Epson EB-760W Laser Display Projector – 4100 Lumens

• Description
• Specifications
• Downloads

• Epson EB-760W Laser Display Projector – 4100 Lumens

  The EB-760W’s ultra short throw lens allows safe, discreet positioning close to the display, enabling presenters free access to perform without casting shadows.

  With 4,100 lumens Colour Light Output and Epson 3LCD technology, the display is bright and vibrant up-to 150″, clearly visible from all angles and from a distance. The experience is immersive and user-friendly.

  Projection also enables flexible display sizes, scalable from 49-150″, display sizes can be optimised for each room with one familiar product and at a fixed cost

  Versatile wired and wireless connectivity options, including screen mirroring via Miracast™, allow participants to effortlessly share content from their PCs or mobile devices. With a connected optional Epson visualiser, documents, presentations or 3D objects can be viewed with incredible detail.

  Unlike a flat-panel display, there is no heavy, breakable, glass panel to create disruptive, reflected blind spots at certain angles, and teachers are not subjected to LCD panel direct blue light radiation, believed to damage eyes. Paired with a hygienic, antibacterial whiteboard, teachers can annotate presentations with dry-wipe pens, or to save energy, simply use the whiteboard with the display turned off.

• Technology
  Projection System	3LCD Technology, RGB liquid crystal shutter
  LCD Panel	0.59 inch with C2 Fine
  Color Light Output	4,100 Lumen- 2,800 Lumen (economy) In accordance with IDMS15.4
  White Light Output	4,100 Lumen – 2,800 Lumen (economy) In accordance with ISO 21118:2020
  Resolution	WXGA
  High Definition	HD ready
  Aspect Ratio	16:10
  Contrast Ratio	Over 2,500,000 : 1
  Light source	Laser
  Laser Light source	20,000 hours Durability High, 30,000 hours Durability Eco
  Keystone Correction	Manual vertical: ± 3 °, Manual horizontal ± 3 °
  Colour Video Processing	10 Bits
  2D Vertical Refresh Rate	100 Hz – 120 Hz
  Colour Reproduction	Upto 1.07 billion colours
  Optical
  Throw Ratio	0.27 – 0.37:1
  Zoom	Digital, Factor: 1 – 1.35
  Lens	Optical
  Screen Size	60 inches – 150 inches
  Projection Lens F Number	1.6
  Projection Lens Focal Length	3.7 mm
  Projection Lens Focus	Manual
  Offset	6 : 1
  Connectivity
  Interfaces	USB 2.0-A (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac, VGA in (2x), VGA out, HDMI in (3x), Composite in, Miracast, Jack plug out, Jack plug in (3x), USB 2.0 Type B (Service Only), Wi-Fi Direct, Microphone input
  Epson iProjection App	Ad-Hoc / Infrastructure
  Network Protocol	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
  Advanced Features	Security, A/V mute, Arc Correction, Auto Power On, Auto source search, Built-in speaker, CEC compatible, Customizable user logo, Digital zoom, Direct Power on/off, Document Camera Compatible, Email notification, Home Screen, Horizontal and vertical keystone correction, Image Shift, JPEG Viewer, Long light source life, Network projection, OSD copy function, PC Free, Power on button, Quick Corner, Schedule Function, Screen Mirroring, Ultra-wide display (16:6), Web Control, Web Remote, Wireless LAN capable, iProjection App
  Video Color Modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
  Projector control	via: Crestron Integrated Partner, Crestron RoomView, Extron IP Link, AMX Device Discovery, Control4 Simple Device Discovery Protocol
  General
  Power consumption	197 Watt (Normal On-Mode), 141 Watt (Eco On-Mode), 263 Watt (Normal Peak-mode), 199 Watt (Eco Peak-Mode), 0.5 Watt (Energy saving standby)
  Heat Dissipation	895 BTU/hour (max)
  Supply Voltage	AC 100 V – 240 V, 50 Hz – 60 Hz
  Product dimensions	356 x 395 x 133 mm (Width x Depth x Height)
  Product weight	5.9 kg
  Noise Level	Normal: 37 dB (A) – Economy: 27 dB (A)
  Supported Temperature	Storage -10° C – 60° C
  Supported Humidity	Operation 20% – 80%, Storage 10% – 90%
  Included Software	EasyMP Multi PC Projection, Epson Projector Content Manager, Epson Projector Management
  Options	Air filter, Ceiling mount, Connection and control box, External Speaker, Safety wire set, Visualiser camera, WP System – ELPWP10, Wall mount, Wireless LAN unit, Wireless transmitter – ELPWT01
  Loudspeaker	16 Watt
  Room Type / Application	Meeting room / Classroom
  Positioning	Ceiling Mounted, Desktop, Wall Mounted
  Colour	White
  Warranty	60 months Carry in or 12,000 h

• Description	Downloads
  Data sheet	Download
