iiyama G-Master GCB4580DQSN-B1 45’’ 0.8ms 165 Hz Monitor

• Description
• Specifications
• Warranty
• Downloads

• iiyama G-Master GCB4580DQSN-B1 45’’ 0.8ms 165 Hz Monitor

  DQHD
  Ultra-wide 32:9 monitors boasting DQHD 5120 x 1440 resolution, also recognized as Dual QHD, guarantee razor-sharp images that bring your games to life. These monitors empower you to organize your gaming setup for an unparalleled gaming experience. You won’t miss a single detail!

  165HZ & 0.8MS MPRT
  With 165Hz refresh rate and 0.8ms MPRT response time the force is with you! Make split second decisions and be sure the image on the screen is always sharp and smooth.

  CURVED DESIGN 1500R
  The 1500R curvature of the screen guarantees a realistic and comfortable viewing experience allowing you to really immerse yourself in the game.

  VA PANEL TECHNOLOGY
  Guaranteeing excellent contrast ratio making all the nuances between the light and dark colours clearly visible.

• Feature	Details
  Diagonal	45″, 113cm
  Panel	VA
  Curved	1500R
  Native resolution	5120 x 1440 @165Hz (7.4 megapixel DQHD)
  Aspect ratio	32:9
  Panel brightness	450 cd/m²
  Static contrast	3000:1
  Advanced contrast	80M:1
  Response time (MPRT)	0.8ms
  Viewing zone	Horizontal/vertical: 178°/178°, Right/left: 89°/89°, Up/down: 89°/89°
  Horizontal Sync	30 – 260kHz
  Viewable area W x H	1087.5 x 305.9mm, 42.8 x 12.0″
  Pixel pitch	0.212mm
  Colour	Matte, Black
  Signal Input	HDMI x2, DisplayPort x1
  USB HUB	x3 (v.3.2 (Gen 1, 5Gbit; DC5V, 900mA))
  USB-C DOCK	x1 (Power delivery 90W, LAN, USB v. 3.2 (Gen 1, 5Gbit))
  HDCP	Yes
  Headphone Connector	Yes
  RJ45 (LAN)	x1
  KVM Switch	Yes
  Blue Light Reducer	Yes
  Flicker Free	Yes
  FreeSync Support	Yes
  Extra	i-Style Mode
  HDR	HDR400
  OSD Languages	EN, DE, FR, IT, RU, JP, CZ, NL, PL
  Control Buttons	Navigation button: Menu/Execution, Down (i-Style Colour), Up (Input Select), Right (Volume), Left (Night Mode), Power
  User Controls	Various controls for picture, colour, input, PBP, audio, i-Style Mode, language, OSD settings, setup menu, etc.
  Speakers	2 x 3W
  Convenience	Kensington-lock™ prepared, DDC/CI, DDC2B, Mac OSX
  Display Position Adjustments	Height, Tilt
  Height Adjustment	130mm
  Tilt Angle	20° up; 3° down
  VESA Mounting	100 x 100mm, 200 x 100mm
  Operation Temperature Range	5°C – 35°C
  Accessories Included	Cables (power, USB, HDMI, DP), Quick start guide, Safety guide
  Power Management	Internal Power Supply, AC 100 – 240V, 50/60Hz, Power usage: 37W default, 0.5W standby, 0.3W off mode
  Sustainability	CE, TÜV-Bauart, PSE, RoHS support, ErP, WEEE, VCCI, REACH, UKCA
  Energy Efficiency Class	F
  REACH SVHC	Above 0.1%: Lead
  Dimensions / Weight	Product: 1090 x 409(539) x 275mm, Weight (without box): 11.2kg
  EAN Code	4948570122264

• 3 Years Warranty

• Description	Downloads
  User manual	Download
  Technical specification	Download
  Drawing	Download
  EU Energy Label	Download
  UK Energy Label	Download

•
