i3 Technologies 10010164 I3 COMPUTER 510 OPS I5-10210U 16GB 256GB W10P

i3 Technologies 10010164 I3 COMPUTER 510 OPS I5-10210U 16GB 256GB W10P

• Description
• Specifications

• Computer for the i3TOUCH
  i3COMPUTER
  The i3COMPUTER is a compact mini-computer that is available with different processors to accommodate different budgets and work styles. It also comes in an OPS format for seamless integration with our touchscreen solutions.

  Integrated display solution
  The iSCOMPUTER OPS is a compact mini-computer that doesn’t have any cables. It can be seamlessly plugged into the display. It automatically turns on and off with the display, so there’s no need to turn it on separately.

  Something for everyone
  The i3COMPUTER is of high quality and very stable, ideal for permanent use with different applications. It’s available with different processors to accommodate different budgets and work styles.

  The OPS Standard
  Our interactive display range (i3TOUCH) is equipped with an OPS (Open Pluggable Specification) slot at the back of the display. Our i3TOUCH products have been thoroughly tested for compatibility with i3-Technologies’ OPS products (i.e., the i3COMPUTER OPS).

  The goal of the OPS solution is to allow a wide variety of OPS computers to be slotted into an i3TOUCH thanks to the standardized 80-pins interface and the fixed dimensions of the slot.

  Deviations from the OPS Standard
  Many manufacturers offer OPS solutions, which can have distinct specifications in terms of chipsets and functionality. Some OPSs are developed for specific purposes and are therefore less suited to being combined with an (i3TOUCH) interactive display. In theory, all OPS solutions should be compliant with the Intel® OPS specifications, and i3TOUCH displays are developed to match these specifications as close as possible. With the aim of being able to work with a broad range of OPS brands. However, in practice, we see that some OPS manufacturers deviate from the OPS standard and make modifications to the OPS (like dimensions, connectors, and interface protocols) and adjust the core operations of the OPS unit for certain purposes, which can cause compatibility issues, resulting in malfunctions when being used in an i3TOUCH display.

  Guaranteed Compatibility
  Since OPS manufacturers can change the specifications of their units without notice and the fact that those specs can have regional differences, i3-Technologies cannot provide any recommendations about the compatibility of i3TOUCH units with third-party OPS solutions.

  i3-Technologies can also not make suggestions about compatibility between older and newer generations of the i3COMPUTER OPS and i3TOUCH. We recommend you follow the recommendations of the i3-Technologies company and its representatives or one of our accredited resellers.

• Physical Characteristics
  Form Factor	Module

  Power Description
  Maximum Power Consumption	60 W

  Software
  Operating System	Windows 10 Pro

  Storage
  Total Hard Drive Capacity	256 GB

  Memory
  Standard Memory	16 GB
  Memory Technology	DDR4 SDRAM

  Processor & Chipset
  Processor Type	Core i5
  Processor Model	i5-10210U
  Processor Manufacturer	Intel
  Chipset Manufacturer	Intel

  Interfaces/Ports
  HDMI	Yes
  Network (RJ-45)	Yes
  Total Number of USB Ports	5
  Number of USB 2.0 Ports	1
  Number of USB 3.0 Ports	1

  Network & Communication
  Bluetooth	Yes
  Wireless LAN	Yes
  Wireless LAN Standard	IEEE 802.11ax
  Bluetooth Standard	Bluetooth 5.1
  Ethernet Technology	Gigabit Ethernet

  General Information
  Product Type	Single Board Computer
  Manufacturer Part Number	10010164
  Manufacturer Website Address	i3 Technologies Website
  Manufacturer	i3 Technologies
  Product Model	510 OPS
  Product Name	i3COMPUTER 510 OPS Single Board Computer
  Product Line	i3COMPUTER
  Product Series	10
  Brand Name	i3
