Gigabyte WINDFORCE OC NVIDIA GeForce RTX 4060 8 GB Graphics Card
WINDFORCE
COOLING SYSTEM
The WINDFORCE cooling system features two 80mm unique blade fans, alternate spinning, a composite copper heat pipe that directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNING
Reduce the turbulence of adjacent fans and increase airflow pressure.SMOOTH AIRFLOW
GIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.3D ACTIVE FAN
The 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.UNIQUE BLADE FAN
The airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.GRAPHENE NANO LUBRICANT
Graphene nano lubricant can extend the life of sleeve bearing fan by 2.1 times, close to the life of double ball bearing, and is quieter.SCREEN COOLING
Extended heatsink allows air to pass through, providing better heat dissipation.OPTIMIZED THERMAL MODULE
The pure copper heat pipe makes direct contact with the GPU to facilitate enhanced heat transfer to the heatsink, optimizing the cooling efficiency of the graphics card.PROTECTION BACK PLATE
The back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.GIGABYTE CONTROL CENTER
GIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time. -
Feature Specification Brand Gigabyte SKU 10391509 Manu Part # GV-N4060WF2OC-8G EAN 4719331313685 Features DLSS Version NVIDIA DLSS 3 Architecture Ada Lovelace Tensor Cores 4th Generation (Up to 4x DLSS 3 performance) RT Cores 3rd Generation (Up to 2X ray tracing performance) GPU GeForce RTX 4060 VRAM 8GB GDDR6 Memory Interface 128-bit Cooling System WINDFORCE Back Plate Protection back plate Design Number of Fans 3 Product Colour Black Cooling Type Active Form Factor Full-Height/Half-Length (FH/HL) Cooling Technology Gigabyte WATERFORCE Packaging Data Package Type Box Processor Maximum Resolution 7680 x 4320 pixels Graphics Processor Family NVIDIA Parallel Processing Technology Support Not supported Processor Frequency 2475 MHz CUDA Cores 3072 Ports & Interfaces DisplayPort Version 1.4a Interface Type PCI Express 4.0 HDMI Version 2.1a HDMI Ports Quantity 2 DisplayPorts Quantity 2 Memory Memory Type GDDR6 Discrete Graphics Card Memory 8 GB Memory Bus 128-bit Data Transfer Rate 17 Gbit/s Performance AMD FreeSync No DirectX Version 12 Ultimate HDCP Yes TV Tuner Integrated No NVIDIA G-SYNC Yes Dual Link DVI No OpenGL Version 4.6 Power Supplementary Power Connectors 1x 8-pin Minimum System Power Supply 450 W Weight & Dimensions Width 120 mm Depth 192 mm Height 41 mm Packaging Content Quick Installation Guide Yes -
Description Downloads Gigabyte WINDFORCE OC NVIDIA GeForce RTX 4060 DataSheet Downloads
