ELO E344260/4363L 43″ Full HD Open-Frame Touch Screen Monitor
- Description
- Specifications
- Warranty
- Downloads
-
The perfect touchscreen for any enclosure.
Elo’s 4363L 43-inch full HD open-frame delivers a state-of-the-art slim form factor designed for easy integration into enclosures and kiosks. Whether for self-order and self-checkout kiosks or industrial controls, operating room control boards and wayfinding solutions, Elo’s commercial-grade interactive displays offer the versatility to add touch to your solution.
Get the durability your kiosks need.
UL60950
IK07
Ready for 24/7 Use
IP65 (requires integration)
Brilliant, interactive TouchPro® PCAP display.
The 4363L offers anti-glare or anti-friction models with edge-to-edge glass and up to 40 simultaneous touches for an enhanced, tablet-like experience.
Integrated connectivity.
HDMI
USB 2.0
VGA
RJ45
Brilliant, interactive TouchPro® PCAP display.
The 4363L offers anti-glare or anti-friction models with edge-to-edge glass and up to 40 simultaneous touches for an enhanced, tablet-like experience.
Captivate customers and employees with reliable,easy to use interactive solutions.
Payment and Ticketing
Operating Room Control Board
Point of Information
Self-Order/Self-Checkout
Automation/Industrial Controls
Wayfinding & Interactive Signage
Designed for easy integration.
Mount the 4363L touchscreen monitor in landscape, portrait and upward facing orientations, providing optimal flexibility for integrating in any counter, kiosk or cabinet design.
Get the viewing experience you want to see.
Whether viewing straight on or at an angle, close-up or from a distance, Elo’s touchscreen displays offer optimal clarity for the viewing experience.
Place your touchscreen behind an extra layer of protection.
For installations that require specific IP ratings or protection from vandalism and harsh environments, Elo’s TouchPro PCAP displays offer touch thru capability. With touch thru technology, the display can be mounted behind a front layer of glass up to 6 mm or plastic up to 3 mm to create a fully enclosed kiosk.
Make your digital transformation faster,and more affordable.
Elo EssentialEdge™ for Android offers everything you need to build and operate interactive solutions for your business.
The Elo Backpack brings computing power that scales.
With the Elo Backpack you get a powerful, commercial-grade Android compute engine purpose-built to fit in compact spaces. Boasting a small footprint in both size and weight, the Elo Backpack can secure inside any kiosk with the built-in VESA mount. Scaling Elo’s commercial Android platform across sizes and form factors has never been easier.
EloCare℠ provides service and support from the people who know your Elo products best.
Advanced Unit Replacement
Extended Warranty
Professional Services
Configurations -
Category Details Part Number(s) – TouchPro PCAP (clear with anti-friction) – E344056<br>- TouchPro PCAP (anti-glare) – E344260 Enclosure Color Black Touch Technology & Capacity PCAP (TouchPro® Projected Capacitive) – 40 Touch with Palm Rejection and Touch Thru capability Touch Thru Supports up to 6mm glass/3mm plastic with up to 2 touches. Supports gloves up to 1.4mm Touch Interface USB Diagonal Size 42.5” diagonal, Active matrix TFT LCD (LED) On Screen Display Accessible through switches on the OSD Control Remote accessory.<br>Controls (side): Menu, Up, Down, Select<br>Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Recall Defaults, Video Source, Touch, RTC, MDC, Touch Through<br>Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese<br>Lockouts: OSD, Power<br>RTC Settings: The clock/time and the monitor ON/OFF schedule can be changed within this menu. Daylight Saving time is adjusted for automatically and will change the current time by one hour to accommodate daylight savings time.