D-Link 180W Redundant Power Supply | DPS-520

• Description
• Specifications
• Downloads

• D-Link 180W Redundant Power Supply | DPS-520

  Stay protected against power failures.
  The DPS-520 offers uninterrupted operation for up to x4 D-Link switches and in the event of a power failure, it will be immediately activated, allowing your business to stay operational.


  High Flexibility and Availability
  Connect devices at distances of up to 100m

  PoE Capable
  Up to 180 W PoE output through PoH

  Cost-Effective Solution
  Supply 4 devices with redundant power with a single RPS

  Auto discovery
  Automatically detect PD (powered device) to deliver immediate power

  RPS Port Priority
  Allows the network administrator to define RPS failover policy

  Power Redundancy
  Provide power redundancy to network switches (non-PoE models)

  Status Reporting
  Monitor status and backup a failed switch via web browser

  2-Year D-Link Warranty
  You’re protected by one of the global leaders in the industry


  Flexible Deployment
  Any standard Category 5e or higher Ethernet cable can be used to connect the RPS to the switch, allowing the RPS to supply PoH power to the switch with up to 100m connection distance.


  Simple Installation
  The DPS-520 is compatible with DGS-1520-28 and DGS-1520-52 and can be installed as a standalone power supply unit or onto a standard mounted switch rack by inserting it into an optional DPS-800 open chassis, designed to hold x2 DPS-520 RPS units.

  Connect to the RPS with a standard CAT-5e cable with a connection distance of up to 100m.


  Status Reporting
  Switch status information can be monitored through any web browser with our comprehensive tool, allowing administrators to backup a failed switch.

• Category	Specification
  General Interfaces	– 4 x 10/100/1000BASE-T PoE ports
  	– 1 x 10/100/1000BASE-T MGMT port
  Standards	– PoH (Power over HDBaseT)
  Functionality	– PoE (Power over Ethernet)
  Power Budget	– 90 W per port
  	– 180 W total power budget
  Input Voltage Range	– 90 to 264 V AC
  Input Frequency	– 47 to 63 Hz
  Physical Dimensions	– 196 x 257 x 52 mm
  	– Panel size: 196 x 52 mm
  Weight	– 1.15 kg
  Operating Temperature	– 0 to 50 °C
  Storage Temperature	– -40 to 70 °C
  Operating Humidity	– 10 to 90% RH
  Storage Humidity	– 5 to 95% RH
  MTBF	– 53,858 hours
  Optional Accessories	– DPS-800 2-slot Rack Mount Kit
