• DELL PowerEdge R6515 2.8 GHz 16 GB DDR4-SDRAM Rack (1U) AMD EPYC 550 W Server


  Dell PowerEdge R6515
  Dual-socket performance in a single-socket 1U rack design
  The Dell EMC PowerEdge R6515 is a single-socket 1U server designed to handle workloads like virtualization, HCI and OpenStack Ready Architecture.

  Efficiently scale your IT operations
  The R6515 is a powerful single-socket/1U server that can scale out to match performance of under-utilized systems. With the enhanced 3rd Gen AMD EPYC™ processor, up to 2 single-wide GPUs, and 2TB of 3200 MT/s memory, the R6515 is perfect for virtualization and HCI. The small form factor makes it great for everything from small and remote offices to larger scale out computing deployments.


  Deliver breakthrough performance, innovation and density
  The popularity of single-socket systems has started to show in the make up of data centers. The PowerEdge R6515 creates an equilibrium of compute resources within a single-socket/1U form factor. The low profile design offers increasingly more compute power with each new generation of AMD EPYC™ processors.
  Replace your legacy two-socket cluster with an updated and cost efficient single-socket server without compromising performance
  Enhanced 3rd Gen AMD EPYC™ (up to 280W) processor may be the only socket you need
  Improved TCO with VM density and SQL performance improvements
  High parallelism for low latency on ROBO and Dense Azure Stack HCI


  OpenManage systems management
  The Dell EMC OpenManage systems management portfolio helps tame the complexity of your IT environment with tools and solutions to discover, monitor, manage, update, and deploy your PowerEdge infrastructure.


  Intelligent Automation
  PowerEdge and OpenManage solutions integrate tools across the portfolio to help organizations automate the server lifecycle, optimize operations, and scale efficiently.


  Built-in security
  Dell EMC PowerEdge servers are made with a cyber resilient architecture that builds in security at every phase of the product lifecycle, from the silicon root of trust and secured component verification, to signed firmware and drift detection, to BIOS recovery.

• Category	Feature	Details
  Processor	Processor Manufacturer	AMD
  	Processor Family	AMD EPYC
  	Processor Model	7282
  	Processor Frequency	2.8 GHz
  	Processor Boost Frequency	3.2 GHz
  	Processor Cache	64 MB
  	Number of Processors Installed	1
  Memory	Internal Memory	16 GB
  	Internal Memory Type	DDR4-SDRAM
  	Buffered Memory Type	Registered (buffered)
  	Memory Ranking	2
  	Memory Clock Speed	3200 MHz
  	Memory Layout (Slots x Size)	1 x 16 GB
  	Memory Data Transfer Rate	3200 MT/s
  	Maximum Internal Memory	128 GB
  Storage	Total Storage Capacity	480 GB
  	Number of HDDs Supported	8
  	Supported HDD Sizes	2.5″
  	Number of SSDs Installed	1
  	SSD Capacity	480 GB
  	SSD Interface	SATA
  	SSD Size	2.5″
  	Supported SSD Sizes	2.5″
  	Number of SSDs Supported	8
  	Supported RAID Controllers	PERC H730P
  	Hot-Plug Support	Yes
  	Optical Drive Type	None
  	Drive Writes Per Day (DWPD)	3
  Graphics	On-board Graphics Card	No
  	On-board Graphics Card Model	Not available
  Network	LAN Controller	Broadcom 5720
  	Ethernet LAN	Yes
  	Cabling Technology	10/100/1000Base-T(X)
  	Ethernet Interface Type	Gigabit Ethernet
  Ports & Interfaces	USB 2.0 Ports Quantity	1
  	USB 3.2 Gen 1 (3.1 Gen 1) Type-A Ports	2
  	VGA (D-Sub) Ports Quantity	2
  	Serial Ports Quantity	1
  	Power Cables Quantity	1
  Expansion Slots	PCI Express x16 Slots	2
  Design	Chassis Type	Rack (1U)
  	Product Colour	Black
  	Bezel	Yes
  Performance	Remote Administration	iDRAC9 Enterprise 15G
  Software	Operating System Installed	None
  	Compatible Operating Systems	Ubuntu, Citrix Hypervisor, Windows Server, Red Hat, SUSE, VMware ESXi
  Power	Redundant Power Supply (RPS) Support	Yes
  	Power Supply	550 W
  	Number of Redundant Power Supplies	2
  	Number of Main Power Supplies	1
  	Power Cable Length	2 m
  	Power Cable Connector 1	C13 coupler
  	Power Cable Connector 2	C14 coupler
  	Power Cable Current	10 A
  Operational Conditions	Operating Temperature (T-T)	10 – 35 °C
  	Storage Temperature (T-T)	-40 – 65 °C
  	Operating Relative Humidity (H-H)	8 – 80%
  	Storage Relative Humidity (H-H)	5 – 95%
  	Operating Altitude	0 – 3048 m
  	Non-Operating Altitude	0 – 12000 m
  Logistics Data	Harmonized System (HS) Code	84714100
  Weight & Dimensions	Width	482 mm
  	Height	42.8 mm
  Other Features	Data Transfer Rate	6 Gbit/s
  	Bytes per Sector	512