<br>See user manual for full details. Aspect Ratio 16:9 Active Area 37.04″ x 20.84″ / 940.86 mm x 529.254 mm Resolution 1920 x 1080 @ 60hz Other Supported Resolutions – 640×480 @ 60Hz<br>- 800×600 @ 56/60Hz<br>- 1024×768 @ 60Hz<br>- 1280×720 @ 60Hz<br>- 1280×800 @ 60Hz RB<br>- 1280×960 @ 60Hz<br>- 1280×1024 @ 60Hz<br>- 1366×768 @ 60Hz<br>- 1366×768 @ 60Hz RB<br>- 1440×900 @ 60Hz<br>- 1440×900 @ 60Hz RB<br>- 1680×1050 @ 60Hz<br>- 1680×1050 @ 60Hz RB<br>- 1920×1080 @ 60Hz Viewing Angle Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total Number of Colors 8-bit (16.7 million) Brightness (typical) – LCD panel: 450 nits<br>- TouchPro PCAP: 387 nits Response Time-total (typical) 8 msec Contrast Ratio 4000:1 I/O Ports – HDMI 1.4 x2<br>- USB 2.0 Type B (for Touch)<br>- RJ45 (for optional OSD remote)<br>- VGA Video – 2x HDCP-capable HDMI on Type A connector<br>- Female DE-15 VGA connector<br>- Input Video Horizontal Sync frequency range: 31.5 – 80 KHz<br>- Input Video Vertical Sync (frame rate) frequency range: 47 – 63 KHz Power – Input connector (power): IEC 60320-C14<br>- Input signal specifications (power): 100-240VAC 50/60Hz Maximum Operating Time 24 hours/day Power Consumption (Typical) – ON (monitor + AC/DC adapter): 51 W<br>- SLEEP (monitor + AC/DC adapter): 0.61 W<br>- OFF (monitor + AC/DC adapter): 0.20 W Dimensions 39.34″ x 23.13″ x 2.61″ / 999.28 mm x 587.5 mm x 66.4 mm Shipping Box Dimensions 48.06″ x 9.85″ x 31.12″ / 1220 mm x 250 mm x 790 mm Weight (Unpackaged) 37.77 lbs / 17.17 Kg Weight (Packaged) 50.79 lbs / 23.09 Kg Operating Temperature – Portrait/Landscape Mode: 0°C to 40°C / 32°F to 104°F<br>- Tabletop Mode: 0°C to 35°C / 32°F to 95°F Storage Temperature – Portrait/Landscape Mode: -20°C to 60°C / -4°F to 140°F<br>- Tabletop Mode: -20°C to 60°C / -4°F to 140°F Humidity – Operating: 20% to 80%<br>- Storage: 10% to 90% (38.7°C max wet bulb temperature) Sealability – Touchscreen sealed to bezel<br>- Touchscreen sealed to LCD MTBF 50,000 hours demonstrated Warranty 3-year Extended Service Options – 4 year warranty coverage + AUR – Elo P/N: E740135<br>- 5 year warranty coverage + AUR – Elo P/N: E740330 Regulatory approvals and declarations – Argentina S-Mark<br>- Australia RCM<br>- Canada CUL, IC<br>- China CCC<br>- Europe CE<br>- Japan VCCI<br>- Korea KCC e-Standby<br>- Mexico CoC<br>- Russia EAC<br>- Taiwan BSMI<br>- United States UL, FCC<br>- International CB<br>- Mexico NOM<br>- RoHS, China RoHS, WEEE<br>- Energy Star 8.0<br>- UL 60950 ball-drop compliant<br>- IK07 impact compliant<br>- CB (International safety) (IEC/EN60950-1+IEC/EN62368-1) Mounting Options VESA 400mm x 400mm<br>See dimensional drawings for details Other Features Ambient Light Sensor – changes panel color to match ambient light, Auto Wake What’s in the Box – Quick Install Guide<br>- HDMI 1.4 cable (Type A plug to Type A plug)<br>- VGA cable (DB-15 male to DB-15 male)<br>- USB cable (Type A plug to Type B plug)<br>- RJ45 Wired OSD remote<br>- Power cable, IEC 60320-C13 to NA plug<br>- Power cable, IEC 60320-C13 to EU/KR plug<br>- Power cable, IEC 60320-C13 to UK plug<br>- Energy label according to EU Regulation 2019/2013<br>- 8 sets Flushmount Brackets<br>- 48 pcs Screws<br>- Foam Gasket Options / Peripherals / Upgrades Elo 43-inch Wide Flush-mount Bracket – Elo P/N: E848336 -
Touchscreen Monitors LCD Monitors 3 years -
Documents and Certificates Dimensional Drawing CAD Drawings Agency Approval Certificates Material Safety Data Sheet (MSDS) EU Regulation 2019/2013 Energy Efficiency Label UK Regulation 2019/2013 Energy Efficiency Label Energy Efficiency Fiche Spec Sheet
