DynaScan DW651LR5 65″ Clean Back High Brightness Display

DynaScan DW651LR5

65″ Clean Back High Brightness Display

• Description
• Specifications
• Warranty
• Download

• Ultra High Brightness Displays
  DynaScan introduces a revolutionary leap for window-facing display technology. The DW651LR5 is a clean back ultra-high brightness LCD with a sunlight-viewable 4000-nit brightness designed for in-window applications.

  The DW Series offers users a complete window-facing display solution with high-end design features such as hidden cable management, portrait and landscape orientations, and versatile mounting options such as ceiling mount and floor stand compatibility.

  Every display is factory color calibrated for remarkable color reproduction, high contrast, and superb picture quality.

  SUNLIGHT VIEWABLE IMAGE

  PORTRAIT & LANDSCAPE

  CEILING SUSPENDED

  CLEAN-BACK DESIGN

  TRUECOLOR™ CALIBRATED

  VIEWABLE WITH POLARIZED LENSES

  BUILT-IN MEDIA PLAYER

  BLACKENING DEFECT-FREE

  Product Highlights
  High-brightness 4000 nits, blackening defect-free in direct sunlight, integrated cable management, clean back design, integrated media player, 3840×2160 4K UHD resolution, all-metal construction.

  Clean Back Design
  Designed to hang in a storefront window with its back exposed, the DW651LR5 features a clean-back design, ensuring an elegant and clutter-free appearance from all angles.

  Blackening Defect-Free
  The DW651LR5 is equipped with a high-temperature LCD panel capable of withstanding temperatures up to 110˚C (230°F) without blackening – crucial for direct sunlight applications.

  Auto Brightness Control
  Different external lighting conditions require different brightness levels. An onboard light sensor measures the ambient light in the area and automatically adjusts the image accordingly.

  TrueColor™ Calibration
  Each screen is individually color calibrated to the D65 (6500K) CIE color standard. Not only does this produce a true, natural white, but also accurately reproduces brand colors, skin tones, and colorways.

  Built-in Media Player
  An integrated Android™ based media player with wireless connectivity offers users the freedom to select from the array of various media software solutions on the market or use the bundled DynaScan DSM365 application for local video playback, playlist creation, and content scheduling.

• PANEL
  LCD Panel Size	64.53 inches
  Native Resolution	3840 x 2160
  Backlight	LED
  Default Color Temperature	D65 (6500 K)
  Brightness	4000 nits
  Color Depth	10 bits
  Contrast Ratio	3000:1
  Response Time (Typ.)	8 ms
  Viewing Angle (H/V)	178° / 178°
  Light Lifetime (Typ.)	100,000 hrs
  Panel Surface	AG Haze 3%, 2H
  Blackening Defect Free	Up to 110°C (230°F)
  Viewable with Polarized Lenses	Yes

  POWER
  Power Supply	Internal
  Rated Voltage	100-240 V, 50/60 Hz
  Power On Mode (Typ./Max.)	510 W / 740 W
  Power Saving Mode	< 1 W

  MECHANICAL SPECS
  Bezel Width (T/B/L/R)	Even bezel 19.0 mm
  Cabinet Color	Black
  Monitor Dimension (LxHxD w/o Stand)	1472.5 x 847.4 x 74.6 mm
  Monitor Weight	43 kg
  Orientation	Portrait & Landscape
  Carrying Handles	Yes

  USER INTERFACE
  Language	English
  Support SNMP (Up to V3.0)	Yes
  Dimming Control	Yes
  Image Retention Proof	Yes
  Auto Orientation Sensor	Yes
  Ambient Light Sensor	Yes
  Power On/Off Scheduling	Yes
  Internal Temperature Sensor	Yes
  OSD Menu Rotation	Yes

  INPUT
  HDMI 2.1 (HDCP 2.3)	x2 (2160p)
  DisplayPort	x1
  USB 3.0	x1
  Micro SD Slot	x1

  OUTPUT
  Audio	x1

  EXTERNAL CONTROL
  RS-232	In x1
  RJ-45	x2 (LAN)

  INTERNAL PLAYERS
  Operating system	Android 8.0.0
  Processor	Dual-core A73 and dual-core A53
  Clock Speed	1.5 GHz
  Main Memory Interface	DDR4, 2G
  Graphics	Quad-core MaliG51
  Storage	Internal: 16GB eMMC Flash External: Support Micro SD, Up to 32GB(exFAT) /128GB(FAT32)
  Multimedia	4K 10bits VP9/H265/H264 video decoders, up to 60fps 1080P other video decoders (VC-1, MPEG-1/2/4, VP8)
  Wi-Fi Specification	802.11 b/g/n

  ENVIRONMENT
  Operating Temperature	0°C ~ 45°C
  Storage Temperature	-20°C ~ 60°C
  Humidity	10% ~ 80% RH Non-condensing

  CERTIFICATION
  CE	FCC
  RoHS

• DynaScan’s warranty obligations are limited to the terms set forth below:

  DynaScan warrants its professional LCD display product delivered new to the original purchaser against defects in materials and workmanship for THREE (3) YEARS from the date of original purchase.

  If a product is found to be defective in material and workmanship during the Limited Warranty Period, DynaScan will, at its sole option, (a) repair the product at no charge with new or reconditioned parts, or (b) replace the product with a functionally equivalent product. A replacement part or product assumes the remaining warranty of the original part or product, or NINETY (90) DAYS from the date of replacement or repair, whichever provides a longer coverage. When a part or product is replaced, any replacement item becomes your property and the replaced item becomes DynaScan’s property.

• Resource	Download Link
  Data Sheet	Download
  User Manual	Download
