Datalogic Matrix 120 310-001 Fixed Barcode reader, 1D/2D | 937800004

• Description
• Specifications

• Datalogic Matrix 120 310-001 Fixed Barcode reader, 1D/2D | 937800004

  Matrix 120™ is the smallest ultra-compact industrial 2D imager that fits into any integration space. This is the newest entry level member of the best-in-class Matrix family of high performance industrial 2D imagers.

  The Matrix 120 imager leads the market for ease of use and has the highest industrial grade in its class; multiple models of the Matrix 120 imager allow it to cover an extensive range of applications in OEM and Manufacturing industries.

  The only imager on the market with an External Smart User Selectable Focus for an easy setup

  Ultra-compact form factor with the smallest Ethernet model on the market allows easy integration in every application

  Complete Product Range for applications in Manufacturing and OEM: WVGA for standard applications; 1.2 MP for high resolution bar codes; Wide angle version for proximity reading; 1D code model for best price/performance ratio; Polarized model for orthogonal mounting on reflective surfaces

  Multiple embedded connectivity options: Serial (RS-232 and RS-422), USB connection, Ethernet connection

  DL.CODE software offers a usable interface that guarantees Customer ease of use, Fast setup. It is intuitive since graphical and is characterized by large format images. DL.CODE software incorporates a high level of innovation, designed to exceed customer’s Needs

  IP65 protection and ESD safe for use in the Electronic industry Glass-free protection window for applications in the food industry

• Category	Specification
  Type	Fixed bar code reader
  Scanner Type	1D/2D
  Sensor Type	CMOS
  Linear (1D) Barcodes Supported	Planet, POSTNET
  2D (Matrix & Stacked) Barcodes Supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
  Optical Sensor Resolution (W x H)	1280 x 960 pixels
  Ports & Interfaces
  Connectivity Technology	Wired
  Standard Interfaces	USB, RS-232
  Performance
  Product Colour	Blue
  Housing Material	Plastic, Zinc
  International Protection (IP) Code	IP65
  Internal Memory	128 MB
  Power
  Power Source Type	DC
  Power Consumption (Typical)	2.4 W
  AC Adapter Output Voltage	30 V
  Weight & Dimensions
  Weight	117 g
  Width	45.4 mm
  Depth	31.1 mm
  Height	23.5 mm
  Operational Conditions
  Operating Temperature (T-T)	0 – 45 °C
