HPE ProLiant DL380 Gen10 Rack (2U) Intel Xeon Silver 4210R 2.4 GHz 32 GB DDR4-SDRAM 800 W Server | P56961-421
- Description
- Specifications
-
HPE ProLiant DL380 Gen10 Rack (2U) Intel Xeon Silver 4210R 2.4 GHz 32 GB DDR4-SDRAM 800 W Server
The HPE ProLiant DL380 Gen10 server delivers the latest in security, performance and expandability, backed by a comprehensive warranty. Standardize on the industry’s most trusted compute platform. The HPE ProLiant DL380 Gen10 server is securely designed to reduce costs and complexity, featuring the First and Second Generation Intel® Xeon® Processor Scalable Family with up to a 60% performance gain1 and 27% increase in cores2, plus the HPE 2933 MT/s DDR4 SmartMemory supporting 3.0 TB. It supports 12 Gb/s SAS, and up to 20 NVMe drive plus a broad range of compute options. Intel® Optane™ persistent memory 100 series for HPE offers unprecedented levels of performance for databases and analytic workloads. Run everything from the most basic to mission-critical applications and deploy with confidence.
HPE ProLiant DL380 Gen10 server with one Intel® Xeon® Silver 4210R processor, 32 GB dual rank memory, MR416i-p storage controller and smart storage battery, 8 small form factor drive bays, one embedded 4 x 1GbE Network Adapter, SFF Easy Install Rail Kit, Cable Management Arm Kit, 800W power supply, and 3/3/3 warranty
Defend applications and data before your server is built with the new HPE Trusted Supply Chain offering.
Supporting additional second generation Intel® Xeon® Scalable processor family offerings.
Increased Single-Width GPU Density with up to 7 NVIDIA Tesla T4 16GB Computational Accelerators or 7 Xilinx Alveo U50 Accelerators supported in a standard-depth 2U rack form factor
Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
Intel® Optane™ persistent memory 100 series for HPE offers the flexibility to deploy as dense memory or fast storage and enables per-socket memory capacity of up to 3.0 TB.3
iLO 5 security enhancements: Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor. HPE InfoSight provides cloud-based analytics to predict and prevent issues proactively.
Defend Applications and Data Before Your Server is Built with HPE Trusted Supply Chain
A new first line of defense against cyber-attackers with select servers built to the world’s toughest security standards in secured facilities, bringing together security, processes and people to deliver protection for your most sensitive applications and data even before your server is built.
Built in secure HPE facilities to the most stringent Country of Origin USA and conformance requirements, HPE Trusted Supply Chain servers are inspected to be free from malicious microcode and counterfeit parts, safeguarding it against cyber-exploits throughout its life cycle.
With hardened security built in, HPE Trusted Supply Chain hardens the protections designed into select HPE products with unrivaled supply chain visibility and standards compliance providing a 360-degree view and mitigation plan for current and emerging cyber-threats.
Allied to ensure authenticity, HPE Trusted Supply Chain doubles down on your protection with vetted HPE employees assigned to the product build to manage the product manufacturing process that adheres to the strictest sourcing, inspection and traceability standards
World-Class Performance featuring Enhanced Compute Density
The ProLiant DL380 now features significantly enhanced GPU density, expanding support from five to seven Full-Height, Half-Length, Single-Width Accelerators/GPUs; or up to six in a balanced configuration with additional PCIe expansion via the tertiary riser.
Leveraging HPE’s most popular 2U rackmount server, fitting standard depth racks, customers can benefit from one of the densest Accelerator/GPU platforms with an extensive set of Accelerator options, enabling diverse cloud workload performance and optimization of AI and deep learning experiences.
Supported on the ProLiant DL380, the NVIDIA T4 GPU is ideal for Deep learning, Inferencing, Machine Learning, HPC, Rendering, VDI, Virtual Workstations and combinations thereof for mixed workloads – maximizing utilization of data center resources and lowering TCO.
Flexible Design Making Your Investment Expand As Your Business Needs Grow
The HPE ProLiant DL380 Gen10 server has an adaptable chassis, including new Hewlett Packard Enterprise modular drive bay configuration options with up to 30 SFF, up to 19 LFF or up to 20 NVMe drive options along with support for up to three double wide GPU options.
