Hikvision DS-D5022FN-C 21.5″ Led Full HD Borderless Monitor
- Product Descriptions
- Product Specifications
- Delivery Time
- Return and Warranty
-
LED backlit technology with full HD 1920 × 1080.
Wide viewing angle: Horizontal 178°, Vertical 178°.
Multiple interfaces: HDMI, VGA.
Image processing: 3D comb filter, 3D de-interlace, 3D noise reduction. -
Specification Value Model DS-D5022FN-C Screen Size 21.5″ Active Display Area 478.656 (H) mm × 260.28 (V) mm Resolution 1920 × 1080 Backlight E-LED Pixel Pitch 0.0831 (H) mm × 0.241 (V) mm Brightness 250 cd/㎡ Viewing Angle 178°/178° Color Depth 8 bit Contrast Ratio 3000:1 Response Time 6.5 ms (typ) Refresh Rate 60 Hz Haze 25 % Reliability 7 × 16 H Color Gamut 72% Video & Audio Input HDMI × 1, VGA × 1 Power Supply 12 VDC Power Consumption ≤ 22 W Standby Consumption ≤ 0.5 W Working Temperature 0 ℃ to 40 ℃ (32 ℉ to 104 ℉) Working Humidity 20% to 90% RH (Non-Condensing) Storage Temperature -20 ℃ to 60 ℃ (-4 ℉ to 140 ℉) Storage Humidity 20% to 80% RH (Non-Condensing) Casing Material Plastic VESA 75 mm × 75 mm, 4-M6 × 6 screw holes Bezel Width 19.06 mm (top/left/right), 30.87 mm (bottom) Product Dimensions With base: 492.356 (W) mm × 390.11 (H) mm × 199.79 (D) mm (19.38” × 15.36” × 7.87”)<br>Without base: 492.356 (W) mm × 289.680 (H) mm × 43.88 (D) mm (19.38” × 11.40” × 1.73”) Package Dimensions 644 (W) mm × 108 (H) mm × 403 (D) mm (25.35” × 4.25” × 15.87”) Net Weight 2.5 ± 0.5 kg (5.5 ± 1.1 lb.) Gross Weight 3.8 ± 0.5 kg (8.4 ± 1.1 lb.) Packing List Power adapter × 1, RoHS certificate × 1, base bracket × 1, user manual × 1, quick start guide × 1, HDMI cable × 1 Remarks *The base is included by default.<br>*The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information. -
Standard Shipping: Deliver within 1-3 days after the order was placed.
Next-Business-Day: Shipping same-day (before 14:00 PM Orders), arriving next business days. -
Hikvision 5 Year Warranty
Hikvision takes quality seriously and puts a lot of effort into ensuring our products are both innovative and reliable. We understand the importance of this, both for peace of mind and cost control, so we have developed extra levels of support for certain products lines: a new 5-year Warranty.
Most of our products come with a standard 3-year warranty, but we know extra support on certain series is welcomed by customers. From 1 January 2020, these products have an extended warranty of five years in total (T&C’s apply). This warranty also applies to purchases of these products going forward.
Customers can see the products that qualify for the warranty in the chart below. It automatically applies from purchase, with no action required from customers. That means no registration, no administration and no hassle. They can simply enjoy enhanced support free of charge – leading to costs savings over the duration of a project.
