Hisense 49WF45H 49” Window Facing High Brightness Digital Signage Display

• Description
• Specifications
• Warranty
• Downloads

• Hisense 49WF45H

  49” Window Facing High Brightness Digital Signage Display

  Hisense Commercial Display solutions are perfect for high volume retail and corporate installation. A combination of seamless design and enhanced brightness ensure digital content vividly stands out from the crowd. Hisense window facing high brightness displays are perfect for the delivery of high-visibility and high-impact messaging to a target audience. With 4500 nits ultra high brightness the 49WF45H is suitable for use in ambient and outdoor lighting conditions.

  Round-the-clock operation
  Designed with dual-core System on Chip (SoC) technology, Hisense displays can be used as reliable digital signage for both offline and cloud based content 24 hours a day, 7 days a week. You are completely free to choose your content management system to help display your advertising. If necessary the internal memory will allow you to upload media into the display for instant broadcast without the need for external hardware or software.

  178° Wide viewing angle
  The extra wide 178° viewing angle is a perfect fit for shoppers, employees or visitors that will view displays from diverse angles while passing by.

  Landscape & portrait
  Both landscape and portrait orientations are possible, providing you with endless creative and functional possibilities to fulfil your commercial or informative goals.

  Visible With Polarized Sunglasses
  LED display correction technology could uniformly lighten several hundred thousand LED lights, presenting a uniform display effect with the same brightness and color scale.

  Smart Brightness Sensor
  Self-heat dissipation design, energy saving and noise reduction improve the service life.

  4500 nits
  LED display could reveal more details, including layers and colors, than traditional displays do.

• General	Details
  Model	49WF45H
  Screen size	49″
  Screen Active Area (mm)	1073.8×604.0
  Resolution	FHD (1920×1080)
  Aspect Ratio	16:9
  Brightness (nit)	4500nits
  Contrast Ratio	1300:1
  Dynamic CR	Up to 450000:1
  Viewing Angle (H/V)	178°/178°
  Backlight Life Cycle	50,000 Hrs
  Operation Hours	24/7
  Response Time	8ms
  Screen Orientation	Portrait or Landscape
  System
  OS	Android 9.0
  CPU	ARM Quad Core Cortex-A53 1.5G
  GPU	Arm Mali-G52 2EE MC1
  DDR	DDR 2GB
  ROM	16GB EMMC
  Language	Chinese/English
  Connectivity
  Input	USB2.0 x2, HDMI IN x2, Ethernet RJ45 x2, RS232 RJ45 x1, IR in x1, Sensor x1
  Output	HDMI Out x1, Audio out x1
  Network connection	Wifi or LAN: Yes
  3G/4G Connection	Optional
  Speaker
  Built-in speaker	Yes
  Line-out Support	Yes
  BT Speaker Support	Yes
  Thermal Management
  Smart Backlight Control	Yes
  Smart Temperature Control	Yes
  Smart Fans Control	Fanless
  Smart Monitoring System Cloud	Optional / CetusMSC
  Overheating protection	Yes
  Physical
  IP rating	IP5X (Front Panel)
  Glass	No
  Shell	Aluminum
  Standard Color	Black
  Bezel width(T/L/R/B)	10mm(T/B/L/R)
  Dimensions	1096.18 x 626.4 x 56.75mm
  Packing Dimensions	1224 x 759 x 180mm
  VESA	300 x 300
  Operation
  Working environment	Indoor window facing
  Auto Brightness control	Light sensor
  Operation Temperature	-10°C to 35°C (Direct Sunlight) -10°C to 45°C (w/o Direct Sunlight)
  Operation Humidity	10% to 80%
  Storage Temperature	-10°C to +60°C
  Storage Humidity	10% to 80%
  Power
  Power Supply	AC 110 /220V,50/60Hz
  Power Type	Built-In Power
  What’s in the box	Accessories: Power cord, IR receiver, Remote Control, AAA batteries x2, Wifi antenna, Lifting ring(M6) x2, Filler pad(M6) x2, Spring pad(M6) x2, User manual (Electronic version)
  Available Regions	EU, APAC, SA

• Hisense Premium Commercial Display Warranty

  Hisense proudly provides a unique 3-year de-installation warranty, ensuring seamless operation of your signage and swift solutions if challenges arise.

  Curious about the Hisense Display Collection?
  For any inquiries or additional details on the Hisense Digital Signage Displays, feel free to reach out to our dedicated team at 020 8191 9223 or drop us an email at: [email protected]

• Document Type	Download Link
  49WF45H Datasheet	DOWNLOAD
  WF Series Quick Installation Guide	DOWNLOAD