Adapting and growing to changing business needs, Networking Choice (NC) server models provide flexibility in the primary networking choice while Embedded LOM server models offer an embedded 4x1GbE by default; both provide network options (1GbE to 100GbE) via HPE FlexibleLOM or PCIe standup adapters.
HPE Persistent Memory works with DRAM to provide fast, high capacity, cost effective memory and storage to transform big data workloads and analytics by enabling data to be stored, moved, and processed quickly.
In conjunction with the embedded SATA HPE Dynamic Smart Array S100i Controller for boot, data and media needs, the redesigned HPE Smart Array Controllers allow you the flexibility to choose the optimal 12 Gb/s controller most suited to your environment, and operate in both SAS and HBA mode.
Supporting a wide range of operating environments from Azure to Docker to ClearOS in addition to traditional operating systems.
Industry Leading Services and Ease of Deployment
The HPE ProLiant DL380 Gen10 server comes with a complete set of HPE Technology Services, delivering confidence, reducing risk, and helping customers realize agility and stability.
HPE Services simplifies all stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an optimal solution. Professional Services enable rapid deployment of solutions and Operational Services provide ongoing support.
A suite of embedded and downloadable tools is available for server lifecycle management including Unified Extensible Firmware Interface (UEFI), Intelligent Provisioning; HPE iLO 5 to monitor and manage; Smart Update Manager (SUM), and Service Pack for ProLiant (SPP).
Hewlett Packard Enterprise IT investment solutions help you transform to a digital business with IT economics that align to your business goals. -
Category Feature Details Network & Communication Ethernet Technology Gigabit Ethernet Storage Total Hard Drive Capacity No Warranty Additional Warranty Info 3-year parts, labor, and onsite support with next business day response. Chipset Chipset Manufacturer Intel Chipset Model C621 Display & Graphics Graphics Memory Capacity 16 MB Miscellaneous Security Features UEFI Secure Boot, Tamper-free updates, Immutable Silicon Root of Trust, Firmware rollback, FIPS 140-2, Secure NAND erase, PCI DSS compliance, AES, 3DES, CNSA, Secure Recovery, TPM, Bezel Locking Kit Environmentally Friendly Yes Energy Star Yes Controllers Controller Type 12Gb/s SAS, Serial ATA RAID Supported Yes Controller Model MR416ip 4GB and Smart Storage Battery Interfaces/Ports VGA Yes Network Ports 4 x RJ-45 Remote Management Yes USB Ports 5 x USB 3.0 Memory Max Memory Supported 1.54 TB Signal Processing Registered (Buffered) Standard Memory 32 GB Memory Technology DDR4 SDRAM Total Memory Slots 24 Occupied Memory Slots 1 Physical Characteristics Weight 19.50 kg Form Factor Rack Rack Height 2U Dimensions Height: 87.3 mm, Width: 445.4 mm, Depth: 679.4 mm Power Description Input Voltage 120 V AC, 230 V AC Plug/Connector Type C13/C14 Power Supplies Supported 2 Power Supplies Installed 1 Hot Swappable Power Supply Yes Max Power Supply Wattage 800 W General Information Product Type Server Part Number P56961-421 Website Address HPE Website Manufacturer Hewlett Packard Enterprise Product Name ProLiant DL380 G10 Server Product Line ProLiant Product Series DL380 G10 Brand Name HPE I/O Expansions Internal 2.5″ Bays 8 Total Expansion Bays 8 Total Expansion Slots 3 Hot Swappable Bays Yes PCI Express Slots 1 x PCIe x16 (Gen 3.x), 2 x PCIe x8 (Gen 3.x) SFF Bays 8 Processor Cache 13.75 MB Processor Speed 2.40 GHz Processor Type Xeon Silver Processor Model 4210R Processor Core Deca-core (10 Core) Processor Manufacturer Intel Processors Supported 2 Processors Installed 1 Processor Generation 2nd Gen Operating System OS No OS Supported Windows Server (various editions), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, ClearOS, Hyper-V Software OS No Supported OS Windows Server (2012-2022), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, ClearOS, Hyper-V
