  MOBIUS 120P ARGB WHITE EDITION
  MORE BALANCE, MORE BURST
  Ring Blade Design (RBD)
  Pressure Air Acceleration
  Absolute Acoustics
  Luminescent Light Effects
  Addressable Gen 2 RGB

  PERFECTING ENGINEERING
  Cooler Master’s Mobius120P ARGB White Edition is our new series of performance fans. With our enhanced Ring Blade Design, the Mobius Series optimizes both performance and acoustics, catering to a dynamic range of applications from case, liquid or air, to overclocking and intense gaming.

  RING BLADE DESIGN (RBD)
  Interconnecting fan blades designed for a reinforced and rigid structure, eliminating vibration for stable and fluid fan operation.

  OIL REFLOW BEARING SYSTEM
  Our newly designed ORBS (Oil Reflow Bearing System)has thick oil film and lubrication formation that can achieve stable running

  OIL REFLOW
  The oil flows back to the sealed bearing to create constant lubrication against friction and increases the life span of the fan.

  DUST PROOFING
  The sealed and concave position of the bearing prevents air and dust exposure and ensures a smooth transfer of motion.

  ANTI-SWAY SYSTEM
  Magnetic ring prevents bearing shaft from tilting, stabilizing the fan to prevent fan blade obstruction under various orientations, as well as oil spray.

  PRESSURE AIR ACCELERATION
  Angled inner frame rim with chamfered side vents boost airflow draw, maximizing force induced air pressure and diminishing dead air.

  ANTI-VIBRATION DAMPER
  Exclusive Cooler Master color accent dampers diminish vibration and rattling to maintain chassis stability for silent performance.

  ARGB MOTHERBOARD COMPATIBILITY
  Addressable Gen 2 RGB syncs with Cooler Master’s MasterPlus+ software and dedicated controller, allowing customization of individual LED colors, effects, brightness and more – all from an intuitive, convenient interface.

• Attribute	Details
  Product Number	MFZ-M2DW-24NP2-R1
  Exterior Color	White
  Fan Dimensions	120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch
  Fan Profiles	Addressable Gen 2 RGB
  Number of LEDs	8pcs
  Fan Speed	0-2400 RPM ± 10%
  Fan Airflow	75.2 CFM
  Fan Noise Level	30 dBA
  Fan Bearing Type	Loop Dynamic Bearing
  Fan Air Pressure	3.63 mmH2O
  Fan MTTF	>200,000 Hours
  Fan Power Connector	4-Pin (PWM)
  Fan Rated Voltage	12 VDC
  Fan Rated Current	0.18A
  Fan Safety Current	0.35A
  Fan Power Consumption	2.16W
  RGB Connector	3-Pin ARGB
  RGB Rated Voltage	5 VDC
  RGB Rated Current	0.48A
  Fan Weight	179g / 0.38 lbs
  Warranty	5 years
  Series	Mobius Series
  Cooler Type	Case Fan
  Fan Size	120
