Datalogic Touch 90 Lite TD1170-BK-90 Handheld Barcode Scanner – Cable Connectivity

• Description
• Specifications

• Datalogic Touch 90 Lite TD1170-BK-90 Handheld Barcode Scanner – Cable Connectivity

  The Touch™ TD1100 series of linear imaging contact readers represent the Datalogic ADC solution for customers who require a cost-effective solution for close contact bar code reading without sacrificing quality and performance.

  Designed for low throughput applications within multiple markets, the Touch TD1100 readers provide the guarantee of contact reading with an excellent reading performance on virtually all linear bar codes, including damaged or poorly printed codes.

• Feature	Specification
  Host Interface	Keyboard Wedge, Serial
  Additional Information	USB Cable separate
  Environmentally Friendly	Yes
  Environmental Compliance	RoHS, China RoHS
  Weight (Approximate)	153.1 g
  Form Factor	Handheld
  Dimensions	Height: 170.2 mm, Width: 68.6 mm, Depth: 104.1 mm
  Product Color	Black
  Barcode Symbology Supported	1D / Linear Codes: Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes Stacked Codes: GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
  Connectivity Technology	Cable
  Maximum Scan Resolution	0.10 mm
  Depth of Field	0″ – 3.2″ at 7.5 mil – Code 39, 0″ – 4.7″ at 10 mil – Code 39, 0″ – 6″ at 13 mil – EAN13
  Scan Pattern	Omni-directional
  Image Sensor Type	Imager, Linear
  Scanning Capability	1D
  Product Type	Barcode Scanner
  Manufacturer Part Number	TD1170-BK-90
  Manufacturer	Datalogic S.p.A
  Product Model	90 Lite
  Product Name	General Purpose Corded Handheld Contact Linear Imager Bar Code Reader
  Product Line	Touch
  Product Series	TD1100
  Brand Name	Datalogic
