a/b/g/n/ac (M.2 2230)
  Bluetooth	4.2
  Operating system	Win 10 IoT Enterprise 64-bit, Windows 11 compatible
  LAN (RJ45)	x1
  USB	3.0 x4, 3.2 (Type C) x1
  HDMI Out	x1
  Headphone connector	Yes
  Microphone In	x1
  Power usage	65W typical, 1.5W stand by
  Product dimensions (W x H x D)	133.5 x 30 x 202mm
  Box dimensions (W x H x D)	192 x 72 x 267mm
  Weight (without box)	0.75kg
  Weight (with box)	0.97kg
  EAN code	4948570032822
  Operation temperature range	0°C – 45°C
  Operation humidity	10% – 90%
  Storage temperature range	-20°C – 60°C
  Storage humidity	10% – 90%
