D-Link DEM-310GT 1-Port Mini GBIC Module for 1000BaseLX (LC Duplex)

• Description
• Specifications
• Downloads

• D-Link DEM-310GT 1-Port Mini GBIC Module for 1000BaseLX (LC Duplex)


  The DEM-310GT is a high performance 1310nm single mode SFP (mini-GBIC) transceiver. Supporting full duplex, Gigabit speeds on single mode fiber for distances of up to 10km on 9µm respectively. The unit features a metal housing to reduce EMI and to increase durability. The DEM-310GT is hot pluggable and is backed by a standard 2-year product warranty and free technical support.

  * Third-Party Devices Must Comply With specified Supported Industry-Standard Specifications

• Specifications
  Port Standard	1000Base-LX (IEEE 802.3z)
  Connector Type	Duplex LC
  Duplex Mode	Full Duplex
  Flow Control Support	802.3x
  Fiber Type	9μm Single-Mode
  Maximum Distance	Up to 10 km
  Wavelength	1310 nm
  Power Support	3.3 V
  Power Budget	10.5 dB
  Hot Pluggable	Yes
  Laser Product Classification (Safety)	Class 1
  Safety Compliance (Laser)	EN60825-1
  TTL Signal Detect Indicator	Yes
  Enclosure Material	Metal
  EMI Reduction	Lower EMI

• Description	Downloads
  Datasheet	Download
