Icron Advanced 4-Port USB USB 3.1, 2.0, 1.1, 100 meters CAT 6a/7 Point-to-Point Extender System | 00-00453
Icron’s Raven 3104 PRO USB extender pushes the boundaries of USB extension.
The USB 3-2-1 extender offers you a 4-port USB 3.2 over CAT6a (or better cabling) solution that can extend USB up to 100m. As an industry first, this extender is backward compatible with USB 2.0 and 1.1 devices for simultaneous use at full 5 Gbps bandwidth.
The enhanced Icron Raven 3104 Pro is an ideal USB extension solution for USB Camera, Video, and Video Capture Devices. The Raven supports Isochronous USB 3 Transaction and is certified for Google Hangouts Meet as well as other major brands like AVer, Logitech, and Lumens.
Additionally, the Raven 3104 includes Ethernet pass-through for connecting to your network-enabled devices, or for use with your existing infrastructure without losing LAN connectivity. Making this suitable for remote storage, security, and monitoring, and video matrix systems.
With Icron’s patented technology, ExtremeUSB-C, the USB 3-2-1 Raven 3104 PRO provides transparent USB extension, true plug-and-play functionality, and works with all major operating systems (Windows, MacOS, and Linux).
-
Specification Details USB Type USB 3.0, 2.0, 1.1 Transmission Media Cat X Number of USB Ports 4 – Ports Max. Distance Up to 100m Power Adapter Location LEX and REX USB Throughput 5 Gbps Power Requirements 24V DC, 1A USB Hub/Tier Usage 2 hubs total, 1 on LEX and 1 on REX -
