Dahua DHI-LPH75-ST470-B DeepHub Lite Education 75″ 4K UHD Interactive Smart Whiteboard

• Description
• Specifications

• Dahua DHI-LPH75-ST470-B DeepHub Lite Education 75″ 4K UHD Interactive Smart Whiteboard

  Dahua DeepHub Smart Interactive Whiteboard for education has powerful processing capabilities with its 8-core CPU, 4GB RAM and 64GB storage capacity. Equipped with a high-precision infrared frame with a 2mm identification diameter, and a 4K DLED panel, this whiteboard will give you an extraordinary experience with writing, controlling the whiteboard and displaying content on it.

  It features wireless screen sharing, file management, HD display, scan and go, and more AI functions to enhance your experience. You can rely on this whiteboard to modernize your meeting rooms and classrooms.

  Features
  75-inch 4K DLED display with Zero Air Gap technology that delivers a clear image in sharp, vivid colors.
  Wireless screen sharing from multiple devices with an intuitive, easy-to-use system.
  8 physical front buttons for quick access to functions.
  Smooth writing experience, and handwriting recognition.
  Quick file sharing by scanning a QR code, with easy file encryption for added privacy and security.
  Switches between Android and Windows, and OPS module is optional.

  Educational Tools Compatibility
  Effectively assists teachers in each teaching phase, including easy lesson preparation, interesting class organization and in-time performance assessments. It encourages students to fully participate in class activities such as video, games, quiz, etc., and inspires them to explore.

  Hidden Antenna Design
  The Wi-Fi and hotspot antenna is neatly concealed in the front of the device, ensuring the stability of the signal strength when using a flush mount, and giving the device its simple and sleek appearance.

  Screen Sharing
  The content on your screen can be freely shared with one other device through a wired connection.

  Wireless Screen Sharing
  In addition to basic file sharing, the device offers wireless screen sharing, interactive operations between two screens, and reverse transmissions. It also supports screen grouping (multiple transmission), host mode (for overall permission control), real-time transmission of images, videos and audios from the wireless camera of the mobile phone to the device, and split-screen mode that displays up to 9 splits on the same screen.

  Similar to Real Writing Experience
  The electronic whiteboard supports pen-point writing. It comes equipped with specialized pressure-sensitive writing pens, designed to enhance the writing experience. With its soft, comfortable nib, writing on the whiteboard feels natural, similar to the real writing experience.

  Easy to Share
  Enhances the experience of sharing files by scanning a code. It automatically determines the network of the device to readily share the QR code across the extranet and the intranet. QR code encryption and extraction are also featured, providing privacy and data security through the required entry of a 6-digit password for verification.

  Text Recognition
  Converts written letters into text in real time, using the default font of the system.

  AI Recognition of Drawings
  Identifies hand-drawn structures such as straight lines, arrow-straight lines, arrow-dotted lines, triangles, parallelograms, trapezoids, rectangles, pentagons, circles, cylinders, pentagrams, semicircles and ellipses.

  File Management
  Supports managing and using Office files, image, video and audio files, and file formats such as PDF and TXT.

  The whiteboard is ideal for indoor sites such as meeting rooms and classrooms.

• Feature	Details
  Operating System	Android 11
  CPU	Quad-core A73 + Quad-core A53
  RAM	4 GB (optional 8 GB)
  ROM	32 GB (optional 64 GB)
  LCD Panel	75 inch
  Backlight	D-LED
  Aspect Ratio	16:09
  Brightness	400 cd/m²(typ.)
  Contrast	1200
  Resolution	3840 x 2160
  Viewing Angle	178°(H) / 178°(V)
  Display Color	1.07B/10bit (8bit+FRC)
  Response Time	8 ms(typ.)
  Refresh Rate	60 Hz
  Touchscreen	Infrared touch technology
  Touch Points	Android: 32, Windows: 40
  Touch Accuracy	± 1 mm (over 90% Area)
  Touch Resolution	32767 x 32767
  Speaker	Built-in Speaker (2 x 15 W)
  Power Consumption	150 W(typ.); 300 W(max.)
  Standby Power	≤ 0.5 W
  Operating Temperature	0 °C to +40 °C (+32 °F to +104 °F)
  Storage Temperature	-10 °C to +50 °C (+14 °F to +122 °F)
  Operating Humidity	10%–90% (RH)
  Storage Humidity	10%–90% (RH)
  Product Material	Metal
  Glass	4 mm Anti-dazzle tempered glass
  Product Dimensions	1,707.5 mm x 93.0 mm x 1,050.0 mm (67.22″ x 3.66″ x 41.34″)
  Net Weight	52 kg (114.64 lb)
  Gross Weight	65 kg (143.30 lb)
  Certifications	CE, Energy Star, ROHS, REACH, WEEE
  Ports	Type C, HDMI, USB 3.0 Type-B, USB 3.0 Type A, Mic In, VGA In, RS-232, RJ45, SPDIF, OPS slot
  Included Accessories	Power cord, Passive stylus pen (x2), HDMI cable, Quick start guide, Wall mount bracket, Remote control, Accessory package, Legal and Regulatory Information
