Honeywell Eclipse MS5145 Handheld Barcode Scanner | MK5145-31A38-EU

• Description
• Specifications

• Honeywell Eclipse MS5145 Handheld Barcode Scanner | MK5145-31A38-EU

  Metrologic’s Eclipse MS5145 Bar Code Reader is a single-line, handheld laser scanner. Equipped with Metrologic’s patented CodeGate technology, Eclipse can be used in a wide variety of applications. CodeGate technology allows the user to easily target the desired bar code and complete the data transmission with a simple press of a button. This makes Eclipse a perfect selection for menu scanning, point-of-sale, document processing and inventory control.

  Creates a high ROI because of diminishment in workforce and descend inventory errors

  Allows productive and precise reading of 1D barcodes

  Wired connectivity makes this scanner ideal for retail and desktop applications

  Laser scan engine guarantees rapid error free data entry

  Scan barcodes with a staggering speed of 72 scan/s

• Attribute	Details
  Host Interface	Multi-interface
  Additional Information	Supported Interface: USB, USB Cable included
  Environmentally Friendly	Yes
  Weight (Approximate)	97 g
  Form Factor	Handheld
  Height	35.6 mm
  Width	63.5 mm
  Depth	170.2 mm
  Product Color	Black
  Product Type	Barcode Scanner
  Manufacturer Part Number	MK5145-31A38-EU
  Manufacturer	Honeywell International, Inc
  Product Model	MS5145
  Product Name	Eclipse MS5145 Bar Code Reader
  Product Line	Eclipse
  Brand Name	Honeywell
  Barcode Symbology Supported	Autodiscriminates all standard barcodes, including RSS
  Connectivity Technology	Cable
  Scanning Distance	178 mm
  Light Source	Laser
  Maximum Scan Resolution	0.10 mm
  Drop Specification	Designed to withstand 1.5 m (5´) drops
  Scan Pattern	Single Line
  Scan Rate	72 scan/s
  Cable Type Included	USB
  Scanning Capability	1D
  Field of View (Horizontal)	50°
  Reading Angle (Skew)	52°
  Reading Angle (Pitch)	68°
  Maximum Ambient Light	4842 lux
  Minimum Print Contrast	35%
