Geephon 55″ 2500 cd/m² Window Facing High Brightness Display | BAB5522A-AC-25

• Description
• Specifications
• Downloads

• Geephon 55″ 2500 cd/m² Window Facing High Brightness Display


  GBright High Brightness
  Excellent Visibility And Smart Light Sensor
  Resolution 2K/4K guarantees true color expression.
  You would not “Miss a Thing” with 4500nit high brightness
  Which guarantees to deliver excellent picture quality at your shop window,even in direct sunlight.

  GSunshine
  Enhanced brightness, color, and color saturation under direct-sunlight to ensure that the picture quality remains great.

  GPolarView
  Viewable through polarized lenses

  GDynamic Long Lasting Green Signage With LDM Technology
  Energy savings of up to 45% can be achieved at the same brightness.

  Contrast ratio up to 450000:1
  Compared with traditional digital signage products, Geephon Eco- digital signage products not only have ultra-high display brightness, but also ultra-low power

  GComponent Lightweight Design
  Modularization design of components for easy maintenance, easy field removal and replacement of damaged devices.
  Advanced design concept makes the product thinner and lighter. Made of nigh-strength aluminum alloy material, the product is stronger and greatly reduces weight, easy to install and transport.

  Flexible And Multiple Ways To Integrate
  Ceilling installation
  Standing installation
  Extended Mode

  IP5X Protection
  The equipment has excellent dust-proof performance and can easily cope with the needs of indoor scenes


  Fail Over System
  The Fail Over system can automatically start playing the pictures and videos pre-setting on the device,when the HDMl input fails.
  So that the machine can continue to display stably then the Fail Over system will automatically report to the monitoring system, then the team can maintain the device.Make sure our display sare never down.

  GFanless Design
  The specially optimized structural design make fanless design signage is noise free and maintenance free. only for products of 2500nit and 3500nit.

  GSilence Fan Speed Control
  GSilence Technology for product of 4500nit.The built-in high-flux low-noise fan combines intelligent algorithms withsensor data to ensure device heat dissipation while minimizing noise.

  All-in-One Signage Solution
  Support CMS&MSC
  Support SDK/Open AP
  Support OTA update/upgrade function

  SDK/OPEN API RS232 CONTROL
  The product supports SDK development and provides OpenAPl interface(via RS232) to third-party companies for development and docking. a strong R&D team supports and quarantees the needs of partners for in-depth customization.

• Attribute	Value
  Screen Size	55 inch
  Screen Active Area	1209.6 x 680.4 mm
  Resolution	1920 x 1080
  Aspect Ratio	16:9
  Type	D-LED BLU
  Brightness (nit)	2500 nit
  Contrast Ratio	1000:1
  Dynamic Contrast Ratio	Up to 250000:1
  Color Depth	16.7M
  Color Gamut	72%
  Viewing Angle (H/V)	178°/178°
  Operation Hours	24/7
  Response Time	6ms
  Screen Orientation	Portrait or Landscape
  OS	Android 9.0
  CPU	ARM Quad Core Cortex-A53 1.5G
  GPU	Arm Mali-G52 2EE MC1
  DDR	2GB
  ROM	16GB EMMC
  Input	USB 2.0 x2, HDMI IN x2, Ethernet x2, RS232 (RJ45) x1, IR in x1, Sensor x1
  Output	HDMI Out x1, Audio Out x1
  Network Connection	WiFi or LAN
  Speaker	Built-in speaker
  IP Rating	IP5X (Front Panel)
  Dimensions (L/W/D)	1232 x 702.8 x 56.85 mm
  Net Weight	24.6 kg
  Power Supply	AC 110/220V, 50/60Hz
  Max Power Consumption	250W (Brightness: 2500 nit)
  Operation Temp	0°C to +40°C (Direct Sunlight)

• Description	Downloads
  Geephon 55″ 2500 cd/m² Window Facing High Brightness Display | BAB5522A-AC-25 DataSheet	Downloads
