Dell Intel X550 Dual Port 10G Base-T Low Profile Adapter | 540-BBRG

• Description
• Specifications

• Dell Intel X550 Dual Port 10G Base-T Low Profile Adapter


  Highlights
  – Offers 10GbE Ethernet
  – Support demanding workloads for enterprise, cloud, and telecommunication service providers and data centers

  Overview
  The Intel X550 Dual Port 10G Base-T Adapter, Low Profile Ethernet is is validated and optimized on Intel® Xeon® processors and is backward Compatible with 1000BASE-T. It has an integrated MAC + 10GBASE-T PHYs, Single-Chip Solution and is designed for Multi-Core Processors: MSI/MSI-X and Direct Cache Access, Flow Director, up to 128 Tx/Rx physical queues per port. It is the best choice for virtualized servers, providing advanced features including Intel® Virtualization Technology for Connectivity (VT-c), Virtual Machine Device Queues (VMDq) and Single Root I/O Virtualization (SR-IOV) up to 64 VFs per port, NVGRE and VXLAN stateless offloads delivering amazing performance.

  – Built to enable Network Virtualization and Network Functions Virtualization (NFV)
  – Unparalleled supply line, customer support, and warranty
  – Designed to support demanding workloads for enterprise, cloud, and telecommunication service providers and data centers.
  – Intel is the #1 Ethernet vendor- having shipped over 1 billion Ethernet ports

• Category	Feature	Details
  Design	Chipset	Intel
  	Compatible Products	PowerEdge FC430, FC830, M630, M830, R430, R530, R630, R730, R730xd, R930, T430, T630
  	Component For	Server
  	Internal	Yes
  	Product Color	Black/Green
  	Recommended Usage	Server
  Legal Info	EU ECCN Code	N/A
  	UNSPSC Code (Icecat)	43201404
  	US ECCN Code	5A991
  Network	Cabling Technology	10GBase-T
  	Data Link Protocols	10 GigE
  	Ethernet Interface Type	10 Gigabit Ethernet
  	Ethernet LAN	Yes
  	Ethernet LAN Data Rates	10000 Mbit/s
  	LAN Controller	Intel® X550
  	Max Data Transfer Rate	10000 Mbit/s
  	Wake-on-LAN Ready	Yes
  Other Features	Chipset	Intel
  Package Details	Gross Weight	0.4 kg
  Ports & Interfaces	Connectivity Technology	Wired
  	Ethernet LAN (RJ-45) Ports	2
  	Host Interface	PCI Express
  	Interface	Ethernet
  Product Dimensions	Net Weight	0.3 kg
  Vendor Info	Brand Name	Dell
  	Warranty	1 Year(s)
  Categories	Main Category	Server, Computer & Printer Parts
  	Subcategories	Servers & Computers, System Components, Networking Cards
