Cooler Master MLX-D36M-A25PZ-R1 MasterLiquid 360Atmos ARGB
360 DEGREES OF COOL
The next generation AIO liquid cooling is here with the MasterLiquid 360 Atmos. The Atmos is our forward-thinking, innovative take on what an AIO cooler can and should be. Exceptionally silent performance provided by our SickleFlow Edge fans. An optimized user experience from unboxing to the MasterCTRL software. A pump top cover fully customizable with your own 3D-printed creations. Eco-friendly construction implemented throughout. Our signature dual chamber pump design, refined. The Atmos represents the best of the best in modern AIO liquid cooling, a full 360 degrees of cool.REFINED DUAL CHAMBER DESIGN
Our latest patented dual chamber design has been refined for enhanced cooling synergy. The new design increases water pressure and optimizes water flow directly to CPU hot spot.IMPROVED QUALITY
Fully automated production and assembly of the pump with fully recorded production history.ECO-FRIENDLY CONSTRUCTION
The pump top cover has been constructed from recycled plastic materials, while 35% of the cooler’s metal materials are recycable. Along with sustainable packaging materials and a 30% reduction in total packaging size, the Atmos is an eco-pioneer.LATEST SICKLEFLOW EDGE 120 FANS
Pre-installed SickleFlow Edge 120mm fans further improve cooling performance and simplify user installation.OPTIMIZED USER EXPERIENCE
With features such as our streamlined MasterCTRL software and modernized packaging techniques,
the Atmos is bringing a overhauled, and smoother,user experience.TUBE CLIPS INCLUDED
Tube clips are made for AIO tube size that not only to improve and strengthen your cooler setup, but also can fix your ARGB or PWM cables. -
Specification Details Product Number MLX-D36M-A25PZ-R1 Exterior Color Black CPU Socket LGA1700, LGA1200, LGA1151, LGA1150, LGA1155, LGA1156, AM5, AM4 Radiator Material Aluminum Radiator Dimensions 394 × 119 × 27.2 mm / 15.5 × 4.7 × 1.1 inch Pump Dimensions 84.9 x 81 x 53.15 mm / 3.3 x 3.2 x 2.1 inch Pump MTTF >210,000 Hours Pump Noise Level 25 dBA (Max) Pump Connector 4-Pin Pump Rated Voltage 12 VDC Pump Power Consumption 3.84W Fan Dimensions (L x W x H) 120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch Fan Quantity 3 PCS Fan LED Type ARGB Fan Speed 690-2500 RPM ± 10% Fan Airflow 70.7 CFM (Max) Fan Noise Level 27.2 dBA (Max) Fan Pressure 3.61 mmH₂O (Max) Fan Bearing Type Loop Dynamic Bearing Fan MTTF >160,000 Hours Fan Power Connector 4-Pin (PWM) Fan Rated Voltage 12 VDC Fan Rated Current 0.2A Fan Safety Current 0.3A RAM Clearance N/A Warranty 5 years Series MasterLiquid Cooler Type Liquid Cooler Radiator Size 360 -
